  • Page 1 OWNER’S MANUAL CDG X-3 Mark II DIGITAL CDG AND CASSETTE KARAOKE PLAYER IMPORTANT INFORMATION: Thank you for purchasing the CDG X-3 Mark II To make full and effective use of this unit, please read this Owner ’s Manual carefully before operating.

  • Page 2: General Warning

    GENERAL WARNING CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated-insulated “dangerous voltage”...

  • Page 3: General Safety Precautions

    STRUCTIONS SHOULD BE KEPT FOR FUTURE REFERENCE. ALSO KEEP THE BOX IN CASE THE UNIT NEEDS TO BE RETURNED FOR SERVICE. 3. HEED WARNINGS - ALL WARNINGS ON THE CDG X-3 MARK II AND IN THESE OPERATING INSTRUCTIONS SHOULD BE FOLLOWED.
  • Page 4 CDG X-3 MARK II FEATURES • 19 STEP DIGITAL KEY CONTROLLER • BUILT-IN CASSETTE PLAYER FOR PLAYBACK AND RECORDING • BUILT-IN SHOCK RESISTANT CD/CDG PLAYER • 3 MICROPHONE JACKS WITH INDIVIDUAL VOLUME CONTROLS (TWO FOR VOCALS, ONE DRY FOR KJ/DJ ANNOUNCEMENTS) •...

  • Page 5: Table Of Contents

    TABLE OF CONTENTS Congratulations! And thank you for purchasing the VocoPro CDG X-3 Mark II. With proper care and handling, this unit will continue to provide you with years of entertainment and fun for friends and family. Please read this manual carefully before getting started.

  • Page 6: Before You Start

    BEFORE YOU START Thank you for purchasing the CDG-X3 Mark II. At VocoPro we care about product quality and customer satisfaction. We know the CDG-X3 Mark II will provide years of quality enjoyment and reliable music entertainment for you when used properly.

  • Page 7: Quick Start

    It is best to begin by first setting the music volume at a comfortable level for the room in which you are using your CDG X-3 Mark II. The number of people in a room will generally have an effect on the acoustics of a room and how much volume you will need.

  • Page 8: Using Effects And Changing The Key

    USING EFFECTS AND CHANGING THE KEY ADDING BASS OR TREBLE TO THE MUSIC Locate the small “BASS” and “TREBLE” control knobs on the front of the CDG-X3 Mark II underneath the large “MUSIC VOL” knob. To add bass tones to the music, turn the “BASS” knob clockwise until you have added the desired amount of bass tone to the music.

  • Page 9: Changing The Key (Cont.)

    CHANGING THE KEY (Cont.) USING THE CASSETTE DECK RAISING OR LOWERING THE PITCH (OR KEY) OF THE MUSIC To raise the pitch or key of the music press the “sharp” (#) sign once for each ½ step you would like the music raised. To lower the pitch or key of the music press the “flat”...

  • Page 10: Using The Cassette Deck (Cont.)

    USING THE CASSETTE DECK (Cont.) TO RECORD WITH THE CASSETTE DECK You can record you voice on the cassette deck while singing with a Karaoke CD/CDG. NOTE: Be sure to select the “CDG” button located under the CDG tray before you start. Follow the instructions for playing a CD/CDG and select the desired “track”...

  • Page 11: Listen To Your Recording

    IMPORTANT! IF THE FUSE BLOWS OUT IT IS AN IMPORTANT INDICATION THERE MAY BE A SHORT SOMEWHERE IN THE SYSTEM. DO NOT REPLACE THE FUSE! TAKE YOUR CDG X-3 MARK II TO AN AUTHORIZED REPAIR FACILITY. REPLACING THE FUSE COULD POSSIBLY CAUSE ADDITIONAL DAMAGE THAT MAY NOT BE COVERED BY THE WARRANTY.

  • Page 12: Connecting Other Components

    COMPONENTS TO THE CDG X-3 MARK II The CDG X-3 Mark II is designed so you can connect other components to it and use the Karaoke features that are built-in to the CDG X-3 Mark II in conjunction with those components.

  • Page 13: Using The Remote Control

    CDG tray and stop. The memory function can be used with the remote control to program specific song selections when using the CD/CDG player. The remote control will not work with the tape deck. Be sure not to block the infrared eye on the CDG X-3 Mark II (See #15 FRONT PANEL diagram) or the sensor on the hand held remote control (#1 REMOTE CONTROL diagram).

  • Page 14: Parts And Functions Of The Remote Control

    INFRARED REMOTE SENSOR: The sensor on the top of the hand held remote control communicates with the infrared sensor on the front panel of the CDG X-3 Mark II and should not be covered or the remote control will not work properly.

  • Page 15: Trouble Shooting Guide

    Be sure the “VIDEO OUTPUT” jack (See PARTS AND FUNC- TIONS diagram) on the rear panel of the CDG X-3 Mark II is connected to the “VIDEO INPUT” section of the TV monitor. You will need an “RF Modula- tor”, or VCR.

  • Page 16: Parts And Functions (Front Panel)

    PARTS AND FUNCTIONS (FRONT PANEL) POWER BUTTON: Turns on the power to the CDG X-3 Mark II. TAPE COUNTER: Use the tape counter when playing or recording cassettes to keep track of your location on the tape. OPEN/CLOSE BUTTON: To open/close CD/CDG tray.
  • Page 17 For example, if an additional tape deck or CD player is used with the CDG X-3 Mark II, and it is connected to the “AUX” input jacks, this key will need to be selected before the component can be used.
  • Page 18 (See “Using Effects and Changing the Key” and “Connecting Other Com- ponents to the CDG X-3 Mark II”) Note: The key control fea- ture will not change the tempo of the song being played. FLAT KEY: Press this key to LOWER the pitch of the song selection being played.

  • Page 19: Parts And Functions Rear Panel

    FUSE: IMPORTANT! If the fuse blows out it’s a good indication that there may be a short in the system. DO NOT REPLACE THE FUSE! Doing so could possibly cause additional damage to the unit. Take your CDG X-3 Mark II to an authorized repair facility.

  • Page 20: Parts And Functions (Rear Panel Cont.)

    You will need an “RF” modulator. To use an “RF” modulator, connect the “VIDEO OUTPUT” jack on the back of the CDG X-3 Mark II to the “VIDEO IN” jack on the “RF” modulator. Next, Connect the “OUTPUT” of the “RF”...

  • Page 21: Connection A Television Monitor (Diagram)

    CONNECTING A TELEVISION MONITOR...

  • Page 22: Connection Diagram For Other Components

    CONNECTION DIAGRAM for other components...

  • Page 23: Specifications

    AUDIO INPUT (AT1KHZ) MICROPHONE ... AUX/DVD/LD/CDG/CASSETTE... AUDIO OUTPUT... VIDEO INPUT CDG/LD/DVD... FREQUENCY RESPONSE AUX/DVD/LD/CDG/CASSETTE... TONE CONTROL (MUSIC) BASS... TREBLE ... ECHO TIME DELAY... KEY CONTROL RANGE ... SIGNAL TO NOISE RATIO... CASSETTE MOTOR SPEED (ATT-111N 3KHZ) ... CASSETTE WOW-FILTER ATT-111N 3KHZ) ... POWER SUPPLY, OTHERS POWER REQUIREMENTS...
