Vision Fitness ST250 Assembly Manual

Leg press
Hide thumbs Also See for ST250:

Advertisement

Quick Links

Download this manual See also: Owner's Manual
A s s e m b l y
G u i d e
ST250
LEG PRESS

Advertisement

loading

Related Manuals for Vision Fitness ST250

Summary of Contents for Vision Fitness ST250

  • Page 1 A s s e m b l y G u i d e ST250 LEG PRESS...
  • Page 2 A s s e m b l y G u i d e ST250 LEG PRESS To avoid possible damage to this Leg Press, please follow these assembly steps in the correct order. Before proceeding, find your new Leg Press’ serial number located on the back of the base tube (1b), and enter here: Refer to this number when calling for service, and enter this serial number on your Warranty Card and in your own records.

  • Page 3: Table Of Contents

    STEP STEP STEP STEP STEP STEP STEP STEP...
  • Page 4 TOOLS & PARTS INCLUDED 10mm/17mm Wrench 19mm Wrench 4mm L-Shaped Wrench 6mm L-Shaped Wrench (2) PARTS BOX Color-coded Hardware Bags Owner’s Guide Assembly Guide Warranty Card...
  • Page 5 HARDWARE INCLUDED ORANGE BAG SW10.2 x 18.4 x 2.5T Spring Washer M10 x 1.5P x 100L Bolt Quantity: 8 Quantity: 4 M10 x 1.5P x 60L 10.5 x 18 x 2T M10 x 1.5P Nut Carriage Bolt Quantity: 12 Flat Washer Quantity: 2 Quantity: 16 BLUE BAG...
  • Page 6 PINK BAG 90mm Shaft Quantity: 1 GREEN BAG 10.5 x 18 x 2T M10 x 1.5P Nut Flat Washer Quantity: 2 Quantity: 2 SW6.1 x 12.2 x 1.5T M6 x 1P x 15L Bolt Spring Washer Quantity: 3 Quantity: 3 HARDWARE INCLUDED 165mm Shaft Quantity: 1...
  • Page 7 HARDWARE INCLUDED BLACK BAG 15x33L SW10.2 x 18.4 x 2.5T 10.5 x 18 x 2T M10 x 1.5P Nut Shoulder Bolt Spring Washer Flat Washer Quantity: 1 Quantity: 1 Quantity: 1 Quantity: 1 M12 Slotted Bolt Quantity: 1 U Bracket Quantity: 1...

  • Page 8: Step

    WEIGHT PLATES STEP • If you aren’t adding any weight plates to the stack, skip this step and proceed to Step 2. • Your unit is equipped to handle 21-ten pound plates (20 plates and the header plate). If you are adding plates to the stack after it has been in use, proceed as follows: Loosen the nuts, attached to the bolts (5g) with a...

  • Page 9: Step

    ORANGE BAG STEP • Attach the connecting brace (1a) to the empty holes on the left floor support of the base unit (ST200). Connect with two carriage bolts (M10x1.5Px60L), two flat (10.5x18x2T) & spring (SW10.2x18.4x2.5T) washers, and two nuts (M10x1.5P). Attach the opposite end of the connecting brace to the main floor support (1b) of the leg press.

  • Page 10: Step

    BLUE BAG STEP • Lay the seatback (2a) face down. Mate the seatback support (2b) to 2a. Make sure the holes of 2b are pointing up towards the top of the seatback. Securely fasten four bolts (M10x1.5Px30L) into the seatback using a 6mm L-shaped wrench.

  • Page 11: Step

    PINK BAG STEP • Insert the lever arm (3a) into the triangular structure at the front of 1b. When the holes are lined up, insert the 90mm shaft along with a flat (17x25x1.5T) washer through the lower end of 3a and fasten with a flat (10.5x30x2T) washer and a bolt (M10x1.5Px20L).

  • Page 12: Step

    CABLE #2 STEP • If you already have the base unit assembled with cable #2 and are adding the leg press to it, follow this instruction, otherwise proceed to Step 6: Unscrew the nuts and bolt that attaches cable #2 to the rear termination tube (6b of base unit), using a 19mm wrench.

  • Page 13: Step

    GREEN BAG STEP • Attach the pulley structure (U) to the bottom rear floor support of the base unit with three bolts (M6x1Px15L), three flat (6.4x14x1T), and three spring (SW6.1x12.2x1.5T) washers. Tighten with a 4mm L-shaped wrench. • Slide pulley structure (Q) through the back side of the rear vertical support (base unit) and fasten securely with two spring (SW10.2x18.4x2.5T)
  • Page 14 BLACK BAG STEP • Begin routing cable #6 with the end opposite the steel ball end. Feed the cable over pulley R, under S, around T, and under U. Unscrew the nut from the slotted bolt (M12). With the threads of the bolt facing up, slide cable #6 through it and reattach the nut.
  • Page 15 DECALS STEP • Attach the decals according to the diagram below. PINCH POINT SAFETY DECAL PLACEMENT...
  • Page 16 500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551 toll free 800.335.4348 • phone 920.648.4090 • fax 920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 10.05 AG18.38PRD REV2...
