5. MKIV/Pro installation manual
5 - 3. Speaker Installation for MKIV
Pro series does not include speakers
HINT!
1) Attach the hanger to the bottom.
2) Connect the speaker cord to the INPUT LINE2 phone jack.
Hang the Monitor Speaker to the bracket.
Screw the thumbscrews to secure the Monitor Speaker.
3) Wiring theSpeaker
MHB23 MKIV/PRO DIOV1.05, SCV.1.01 PAGE.07
