Dear VIZIO Customer,
Congratulations on your new VIZIO VM190XVT or VM230XVT television purchase. To get the most
out of your new VIZIO HDTV, please read these instructions before making any adjustments, and
retain them for future reference. We hope you will experience many years of enjoyment from your
new VIZIO HDTV High Definition Television.
For assistance, please call 877-MYVIZIO (877-698-4946) or e-mail us at www.VIZIO.com.
To purchase or inquire about accessories and installation services for your VIZIO HDTV, please visit
www.VIZIO.com
our website at
We recommend you register your VIZIO HDTV either at our website
mail your registration card. For peace of mind and to protect your investment beyond the standard
warranty, VIZIO offers on-site extended warranty service plans. These plans give additional coverage
during the standard warranty period. Visit our website or call us to purchase a plan.
Write down the serial number located on the back of your HDTV for easy reference when obtaining
warranty support:
Serial #: _____________________
VIZIO is a registered trademark of VIZIO, Inc. dba V, Inc.
HDMI logo and "High Definition Multimedia Interface" are registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby Laboratories.
and
TruSurround HD and TruVolume technologies are incorporated under license from SRS Labs, Inc.
This product qualifies for ENERGY STAR in the "factory default (Home Use)" setting and this is the setting in which
power savings will be achieved. Changing the factory default picture setting or enabling other features will increase
power consumption that could exceed the limits necessary to qualify for Energy Star rating.
THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED
ARE FOR ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND
OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC.
SUBJECT TO CHANGE WITHOUT NOTICE OR OBLIGATION. © 2008 VIZIO INC. ALL RIGHTS RESERVED.
Version 9/16/2009
or call toll free at (888) 849-4623.
are trademarks of SRS Labs, Inc.
www.VIZIO.com
VIZIO VM190XVT/VM230XVT User Manual
www.VIZIO.com
Purchase Date _____________________
1
or fill out and
PRODUCT SPECIFICATIONS ARE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VM190XVT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Vizio VM190XVT

Summary of Contents for Vizio VM190XVT

  • Page 1 THE TRADEMARKS SHOWN HEREIN ARE THE PROPERTY OF THEIR RESPECTIVE OWNERS; IMAGES USED ARE FOR ILLUSTRATION PURPOSES ONLY. BRAVO, VIZIO AND THE V LOGO AND WHERE VISION MEETS VALUE AND OTHER VIZIO TRADEMARKS ARE THE INTELLECTUAL PROPERTY OF VIZIO INC.

  • Page 2: Important Safety Instructions

    VIZIO VM190XVT/VM230XVT User Manual Important Safety Instructions Your HDTV is designed and manufactured to operate within defined design limits, and misuse may result in electric shock or fire. To prevent your HDTV from being damaged, the following instructions should be observed for the installation, use, and maintenance of your HDTV. Read the following safety instructions before operating your HDTV.
  • Page 3 Liquid sprays or any object drops into your HDTV. Your HDTV is exposed to rain or other moisture. Your HDTV is dropped or damaged in any way. The performance of your HDTV changes substantially. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 4: Television Antenna Connection Protection

    Advisory of the DTV Transition The nationwide switch to digital television broadcasting was completed on June 12, 2009. Your VIZIO HDTV is capable of receiving Digital Broadcasts, and no Digital Converter Box is required. For additional information, please contact the parties listed below, as appropriate: FCC (US Federal Communications Commission) http://www.fcc.gov/...

  • Page 5: Table Of Contents

    Wall Mounting Your HDTV ... 9 CHAPTER 2 BASIC CONTROLS AND CONNECTIONS... 10 Front Panel ..10 Rear Panel Connections... 11 CHAPTER 3 VIZIO REMOTE CONTROL ... 12 Installing the Batteries ... 12 Remote Control Range... 12 VIZIO Remote Control Precautions... 12 Remote Control Buttons ...
  • Page 6 VIZIO VM190XVT/VM230XVT User Manual Input Menu..27 Wide..28 CC (Closed Caption) ...29 Sleep Timer Menu ..29 TV Settings Menu ..30 Input Source...30 Picture ...30 Audio ...30 Tuner...30 PC Settings ...31 Name Input...31...

  • Page 7: Hdtv Accessories And Services

    Blu-ray DVD Players VIZIO also offers installation services and extended warranty services for your HDTV. To purchase or inquire about additional accessories and services for your VIZIO HDTV, visit our website at www.VIZIO.com or call us toll free at 877-MYVIZIO (877-698-4946).

