Summary of Contents for Vivotek IP7151

  • Page 2 Product name: Network Camera (IP7151 / IP7152) Release Date: 2007/09/20 Manual Revision: Web site: www.vivotek.com Email: technical@vivotek.com sales@vivotek.com Made in Taiwan. ©Copyright 2000-2007. All rights reserved - 1 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 3: Before You Use This Product

    For paragraphs preceded by completely the warnings. Ignoring the warnings may result in serious hazards or injuries. This also ensures the product is used properly as the reader should use caution to understand - 2 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 4: Table Of Contents

    Software revision upgrade ... 25 Definitions in Configuration ... 26 System parameters ... 27 Security settings ... 28 Network settings... 30 Network type ... 30 HTTP ... 31 FTP ... 31 RTSP Streaming ... 31 - 3 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 5 Style convention... 65 General CGI URL syntax and parameters ... 66 Security level ... 66 Get server parameter values ... 67 Set server parameter values ... 68 Available parameters on the server ... 70 - 4 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 6 Query status of the digital output ... 95 Capture single snapshot ... 96 Account management ... 97 System logs... 98 Upgrade firmware ... 99 IP filtering ... 99 RTSP SDP ... 100 D. Technical specifications ... 102 - 5 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 7: Package Contents

    Package Contents IP7151/IP7152 Power adapter Camera stand Antenna (IP7152 only) Software CD Lens Quick installation guide Warranty card - 6 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 8: Installation

    Category 5 and not exceed 100 meters in length. Connect the power adapter jack to the Network Camera before plugging in to the power socket. This will reduce the risk of accidental electric shock. - 7 - Depending on the www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 9: Software Installation

    Cameras with the serial number. The serial number is printed on the labels on the carton and the back of the Network Camera body. Please refer to the user’s manual of Installation Wizard 2 for details. - 8 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 10: Initial Access To The Network Camera

    Once the password is set, there is no provision to recover the Administrator’s password. The only option is to restore to the original factory default settings. - 9 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 11: How To Use

    The user may check the option box to save the password for future convenience. This option is not available to the Administrator for obvious reason. Installing plug-in For the initial access to the Network Camera in Windows, the web browser may prompt - 10 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 12 If the web browser does not allow the user to continue to install, check the Internet security option and lower the security levels or contact your IT or networking supervisor for help. - 11 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 13: Primary User's Capability

    Camera View: What the camera sees. Click on the configuration link to the left of the image window to enter the configuration page. Here is the layout in IE when it is MPEG-4 streaming. - 12 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 14 The function in JPEG will be a little different when it is JPEG streaming. Only digital zoom and record button are supported. - 13 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 15 Here is the layout in Firefox when it is MPEG-4 streaming. It uses QuickTime to streaming. - 14 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 16 Here is the layout in Firefox when it is JPEG streaming. - 15 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 17: Digital Zoom

    Uncheck “Disable digital zoom” and use the slider control to change the zoom factors. MP4 Recording Click on the red circle button on the plug-in to start video recording in MP4 file format. You can set the related options in client setting page. - 16 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 18: Snapshot

    Users can point at the snapshot and click the right button of mouse to save it. Language Click on the language, all supported languages are shown in the drop-down list. The user can choose the different display language. - 17 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 19: Client Settings

    There are four protocols choices to optimize your usage – UDP unicast, UDP multicast, TCP and HTTP. The UDP unicast protocol allows for more real-time audio and video streams. However, - 18 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 20 UDP protocol, save, and return HOME to re-connect. The fourth one is “Save Options”. User can specify the recording folder, file name prefix and suffix here. - 19 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 21: Digital Output

    Click on “ON”, the digital output of the Network Camera will be triggered. Or, clicking on “OFF” can let the digital output turn into normal state. Administrator’s capability Fine-tuning for Best Performance Best performance generally equates to the fastest image refresh rate with the best - 20 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 22 Most 3GPP cell phone supports media streaming with MPEG4 video and GSM-AMR audio. Due to the limitation of the bandwidth for 3GPP, only 176x144 video solution will be supported for cell phone viewing. Please set related video settings first as - 21 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 23: Only Quality Images Will Do

    Start from 30 fps down for best results but not below 15 fps. If the image qualities are not improved, select a lower bandwidth setting. - 22 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 24: Opening Accounts For New Users

    This password is used to identify the administrator. Then add an account with user name, password and authentication for your friends in ○ from ○ . You can edit or delete users - 23 - to enable protection. www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 25: Build A Security Application

    Select the Trigger on Motion detection and Check the window name set in step Set the appropriate delay time to avoid continuous false alarms following the original event - 24 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 26: Software Revision Upgrade

    13. Click on save to validate. Software revision upgrade Customers can obtain the up-to-date software from the web site of Vivotek. An easy-to-use Upgrade Wizard is provided to upgrade the Network Camera with just a few clicks. The upgrade function is opened to the Administrator only. To upgrade the system, follow the procedures below.

