- Page 1 I n s t r u c t i o n M a n u a l SUB-1200 120W 12" POWERED SUBWOOFER...
-
Page 2: Safety Instructions
Safety Instructions CAUTION RISK OF SHOCK CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No user- serviceable parts inside. Only refer servicing to qualified service personnel. Explanation of Graphical Symbols The lightning flash & arrowhead symbol, within an equilateral triangle, is intended to alert you to the presence of danger. - Page 3 CAUTION: Read this before operating your unit The apparatus is not disconnected from the AC power source so long as it is connected to the wall outlet, even if the apparatus itself is turned off. To fully insure that the apparatus is indeed fully void if residual power, leave unit disconnected from the AC outlet for at least fifteen seconds.
- Page 4 Club VocoPro for Karaoke news and events, chat rooms, club directories and even a Service directory! We look forward to hearing you sound like a PRO, with VocoPro, your ultimate choice in Karaoke entertainment. Please record the model number and serial number below, for easy reference, in case of loss or theft. These numbers are located on the rear panel of the unit.
-
Page 5: Listening For A Lifetime
Now it’s time to consider how you can maximize the fun and excitement your equipment offers. VocoPro and the Electronic Industries Association’s Consumer Electronics Group want you to get the most out of your equipment by playing it at a safe level. -
Page 6: Before Getting Started
5. Nonuse Periods - When the unit is not used, turn the power off. When left unused for a long period of time, the unit should be unplugged from the household AC outlet. ITEM: QUANTITY: SUB-1200 AC Power Cable Instruction Manual Things to Consider... -
Page 7: Installation Environment
Installation Installation Environment 1. Water and Moisture - Do not use this unit near water – for example near a bathtub, washbowl, swimming pool, or the like. Damp basements should also be avoided. 2 . Condensation - Moisture may form in the unit in the following cases: •... -
Page 8: Getting Connected
Connecting to a system with separate components If you only have one set of pre-amp outputs on your amplifier/mixer and need to send the signal to the Sub-1200 as well as another amplifier/mixer, first send the signal to the Sub-1200 via the 'LINE IN' (RCA) jacks, and then from the 'LINE OUT' (RCA) jacks, connect a patch cable to the 'AUDIO INPUT' jacks on your amplifier/mixer. - Page 9 If no low-level Pre-Amp outputs are available, you need to run speaker cables from your main amplifier to the Sub-1200. Run the main LEFT and RIGHT speaker cables to the Sub-1200 HI-LEVEL IN binding posts. Be sure to double check that the polarity (-/+) on the receiver or amplifier matches the polarity on the binding posts of the SUB-1200.
- Page 10 AUTO position instructs the Sub-1200 to remain in STANDBY mode until the unit receives an input signal. NOTE: If the Sub-1200 unit does not receive an input signal for approximately 10 minutes, it will switch to stand by mode until it receives a further signal.
- Page 11 Position/Location Your Sub-1200 should perform well in just about any room location. In fact, unless your ear is within a couple of feet of the subwoofer, the bass should seem to radiate from your main speakers. We recommend setting the Sub- 1200 within 12"...
-
Page 12: Troubleshooting
Check that the power cord is plugged in securely at both ends and make sure that the power outlet the Sub-1200 is plugged into is functioning properly. Unplug the power cord and remove the fuse holder with a screwdriver and check the fuse (located just above the power plug). -
Page 13: Glossary Of Terms
Glossary of Terms Digital Echo- Digital echo is a synthetically processed sound effect that mimics natural echo. Echo in general is the "bouncing" of waves back and forth between 2 surfaces. This effect gives a spacious or ambient feeling that works great with vocals. - Page 14 Glossary of Terms Y-Adapter - Any type of connection that splits a signal into two parts. An example would be a connector with one male RCA jack on one end, and two female RCA jacks on the other end. Woofer - A speaker, (driver), used for low-frequency reproduction. Usually larger and heavier than a midrange or tweeter.
