Wall-Mount Power Vector Amplifiers
WV100, WV150, & WV250 Models
Installation and Use Manual
© 2002 Bogen Communications, Inc.
All rights reserved.
Specifications subject to change without notice.
54-2086-01B 0304 Printed in Korea.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the & WV250 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bogen & WV250

Summary of Contents for Bogen & WV250

  • Page 1 Wall-Mount Power Vector Amplifiers WV100, WV150, & WV250 Models Installation and Use Manual © 2002 Bogen Communications, Inc. All rights reserved. Specifications subject to change without notice. 54-2086-01B 0304 Printed in Korea.

  • Page 2: Important Safety Information

    Every effort was made to ensure that the information in this guide was complete and accurate at the time of printing. However, information is subject to change. Important Safety Information WARNING: To Reduce The Risk of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture.

  • Page 3: Table Of Contents

    Contents PANEL DESCRIPTIONS...2-3 Wall-Mount Power Vector Front Panel ...2 Wall-Mount Power Vector Module Bay (Rear) ...3 Wall-Mount Power Vector Connector Board (Rear)...3 INSTALLATION ...4 Package Contents ...4 Mounting ...4 Front Panel Input Connector...4 MODULES ...5 Module Installation ...5 Output Modules ...5 Functionality ...5 Input Modules ...5 Functionality ...5...

  • Page 4: Panel Descriptions

    Panel Descriptions Wall-Mount Power Vector Front Panel PUSH 1. Input Volume Control Each of the 8 module bays are controlled by an independent volume control. 2. Signal / Clip Indicator A single two-color LED located above each channel’s volume control indicates the audio activity of that chan- nel’s input.

  • Page 5: Wall-Mount Power Vector Module Bay (Rear)

    Wall-Mount Power Vector Module Bay (Rear) 1. Module Bays The amplifier has eight module bays, all of which can accommodate input modules, with two bays (bays 7 and 8) that can accommodate either input or output modules. 2. Low-Cut Switch Slide switch (located in module bay 6) allows roll off of frequencies below 125 Hz.

  • Page 6: Installation

    Installation Package Contents • Amplifier • Instruction Manual • 2 Screws (M 3 x 8) Mounting A surface-mount (model BBS) or flush-mount (model BBF shown below) back box as well as a WMAD door is required for installation. Refer to the instructions provided with these items for proper installation. (See Components on page 13.) Front Panel Input Connector If desired, a front panel mounted combination female XLR and 1/4"...

  • Page 7: Modules

    Module Installation Eight module bays are available to accept Bogen’s new advanced plug-in input modules. Module bays 7 & 8 can also accommodate Bogen’s new advanced plug-in output modules, thereby allowing users to customize the amplifier to suit the needs of the installation.

  • Page 8: Connections

    Connections Speakers Transformer-Coupled Speaker Connections Transformer-coupled, constant voltage speaker loads are connected to their respective load type (i.e., 70V speakers to the 70V terminal, 25V speaker systems to the 25V terminals) and the COM terminal. Make sure the selector switch is in the TRANS OUT position. A separate 8-ohm ter- minal is provided to drive 8-ohm (low-impedance) speakers through an output transformer tap.

  • Page 9: Com And Gnd Terminals

    Master Volume control. The impedance of the shorting connections must be less than 100 ohms in order to operate the control. The Bogen Remote Volume Control Panel (model RVCP) provides a simple and elegant means of remote control.

  • Page 10: Operation

    Operation Front Panel Controls & Indicators Input Volume Controls Each input module may be individually controlled by its corresponding volume control knob. Signal / Clip Indicator A single LED located above each channel’s volume control indicates the audio activity of that channel’s input. Green indicates signal is being applied to the mix bus.

  • Page 11: Output Limiter

    Output Limiter The Output Limiter control sets the threshold at which the unit hard limits the output signal. Once the Limiter's threshold is exceeded, the output signal is prevented from increasing any further.With the control set to the Min position (fully counterclockwise), the Limiter will pro- vide almost no limiting and is essentially turned off.

  • Page 12: Block Diagram

    Block Diagram...

  • Page 13: Specifications

    Power Output (RMS): WV100: WV150: WV250: Frequency Response Transformer: 45-20 kHz; 0/-2 dB @ FRP Direct: 20-20 kHz; 0/-1 dB @ FRP Distortion Transformer: 0.5% THD+N, Maximum, Full-rated bandwidth @ FRP Direct: 0.1% THD+N, Maximum, Full-rated bandwidth @ FRP Signal-to-Noise Fundamental: -94 dB* With Aux Module:...

  • Page 14: Troubleshooting

    Troubleshooting PROBLEM CONDITION Power Indicator LED is off. Power Indicator LED is red. Input Signal / Clip LED is off. NO SOUND Power Indicator LED is red. Input Signal / Clip LED is green. LED Output Meter is off. Power Indicator LED is red. Input Signal / Clip LED is green.

  • Page 15: Warranty

    Bogen believes may affect the reliability of the product, or where the serial number or date code has been removed or defaced.
  • Page 16 50 Spring Street, Ramsey, NJ 07446, U.S.A. Tel. 201-934-8500, Fax: 201-934-9832, www.bogen.com...