  • Page 27: Definitions In Configuration

    If the Administrator also wants to set certain options through the URL, read the reference appendix for details. <url> http://<Network Camera>/setup/system.html <Network Camera> is the domain name or original IP address of the Network Camera. - 26 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 28: System Parameters

    “Digital output” Select Grounded or Open to define normal status of the digital output. The current status is shown, too. Remember to click on to immediately validate the changes. Otherwise, the correct time will not be synchronized. - 27 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 29: Security Settings

    “Manage user” Pull down the user list to find the user’s name and press delete the selected user. Or edit the password or authentication of the selected user and press to take effect. - 28 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 30 <url> http://<Network Camera>/setup/security.html <Network Camera> is the domain name or original IP address of the Network Camera. - 29 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 31: Network Settings

    “Primary WINS server” The primary WINS server that maintains the database of computer name and IP address. “Secondary WINS server” The secondary WINS server that maintains the database of computer name and IP address. - 30 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 32: Http

    “Access name for stream 1” This is the access URL of stream 1 for making connection from client software when the codec type is MPEG-4. “Access name for stream 2” This is the access URL of stream 2 for making - 31 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 33 “Multicast RTCP audio port” The audio channel port for multicast RTCP. It must be the port number of multicast audio port plus 1. “Multicast TTL” It specifies the number of routers (hops) that multicast traffic is permitted to pass through before expiring on the network. - 32 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 34 <url> http://<Network Camera>/setup/network.html <Network Camera> is the domain name or original IP address of the Network Camera. - 33 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 35: Wlan Settings (Ip7152 Only)

    “Key length” The administrator can select the key length among 64 or 128 bits. 64bits is the default setting. “Key format” Hexadecimal or ASCII. “HEX” is the default setting. “HEX” digits consist of the numbers 0~9 and the letters A-F. - 34 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 36 Some invalid settings may cause the system failing to respond. Change the Configuration only if necessary and consult with your network supervisor or experienced users for correct settings. Once the system has lost contact, refer to Appendix A for reset and restore procedures. - 35 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 37: Ddns

    “Save” Click on this button to save current settings for the DDNS service and UPnP function. <url> http://<Network Camera>/setup/ddns.html <Network Camera> is the domain name or original IP address of the Network Camera. - 36 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 38: Access List

    Delete button. Both the Allowed List and Denied List can have 10 entries. <url> http://<Network Camera>/setup/accesslist.html <Network Camera> is the domain name or original IP address of the Network Camera. - 37 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 39: Audio And Video

    “Intra frame period” The interval of intra frame. “Maximum frame rate” This limits the maximal refresh frame rate, which can be combined with the “Video quality” to optimize bandwidth utilization and video quality. - 38 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 40: Audio Settings

    “Internal microphone input gain” Modify the gain of the internal audio input “External microphone input” There are two gain options, 0dB and 20dB. “Audio type” Select audio codec “AAC” or “GSM-AMR” and the bit rate - 39 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 41 <url> http://<Network Camera>/setup/audiovideo.htm <Network Camera> is the domain name or original IP address of the Network Camera. - 40 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 42: Image Settings

    The user may press O.K; press to set the image settings. settings without incorporating the changes. to fine-tune the image. When the image is Click on this to recall the original - 41 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 43: Privacy Mask

    You can see the X, Y, width and height of the window. Click on this button to save the related window settings. "Window Name" The text will show at the top of the window. - 42 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 44 The following figure shows the screen when is clicked and the privacy mask is enabled. - 43 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 45: Ccd Settings

    “IR cut filter” - When set to “Night mode”, the camera will be able to “see” infrared light, it increases light sensitivity. Set to “Auto” to automatically turn the filter off when the available visible light falls below the minimum requirement. In “Schedule mode”, - 44 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 46: Motion Detection

    “Percentage” This sets the space ratio of moving objects in the monitoring window. Higher sensitivity and small percentage will allow easier motion detection. to fine-tune the image. When the image is O.K; press Click on this to recall the original settings - 45 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 47 <url> http://<Network Camera>/setup/motion.htm - 46 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 48: Camera Control

