Marquee SEAFORD 0108619 Assembly Instructions

SEAFORD 7PCE
STEEL DINING SETTING
Item No. 0108619
Part No. Description
Seat
A
B Leg
Short connection
C
bar
Long connection
D
bar
E
Medium bolt
Please ensure you have all the components above before you begin assembly.
Note:
1. Please kindly check the spare parts are included
before assembly.
2. Please do not tighten the screws before assembly
is completed.
Step 1
Unscrew the plastic plugs from the
base of the seat (Part A).
# A
Step 3
Secure the long connection bar (part D)
to the rear of the seat, using washer
(part G) and long bolt (part H). Then
insert the medium bolt (part E) into the
chair with washer (part G).
#H
#E
#G
#G
#D
#E
#G
#B
ASSEMBLY INSTRUCTIONS
Quantity
Pictures
M6*45
Secure the short connection bar (part C),
to the chair legs (Part B), with washer
(Part G) and short bolt (part F). Ensure the
legs are facing the correct way
(refer to images on the right).
#
A
After all components are in position,
tighten securely using Allen Key
(Part I) and cover with nut cap
(part J).
#H
#G
#A

Parts List

Part No. Description
F
Short bolt
1
G
2
Washer
H
1
Long bolt
1 I Allen Key
Nut cap
J
2
WARNING:
Not for children under 3 yrs.
CAUTION! Functional sharp points and edges. Use with care.
To be used under the direct supervision of an adult.
Step 2
#F
#F
#G
#G
#C
#B
Step 4
# J
#
I
Quantity
Pictures
M6*15
M6*48
Wrong assembly
Correct assembly
Please ensure the front
legs are outward-inclined
before assembling legs on
the seat.
Step 5
Your chair is now ready for use.
2
6
2
1
6