  • Page 8: Chapter 1 Setting Up Your Hdtv

    Avoid installing your HDTV in places with high humidity, dust, or smoke so you do not shorten the service life of the electronic components. Install your HDTV in a level, landscape orientation, with the VIZIO logo at the bottom to prevent poor ventilation and excessive component damage.

  • Page 9: Wall Mounting Your Hdtv

    Attach your HDTV to a wall mount (sold separately) using the mounting holes in the back panel of your HDTV. b. Read the instructions that came with your specific wall mount to properly hang your HDTV. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 10: Chapter 2 Basic Controls And Connections

    VIZIO VM190XVT/VM230XVT User Manual Chapter 2 Basic Controls and Connections Front Panel POWER ‘VIZIO’ LIGHT—The VIZIO logo lights white when powered on. Your HDTV TV features touch-sensitive buttons that light when active. The proximity sensor detects you, and as your hand gets closer to the surface, the intensity of the LEDs increase.

  • Page 11: Rear Panel Connections

    Use the white and red connectors to connect the external audio from the same source. 10. AUDIO OUT—(OPTICAL) When digital TV is selected for viewing, the audio associated with the programming will be available on the SPDIF Optical connector for connection to a VIZIO Sound Bar or your home theater system.

  • Page 12: Chapter 3 Vizio Remote Control

    VIZIO VM190XVT/VM230XVT User Manual Chapter 3 VIZIO Remote Control Installing the Batteries 1. Remove the battery cover. 2. Insert two AAA batteries into the remote control. Make sure that you match the (+) and (-) symbols on the batteries with the (+) and (-) symbols inside the battery compartment.

  • Page 13: Remote Control Buttons

    Fast Reverse ( )—Press to skip backward in 15 second increments. You can also press the left navigation key. Also press this button to navigate in open menus. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual — Press to navigate open menus, www.VIZIO.com...

  • Page 14: Chapter 4 Getting Started

    VIZIO VM190XVT/VM230XVT User Manual Chapter 4 Getting Started Your HDTV has a built-in setup app that plays when you turn on your TV for the first time. Follow the on- screen directions to easily setup your new HDTV. 1. Insert batteries into the remote control.

  • Page 15: Chapter 5 Using Your Hdtv For The First Time

    Also, verify that the AC/DC power adapter is plugged into a correctly grounded electrical outlet or surge protector. 1. Press the power button on the remote control. The VIZIO logo on the front will light silver. 2. Select the input to which your device is connected that provide TV programming (i.e. TV, HDMI, COMP).

  • Page 16: Pause-Live-Tv (Plt)

    VIZIO VM190XVT/VM230XVT User Manual Pause-Live-TV (PLT) This feature allows you to pause the digital program being watched (either from your cable service without set-top box or from an antenna) and resume watching it at the point the program was paused.

  • Page 17: Chapter 6 Connecting Equipment

    Composite. So try to use one of those connections first. Note: To maintain the display quality, use a VIZIO certified HDMI cable. This cable is available in 6, 8, and 12 foot lengths. Visit www.vizio.com or call 1-888-VIZIOCE (1-888-849-4623) for details.

  • Page 18: Connecting Your Cable Or Satellite Box

    Cable and Satellite Boxes that have a HDMI digital interface should be connected using HDMI for optimal results. To maintain image quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15, and 30 foot lengths. See www.VIZIO.com or call 877-MYVIZIO (877-698-4946) for details.

  • Page 19: Using Component Video (Better)

    R AUDIO jacks on your HDTV. 4. Turn on your HDTV and cable/satellite box. 5. Select AV using the INPUT button on the remote control, or directly by pressing the AV button on the remote control. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 20: Using Composite Video (Compatible)

    VIZIO VM190XVT/VM230XVT User Manual Using Composite Video (Compatible) 1. Turn off your HDTV and cable/satellite box. 2. Connect the video cable (yellow) from your cable/satellite box to the AV jack (yellow) on your HDTV. 3. Connect the audio cables (white and red) from your cable/satellite box to the corresponding L and R AUDIO jacks on your HDTV.

  • Page 21: Connecting Your Dvd Player

    DVD players that have a HDMI digital interface should be connected using HDMI for optimal results. To maintain image quality, use a VIZIO certified HDMI cable. This cable is available in 6, 15, and 30 foot lengths. See www.VIZIO.com or call 877-MYVIZIO (877-698-4946) for details.

  • Page 22: Using Component Video (Better)

    VIZIO VM190XVT/VM230XVT User Manual Using Component Video (Better) 1. Turn off the power to your HDTV and DVD player. 2. Connect the component cable (green, blue, and red) from your DVD player to the COMPONENT jacks on your HDTV. 3. Connect the audio cables (white and red) from your DVD player to the COMPONENT AUDIO jacks on your HDTV.