    Please refer to the section “Main Screen with Camera View” for the layout in IE when pan, tilt, zoom, and focus functions are enabled. When selecting `Disable’, the camera PTZ control Functions will not appear - 47 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 49 The figure below is the layout when “PTZ camera” is checked. Users can configure the camera driver and RS485 port settings. - 48 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 50 Note that the Network Camera can support multiple protocols to PTZ cameras. If there are PTZ camera functions can’t work, please see your PTZ camera’s user manual to check if your camera supports these functions. - 49 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 51: Preset Position

    Newly added preset position will appear in this list. User can manage this list through adding and deleting - 50 - Pan and Tilt Zoom Focus functions www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 52: Custom Command

    Please note that if “Custom camera” is selected as PTZ driver, user must configure the custom pan, tilt, zoom, and focus functions via “Custom Command” page. 1. Select Custom camera 2. Left click on “Custom Command” - 51 - 3. Configure the PTZF functions www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 53: Application

    If using the same media in different events and the events trigger almost simultaneously, the servers in the second triggered event will not receive any media; there would be only notifications. - 52 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 54: Event

    “Periodic” The event is triggered in specified intervals. The unit of trigger interval is minute. “Digital input” To monitor digital input “System boot” The event is triggered when the system bootup. The weekly and time schedules are provided. - 53 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 55: Server

    “Server name” Check it to sending the selected media when event is triggered. Server “Server name” The unique name for server There are four kinds of servers supported. They are email server, FTP server, HTTP server and network storage. - 54 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 56 “Password” This granted password on the network storage. After input the setting of server, user can click on to test whether the setting is correct. The testing result will be shown in a pop-up window. - 55 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 57: Media

    “File name prefix” The prefix name will be added on the file name of the snapshot images. “Add date and time suffix to file name” Check it to add timing information as file - 56 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 58: Recording

    “Maximum file size” The maximal file size would be generated. “File name prefix” The prefix name will be added on the file name of the video clip. Recording The Network camera supports recording on network storage. The operation of editing - 57 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 59 “Time” shows “Always” or input the time interval. “Destination” Network storage server user added. “Total cycle recording size” The total size for cycle recording in Kbytes “Size of each file for recording” The single file size in Kbytes - 58 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 60: System Log

    RFC 3164. If you have external Linux server with syslogd service, use “-r” option to turn on the facility for receiving log from remote machine. Or you can use some software on Windows which is compliant to RFC 3164. - 59 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 61: Viewing System Parameters

    <Network Camera> is the domain name or original IP address of the Network Camera. Viewing system parameters Click on this link on the configuration page to view the entire system’s parameter set. - 60 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 62 <url> http://<Network Camera>/setup/parafile.htm <Network Camera> is the domain name or original IP address of the Network Camera. - 61 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 63: Maintenance

    Any changes made so far will be lost and the system will be reset to the initial factory settings. The system will restart and require the installer program to set up the network again. “Upgrade firmware” Select the firmware file and click upgrade button - 62 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 64 <url> http://<Network Camera>/setup/maintain.htm <Network Camera> is the domain name or original IP address of the Network Camera. - 63 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 65: Appendix

    Blinking green every other second and steady red Blink green / orange every second and fast blink red Restoring the factory defaults will erase any previous settings. Reset or restore the system after power on. - 64 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 66: Url Commands Of The Network Camera

    192.168.0.220. Special note will be marked as words to take care. Syntax: http://<servername>/cgi-bin/viewer/video.jpg Description of returned data is written with "Return:" in bold face followed by the - 65 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 67: General Cgi Url Syntax And Parameters

    1 [view] anonymous, viewer, dido, camctrl 4 [operator] anonymous, viewer, Operator’s access right can modify most of DESCRIPTION Unprotected. 1. Can view, listen, talk to camera 2. Can control dido, ptz of camera - 66 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 68: Get Server Parameter Values

    Successful control request returns paramter pairs as follows. Return: camctrl, camera’s parameters except some privilege and network options Administrator’s access right can fully control the camctrl, camera’s operation. Internal parameters. Unable to be changed by any external interface. - 67 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 69: Set Server Parameter Values

    Response: HTTP/1.0 200 OK\r\n Content-Type: text/html\r\n Context-Length: 33\r\n \r\n network.ipaddress=192.168.0.123\r\n Set server parameter values Note: The access right depends on the URL directory. Method: GET/POST Syntax: http://<servername>/cgi-bin/anonymous/setparam.cgi? <parameter>=<value> [&<parameter>=<value>…][&update=<value>][&return=<return page>] http://<servername>/cgi-bin/viewer/setparam.cgi? <parameter>=<value> - 68 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 70 If you omit this parameter, it will redirect to an empty page. (note: The return page can be a general HTML file(.htm, .html) or a Vivotek server script executable (.vspx) file. It can not be a CGI command. It can not have any extra parameters. This parameter must be...

