Vizio VT420M Quick Start Manual

Q U I C K
S T A R T
G U I D E
VT420M HDTV
VT470M HDTV
BEFORE YOU BEGIN BEFORE YOU BEGIN
1
What's In the Box
• VIZIO HDTV
• Base Plate
• VIZIO Remote Control
(including 2 AA batteries)
• User Manual
(read Safety Guidelines)
• Registration Card
• Quickstart Guide
• Power Cord
• Premium Screen Cleaning Cloth
INSTALLING YOUR HDTV
2
We provide professional installation services. Visit www.VIZIO.com
call 888-849-4623 to order today!
Attaching the Stand Base to the TV
1. Place the TV face down on a flat surface with a
soft cloth protecting the screen.
2. Line up the base plate with the stand neck
(attached to the TV) and carefully push the base
onto the neck.
3. On the bottom of the base plate, insert the
thumbscrews and tighten snugly .
(see figure 1)
4. Move the TV into an upright position and place so
that the rear connectors remain accessible.
Preparing the TV for Wall Mounting - please refer to "Wall mounting
your HDTV" in your User Manual for more information.
MATCH YOUR VIZIO TO A
CERTIFIED* WALL MOUNT
ARTICULATING
FLUSH MOUNT TILT MOUNT
ARM MOUNT
VMF37-60 VMT37-60
*Tested and certified by VIZIO engineers for compatibility with your TV.
©2009 VIZIO Inc.
Z41TN023997 1A
CONNECTING TO DEVICES
3
YOU DESERVE
THE BEST!
CONNECTION
ADVICE
PICTURE QUALITY
CONNECTION TYPE
CONNECTOR IMAGE
or
MAKE THE BEST
FIG. 1
HIGH DEFINITION
CONNECTION!
OPTICAL
OUT
POWER THE TV
4
VMA31-45
Turn on your TV by pressing the Power button on
either the TV or the remote control.
The GREEN inputs are OPTIMIZED for High Definition Video and
Connect using these inputs wherever possible.
GOOD
HIGHEST DIGITAL
ANALOG HD
QUALITY PICTURE
QUALITY PICTURE
HDMI DTV/TV
COMPONENT
VIZIO HIGH DEFINITION CABLES
For more information about VIZIO Certified* High Definition
cables please visit us at: www.VIZIO.com
BACK OF TV SIDE OF TV
HDTV TIPS
Audio.
Make sure you have components with HDMI
outputs to ensure the BEST possible picture.
COMPATIBLE
LOW RESOLUTION
NOT RECOMMENDED
3 WAYS TO WATCH
HIGH DEFINITION VIDEO
AV/S-VIDEO
1. Get a VIZIO Blu-ray
2. Contact your cable company or satellite
provider to learn more about HD
programming in your local area (an HD
cable box or satellite receiver may
be required.
3. You may be able to get HD signals using
an off-air antenna. To see if you can
receive off-air HD signals, and for help
choosing the right antenna, visit
www.antennaweb.org
HIGH DEFINITION
HOME THEATER
YOUR VIZIO TV EVEN
HAS EASY TO ACCESS
SIDE INPUTS
VIZIO Blu-ray
Bring your movies to life! 1080p Full HD playback
delivers crystal clear images with lifelike detail and High
Definition Audio puts you in the center of the action. Visit
www.VIZIO.com
HIGH-DEFINITION SOUND
Complete your total Home Theatre experience with stunning
audio from VIZIO accessories such as the Sound Bar
with Wireless Subwoofer.
Visit www.VIZIO.com
SATELLITE / CABLE GAMING CONSOLE BLU-RAY / DVD
™
® Disc Player.
®
for more details.
or call 888-849-4623.
