Vizio M160MV Quick Start Manual

M160MV
LED LCD HDTV

BEFORE YOU BEGIN

1
What's In the Box
• VIZIO HDTV
• VIZIO Remote Control
(including 2 AAA batteries)
• User Manual
(read Safety Guidelines)
• Registration Card
• Quickstart Guide
• AC/DC Power Adapter
• Screen Cleaning Cloth

INSTALLING YOUR HDTV

2
We provide professional installation services. Visit www.VIZIO.com or
call (888) 849.4623 to order today!
Attaching the Stand Base to the TV
1. Place the TV face down on a soft, flat surface.
2. Line up the stand base with the stand neck
(attached to the TV) and carefully push the base
onto the neck.
3. On the bottom of the stand base, turn the
thumbscrew and tighten snugly (see Fig. 1).
4. Move the TV into an upright position and place so that the rear connectors
remain accessible.
Preparing the TV for Wall Mounting - please refer to "Wall mounting
your HDTV" in your User Manual for more information.
MATCH YOUR VIZIO TO A CERTIFIED* WALL MOUNT
ULTRA SLIM ULTRA SLIM
FLUSH MOUNT TILT MOUNT
XMF1300 XMT1200 / XMT500
*Tested and certified by VIZIO engineers for compatibility with your TV.
©2010 VIZIO Inc. 50650A166400R(A)XXX

CONNECTING TO DEVICES

3
YOU DESERVE
THE BEST!
CONNECTION
ADVICE
PICTURE QUALITY
CONNECTION TYPE
CONNECTOR IMAGE
MAKE THE BEST
HIGH DEFINITION
FIG. 1
CONNECTION!

POWER THE TV

Full Articulating 4
Mount
Just lightly touch the Power button on your HDTV
to turn in on, or press the Power button on the
remote control.
XMA1200 / XMA500
The touch-sensitive TV controls will then light up when your
hand approaches the TV.
The inputs listed in the BEST column are
and Audio. Connect using these inputs wherever possible.
BEST BETTER
HIGHEST DIGITAL
ANALOG HD
QUALITY PICTURE QUALITY PICTURE
HDMI DTV/TV
COMPONENT
VIZIO HIGH DEFINITION CABLES
For more information about VIZIO Certified* High Definition
cables please visit us at: www.VIZIO.com
RGB PC
HDMI
AUDIO
DTV/ATV
COMPONENT AV
USB Y Pb Pr V L R
BACK OF TV
HDTV TIPS
OPTIMIZED for High Definition Video
Make sure you have components with HDMI
outputs to ensure the BEST possible picture.
GOOD
LOW RESOLUTION
NOT RECOMMENDED
3 WAYS TO WATCH
HIGH DEFINITION VIDEO
AV/S-VIDEO
1. Get a VIZIO Blu-ray
2. Contact your cable company or satellite
provider to learn more about HD
programming in your local area (an HD
cable box or satellite receiver may
be required).
3. You may be able to get HD signals using
an off-air antenna. To see if you can
receive off-air HD signals, and for help
choosing the right antenna, visit
www.antennaweb.org
HIGH DEFINITION
HOME THEATER
VIZIO Blu-ray
Bring your movies to life! 1080p Full HD playback
delivers crystal clear images with lifelike detail and High
Definition Audio puts you in the center of the action. Visit
www.VIZIO.com
HIGH-DEFINITION SOUND
Complete your total Home Theatre experience with stunning
audio from VIZIO accessories such as the Sound Bar
with Wireless Subwoofer.
Visit www.VIZIO.com or call (888) 849.4623.
SATELLITE / CABLE GAMING CONSOLE BLU-RAY / DVD
™
™ Disc Player.
™
for more details.