  • Page 71: Available Parameters On The Server

    A boolean value 1 or 0 represents [Yes or No], [True or False], [Enable or Disable]. <value1>, Enumeration. Only given values are valid. – 1) and (2 – 1) - 70 - – 1) www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 72 Set to ‘auto’ to use NTP to synchronize time. NTP server Indicate timezone and area -480: Kwajalein -440: Island, Samoa -400: GMT-10:00 Hawaii -360: GMT-09:00 Alaska -320: GMT-08:00 Las Vegas, - 71 - GMT-12:00 Eniwetok, GMT-11:00 Midway www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 73 -40: GMT-01:00 Azores, Cape_Verde_IS. 0: GMT Casablanca, Greenwich Mean Time:Dublin, Edinburgh, Lisbon, London 40: GMT 01:00 Amsterdam, Berlin, Rome, Stockholm, Vienna, Madrid, Paris 01:00 Warsaw, Budapest, Bern 02:00 Athens, Helsinki, Istanbul, Riga - 72 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 74 Hanoi, Jakarta, Krasnoyarsk 320: Chongging, Hong Kong, Kuala Lumpur, Singapore, Taipei 360: Sapporo, Tokyo, Seoul, Yakutsk 380: Darwin - 73 - 03:00 Baghdad, 05:30 Calcutta, 06:00 Almaty, 07:00 Bangkok, 08:00 Beijing, 09:00 Osaka, 09:30 Adelaide, www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 75 SECURITY DESCRIPTION (get/set) model name of server characters without hyphen connected - 74 - 10:00 Brisbane, 11:00 Magadan, 12:00 Aucklan, Fiji, Kamchatka, otherwise, server after value except subnet, router, dns2, ddns settings). server after address www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 76 SECURITY DESCRIPTION (get/set) indicate whether open circuit or closed circuit represents inactive status SECURITY DESCRIPTION (get/set) indicate whether open circuit or closed circuit - 75 - firmware, RTSP connection HTTP push server represents www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 77 0 => use preset ipaddress, subnet, rounter, dns1, and dns2 IP address of server subnet mask default gateway primary DNS server secondary DNS server primary WINS server secondary WINS server - 76 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 78 1 Http server push access name for stream 2 SECURITY DESCRIPTION (get/set) RTSP port RTSP authentication mode RTSP access name for stream1 RTSP access name for stream2 SECURITY DESCRIPTION (get/set) - 77 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 79 PPPoE account password SECURITY DESCRIPTION (get/set) Allowed starting IP address for RTSP connection Allowed ending IP address for RTSP connection Denied starting IP address for RTSP connection Denied ending IP address for RTSP connection - 78 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 80 Bit 2 operation. 1(support) Bit 3 operation. 1(support) Bit 4 operation. - 79 - => Support camera function 0(not => Build-in => Support 0(not support), => Support tilt 0(not support), => Support zoom 0(not support), www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 81 “ratecontrolmode”. 1 is worst quality and 5 is the best quality. set bit rate in bps when choose cbr in “ratecontrolmode” - 80 - => Support focus 0(not support), www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 82 => use line input, i.e. internal microphone Enable audio mute Gain of input Enable microphone boost set audio codec type for input set AAC4 bitrate in bps set AMR bitrate in bps www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 83 1~3 Left position. position. Width window. Height of motion detection window. Percent of motion detection window. Sensitivity of motion detection - 82 - contrast image coordinate window coordinate window motion detection www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 84 Your password or key to login ddns service provider The server name for safe100. (This field provider is customsafe100) SECURITY DESCRIPTION (get/set) Enable or disable the UPNP - 83 - => only exists www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 85 Server port used for log The levels to distinguish the importance of information. 0: LOG_EMERG 1: LOG_ALERT 2: LOG_CRIT 3: LOG_ERR 4: LOG_WARNING 5: LOG_NOTICE 6: LOG_INFO 7: LOG_DEBUG SECURITY DESCRIPTION - 84 - UpnP port www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 86 Width of privacy mask window Height of privacy mask window DESCRIPTION The HTTP API version. The server bootup time number of IR interface number of digital input number of digital output number of audio input number of audio output www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 87 T: 886-2-82455282 F: 886-2-82455532...
  • Page 88 T: 886-2-82455282 F: 886-2-82455532...
  • Page 89 Indicate whether to support the wireless 802.11b+ Indicate whether to support the wireless 802.11g Indicate whether to support the wireless WEP Indicate whether to support the wireless WPA Indicate whether to support the wireless WPA2 www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 90 For example, to detect the 1 windows, set mdwin as 5. Interval of period snapshot in minute. This field condition is “seq”. - 89 - video motion motion detection window. and 3 used when trigger www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 91 The identification of this entry Indicate the server type. “email” is email server. “ftp” is ftp server. “http” is http server. “ns” is network storage. The url of http server to upload. - 90 - digital output www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 92 The username to login in the server. The password of the user. The workgroup for network storage. SECURITY DESCRIPTION (get/set) The identification of this entry The media type to send to the server or store by the server. - 91 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 93 SECURITY DESCRIPTION (get/set) The identification of this entry To enable or disable this recoding. Indicate the priority of this recoding. “0” indicates low priority. “1” indicates normal priority. “2” indicates high priority. - 92 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 94: Drive The Digital Output