  • Page 23: Using Composite (Av) Video (Compatible)

    2. Connect the coaxial (RF) connector from your antenna or cable to the DTV/TV connector on your HDTV. 3. Turn on the power to your HDTV. 4. Select TV using the INPUT button on the remote control, or directly by pressing the TV button on the remote control. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 24: Connecting Your Vcr Or Video Camera

    VIZIO VM190XVT/VM230XVT User Manual Connecting Your VCR or Video Camera Using S-VIDEO 1. Turn off the power to your HDTV and VCR or Video Camera. 2. Connect the S-VIDEO cable from your VCR or video camera to the S-VIDEO jack on your HDT...

  • Page 25: Connecting A Home Theater System

    6. Select RGB using the INPUT button on the remote control or side of your HDTV. Note: Refer to your PC computer user manual for more information about the video output requirements. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual COMPUTER www.VIZIO.com...

  • Page 26: Chapter 7 Viewing Pictures

    VIZIO VM190XVT/VM230XVT User Manual Chapter 7 Viewing pictures Connect a USB flash drive to the USB port on your HDTV to view photos. USB drives that are USB 2.0 and FAT or FAT32 are supported. The USB Port does not support external hard drives or USB hubs.

  • Page 27: Chapter 8 Adjusting Your Hdtv Settings

    7. Press EXIT to close the HDTV Settings App. Input Menu Select the Input Source for your HDTV. Choose from TV, AV, Comp, HDMI-1, HDMI-2, VGA, and Photos. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual " to select one of !"# to adjust the...

  • Page 28: Wide

    VIZIO VM190XVT/VM230XVT User Manual Wide Select how the picture displays on the screen. As you select an option, you will see the screen adjusting to the different sizes. Select how the picture displays on the screen. As you select an option, you will see the screen adjusting to the different sizes.

  • Page 29: Cc (Closed Caption)

    Window Color (color of the area where characters are displayed) Window Opacity (transparency of the area where characters are displayed) Sleep Timer Menu Select the timer to turn off the TV in 30, 60, 90, 120 or 180 minutes. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 30: Tv Settings Menu

    VIZIO VM190XVT/VM230XVT User Manual TV Settings Menu When you first turned on your HDTV you set up your TV for DTV / TV channels using the Initial Setup screens. If you did not do this or if your setup has changed, you can do this from the TV menu.

  • Page 31: Skip Channel

    " 3. Press to select Input Labels, and then press OK to show the list of 10 preset labels. " 4. Press to select the new input label name, and then press OK. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 32: Parental Controls

    VIZIO VM190XVT/VM230XVT User Manual To make your own custom label: 1. Select Input Source, and then press OK to show the list of inputs. 2. Press " to select the input label you want to change, and then press OK.

  • Page 33: Block Unrated Tv

    Enter a new, 4-digit password using the number buttons on the remote control. Enter it a second time to confirm you entered it correctly. Note: Make sure you write down and store the new password in a secure place. The Reset Locks feature does NOT reset the password. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 34: Menu Languages

    VIZIO VM190XVT/VM230XVT User Manual RESET LOCKS Return all Parental Control lock settings to factory default. A screen will come up to confirm your selection or to cancel it. Press $ or # to make the selection, and then press OK to accept it.

  • Page 35: Optical Audio Out

    When the programming switches to a commercial or when changing from channel to channel, volume fluctuations occur. When turned ON, SRS TruVolume comfortable and consistent volume level. VIZIO recommends turning TruVolume off when listenting to music content. Equalizer Choose Flat, Rock, Pop, Classical, or Jazz. You can also adjust Bass and Treble.

  • Page 36: Contrast

    VIZIO VM190XVT/VM230XVT User Manual Contrast Adjust the white levels in the picture. If the contrast is too low the picture will look washed out and if the contrast is too high you will not be able to see any detail in the bright parts of a picture.

  • Page 37: Photo Menu

    Choose from Home, Movie, Game, or Custom to vary the screen color/lighting when viewing your photos. Slide Settings Choose Repeat (On or Off), Shuffle (On or Off), Full Screen (On or Off), or Speed (Slow or Fast) Exit Exit the Photo menu. Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual www.VIZIO.com...

  • Page 38: Slide Size

    1. Remove the power cable from the wall outlet. 2. Use a soft cloth moistened with diluted neutral cleaner to clean the TV and remote control. VIZIO recommends using an HDTV cleaning solution which can be purchased at any major retailer.

