Summary of Contents for Freund FE-IPDS-26B
- Page 1 FE-IPDS-26B Door Phone User Manual FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Herzegovina www.ip-integra.ba info@ip-integra.com Tel. +387 33 922 890...
- Page 2 2.2. Receiving a Call ..................................3 2.3. Unlock ....................................4 2.3.1. Unlock by RFID Cards ..............................4 2.3.2. Unlock by DTMF Codes ..............................4 FREUND ELEKTRONIKA d.o.o International Burch University | Francuske revolucije bb | 71210 Ilidza | Bosnia and Herzegovina www.ip-integra.ba info@ip-integra.com...
- Page 3 1.1. Product Description Freund FE-IPDS-26B is a SIP-compliant, hands-free, five buttons door phone. It can be connected with Freund indoor monitors for remote unlock control and monitor. Users can operate the indoor phone to communicate with visitors via voice and video. Users can Figure 1.1 Product Description...
- Page 4 DOOR A/B: Trigger signal input terminal. Relay A/B (NO/NC/COM): Relay control terminal. Note: The general door phone interface diagram is only for reference. 1.3. LED Status Information LED Status Description Figure 1.2-2 General interface Blue Always on Normal status Flashing Calling Flashing Network is unavailable...
- Page 5 IP address and if LED turns green, it means the call has been answered. 2.2. Receiving a Call User can use IP phone or indoor monitor to call FE-IPDS-26B and FE-IPDS-26B will answer it automatically by default. If user disable auto answer, pressing button to answer incoming call.
- Page 6 Place the predefined user cards in RFID card reader to unlock. Under normal conditions, FE-IPDS-26B will announce “The door is now opened.” 13.56 MHz RF card is supported on FE-IPDS-26B. 2.3.2. Unlock by DTMF Codes Users can press the predefined DTMF code from an answer unit to remotely unlock the door during the call.
