Step-5: Display shows "LOCAL NUMBER DELETE" .
Press # key to delete the area code entered. Press * key for next menu.
Step-6: Display shows "QUIT PROGRAMMING" . Press # key to quit the programming. Press
* key to go back to first menu.
In normal mode, the LCD display shows VISIONTEK. On lifting the handset, display shows
"PLEASE DIAL" . Press ** and enter the password. Default password is 9876.
Step-1: On successful entry of password, LCD shows "CHECK SIGNAL QUALITY" . Press # key
to display the signal level in db. Press * key for next menu.
Step-2: Display shows "TOLL CODE ENTRY" . Press # key to enter Toll Free codes i.e. the codes
for which polarity reversal is not required. Provision is given for entering 20 numbers. Press
* key for next menu.
Step-3: Display shows "TOLL CODE REVIEW" . Press # key to review the Toll Free codes
entered. Press * key for next menu.
Step-4: Display shows "TOLL CODE DELETE" . Press # key to delete the Toll Free codes
entered. Press * key for next menu.
Step-5: Display shows "RESET CODE ENTRY" . Press # key for entering new codes. After entry,
Press # key for entering pulse rate. Fifteen codes and corresponding pulse rates can be
entered.
Step-6: Display shows "RESET CODE REVIEW" . Press # key to review codes and pulse rate
entered. Press key for next menu.
Step-7: Display shows "RESET CODE DELETE" . Press # key to delete the codes and pulse
rates entered. Press key for next menu.
Step-8: Display shows "QUIT PROGRAMMING" . Press # key to quit the programming. Press
key to go back to first menu.

PRECAUTIONS:

1. Do not remove or insert the SIM card when the unit is powered ON.
2. Do not bend or roll the ANTENNA cable.
3. Whenever Battery voltage is discharged to 10.8volts, on console display "Battery low
message" is displayed, for safe mode switch off the unit.

TECHNICAL SPECIFICATIONS :

Technology : Advanced microcontroller based.
Display : 16X1 Alphanumeric display

WARRANTY

VISIONTEK FCT 81GF is warranted for a period of 12 months from the date of sale against manufacturing
defects. Linkwell Telesystems Pvt. Limited, obligation under this warranty shall be limited to servicing or
replacing the defective parts provided that notice of such defects and satisfactory proof thereof is given to
Linkwell Telesystems Pvt. Limited.
The warranty does not cover any defect in the product caused by accident, misuse, mishandling,
negligence, alteration, modification or substitution of any of the components or parts or any attempt at
internal adjustments, any form of tampering by unauthorized/unskilled service personnel, loss of
components or accessories, natural calamities and over voltage of electricity.
Under no circumstance shall Linkwell Telesystems Pvt. Limited, be liable for any consequential or resulting
injury or for loss, damage or expenses directly or indirectly arising from the use of this product Linkwell
Telesystems Pvt. Limited will make every effort to carry out repairs/replacement under this warranty as
early as possible and it is expressly made clear that the company shall not be liable to do so within any
specified time or period.
The decision of Linkwell Telesystems Pvt. Limited as to the nature of the defect and applicability of this
warranty shall be final.
Claims if any, to this warranty shall be only made before the courts having jurisdiction in Secunderabad,
Andhra Pradesh.
Product Pictures
Wall Mount
Table Top
RS-232 Port
Linkwell Telesystems Pvt. Ltd.
Gowra Klassic,
1-11-252/1/A,
Begumpet, Hyderabad - 500 016. Andhra Pradesh, INDIA.
Ph. : +91-40-66388000 | Fax : +91-40-66388006, 27763838
BRANCHES: NOIDA - 0120-2549090, 2549095, 2541427, 2541437 | KOLKATTA - 033-22176549, 22169301 |
AHMEDABAD - 079-40062001, 40062002 | MUMBAI - 022-24916940, 24916942 | VIZAG - 0891-2550725,
2564752,2508088 | BANGALORE - 080-25598811, 25550729, 25591457 | CHENNAI - 044-24797950, 24797960
| KERALA - 94471-37717
4
www.visiontek.co.in
User's Manual
UM-0016 Rev.1.0
GSM Fixed Cellular Terminal 81GF
Congratulations !!!
We thank you for purchasing the VISIONTEK 81GF GSM Fixed Cellular
Terminal with Fax a single line simulation with GSM Network. This User's manual will help you in
knowing all the features of the system including installation. Operational and programming procedure
in a step by step manner. Please keep this handy manual for easy reference.
For Servicing and other details kindly look at the corporate address and email id at the backside of
the manual.
1