  • Page 39: Troubleshooting Guide

    If the TV fails or the performance changes dramatically, check the display in accordance with the following instructions. Remember to check the peripherals to pinpoint the source of the failure. If the display still fails to perform as expected, contact the VIZIO for assistance by calling 1-877-MYVIZIO (698- techsupport@VIZIO.com.
  • Page 40 TV has video that is many times better than old TV so you will see interference and deficiencies you did not know you had. Make sure the power button is ON (VIZIO logo glows white). Make sure AC/DC power adapter is securely connected to the AC socket.

  • Page 41: Telephone & Technical Support

    For technical assistance contact our VIZIO Technical Support Department via email or phone. Hours of operation: Monday - Friday: 6 am to 9 pm Please have your VIZIO model number, serial number, and date of purchase available before you call. Telephone: (888) 849-4623 (949) 428-2525 Fax: (949) 585-9514...

  • Page 42: Compliance

    VIZIO VM190XVT/VM230XVT User Manual Compliance Caution: Always use a power cable that is properly grounded. Please use the AC cords listed below for each area. USA: UL Germany: VDE Japan: Electric Appliance Control Act FCC Class B Radio Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 43: Chapter 10 Specifications

    8.10 lbs without stand, 8.67 lbs with stand Gross Weight 12.84 lbs Certifications Energy Star 3.0, CSA, CSA-US, FCC Class B Compliances EIA/CEA-766-A Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual 1x Component and stereo audio 2x HDMI 1x RGB 1x USB Port (photo/service) www.VIZIO.com...
  • Page 44 VIZIO VM190XVT/VM230XVT User Manual VM230XVT Specifications Panel 23.” Diagonal, 16:9 Aspect Ratio Resolution 1920 x 1080 pixels Pixel (Dot) Pitch 0.265mm(H) x 0.265mm(V) Display Compatibility FHDTV (1080p) Colors 16.7 Million Brightness 300nits cd/m (typical) Dynamic Contrast 20,000:1 Ratio Response Time...

  • Page 45: Preset Pc Resolutions

    1280 x 1024@75Hz 1360 x 768@60Hz 1440x900R@60Hz 1440 x 900@60Hz 1440 x 900@75Hz 1600 x 1200@60Hz 1680x1050R@60Hz 1680 x 1050@60Hz 1920 x 1080R@60Hz Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual Horz Freq Horz Vert Freq (kHz) Polarity (Hz) 31.469 59.94 37.861 72.809...
  • Page 46 VIZIO VM190XVT/VM230XVT User Manual VM230 Preset PC Resolutions Preset Pixel Format 640 x 480@60Hz 640 x 480@72Hz 640 x 480@75Hz 800 x 600@56Hz 800 x 600@60Hz 800 x 600@72Hz 800 x 600@75Hz 1024 x 768@60Hz 1024 x 768@70Hz 1024 x 768@75Hz...

  • Page 47: Limited Product Warranty

    (50) United States or Puerto Rico. VIZIO's Responsibility VIZIO displays purchased new from an authorized VIZIO U.S. reseller and that are used in the fifty (50) United States or Puerto Rico are warranted to be free from manufacturing defects in materials and workmanship for one (1) year from the date of the original retail purchase.

  • Page 48: Owner's Responsibility

    VIZIO. If the product is returned to VIZIO (i) without a VIZIO return authorization number, and/or (ii) beyond the fifteen (15) day period, and/or (iii) without proper packaging, VIZIO retains the right to refuse delivery of such return or may return the unit to the customer at the customer's expense and with no refund issued.

  • Page 49: Warranty Replacement Procedure

    VIZIO's option and sole discretion. Proof of purchase is required to confirm the product is within the one- year limited warranty period and meets the terms and conditions of the VIZIO Limited Product Warranty.

  • Page 50: Index

    VIZIO VM190XVT/VM230XVT User Manual Index 16:9 ...28 4:3 ...28 Accessories...7 Adjustments Volume...10 Advanced Adjustments ...27 Ambient Light Sensor...35 Antenna...17 Aspect Ratio...28 Audio Settings Menu ...34 Audio Mode ...34 Balance ...34 Equalizer adjustments...35 Optical Audio Out ...35 Reset Audio Mode...35 SRS TruVolume ...35 SRS TSHD (surround sound)...35...
  • Page 51 Tuner Mode...30 TV Menu ...27 TV Settings App ...27 CC Menu ...29 Input Menu ...27 Sleep Timer Menu...29 Version 9/16/2009 VIZIO VM190XVT/VM230XVT User Manual TV Settings Menu...30 Wide Menu ...28 TV Settings Menu Input Source Menu...30 Menu Language ...34 Name Input...31 Parental Controls Menu ...32...