    Begin time of weekly schedule. End time of weekly schedule. (00:00~24:00 means always.) Indicate the prefix of the filename. The maximum size for cycle recording in Kbytes. The max size for one file in Kbytes - 93 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 95: Query Status Of The Digital Input

    The <return page> can be a full URL path or relative path according the the current path. If you omit this parameter, it will redirect to an empty page. - 94 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 96: Query Status Of The Digital Output

    Note: This request requires the privilege of viewer. Method: GET/POST Syntax: http://<servername>/cgi-bin/dido/getdo.cgi?[do0][&do1][&do2][&do3] If no parameter is specified, all the status of digital output will be returned. Return: HTTP/1.0 200 OK\r\n Content-Type: text/plain\r\n Content-Length: <length>\r\n \r\n [do0=<state>]\r\n [do1=<state>]\r\n [do2=<state>]\r\n - 95 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 97: Capture Single Snapshot

    Server will return the most up-to-date snapshot of selected channel and stream in DEFAULT DESCRIPTION the channel number of video source The resolution of image The quality of image - 96 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 98: Account Management

    Modify the account password and privilege. When using this method, “username” field is necessary, and other fields are optional. If not specified, it will keep original settings. The name of user to add, delete or edit - 97 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 99: System Logs

    The <return page> can be a full URL path or relative path according the the current path. If you omit this parameter, it will redirect to an empty page. - 98 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 100: Upgrade Firmware

    Add a set of allow IP address range to server. Start and end parameters must be specified. If the index parameter is specified, it will try to add starting from index position. - 99 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 101: Rtsp Sdp

    The <return page> can be a full URL path or relative path according the the current path. If you omit this parameter, it will redirect to an empty page. - 100 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...
  • Page 102 “n” is the channel number and “m” is the stream number. You can get the SDP by HTTP or just describe by RTSP protocol directly. For detailed streaming protocol, please refer to “control signaling” and “data format” documents. - 101 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 103: Technical Specifications

    Bi-color LED system status indicator Dimension (including lens) 205.5mm(D) x 82.1mm (W) x 51.2mm(H) Weight (including lens) Net: 568g (IP7151) Net: 581g (IP7152) Operating Environments Temperature: 0 ° ~ 40 ° C ( 32 ° ~ 104 ° F) Humidity: 20 % ~ 80 % RH...
  • Page 104 Event notification using HTTP, SMTP, or FTP Local recording of MP4 file Viewing System Requirements OS: Microsoft Windows 2000/XP Browser: Internet Explorer 5.x or above Cellphone: 3GPP player Real Player 10.5 Quick Time 6.5 Packet Video Player 3.0 - 103 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 105: Technology License Notice

    GB PAT. 819303; IT PAT. 819303; JP PAT. APP. 8-529817; NL PAT. 819303; SE PAT. 819303; US PAT. 5664053. THE LIST MAY BE UPDATED FROM TIME TO TIME BY LICENSORS AND A CURRENT VERSION WHICH AVAILABLE LICENSOR’S WEBSITE HTTP://WWW.VOICEAGE.COM. - 104 - www.vivotek.com T: 886-2-82455282 F: 886-2-82455532...

  • Page 106: Electromagnetic Compatibility (Emc)

    Vivotek Inc. makes no warranty of any kind with regard to the material contained within this document, including, but not limited to, the implied warranties of...

This manual is also suitable for:
