FITNESS
VISION
E3100/3200
ASSEMBLY INSTRUCTIONS
To avoid possible damage to this Fitness Cycle,
please follow these assembly instructions.
Carefully remove all its parts from the box,
lay them out and review the parts list.
If any parts are missing, please call 1-800-335-4348, Ext 12
Before proceeding, find your Fitness Cycle's serial number,
located on the underside of main frame, and enter here:
______________________________
Refer to this number when calling for service.
I I T T
A A L L L L
S S T T A A R R T T S S
W W I I T T H H
A A
V V I I S S I I O O N N
Advertisement
Related Manuals for Vision Fitness Fitness Cycle E3100/3200
Summary of Contents for Vision Fitness Fitness Cycle E3100/3200
-
Page 1: Assembly Instructions
FITNESS VISION E3100/3200 ASSEMBLY INSTRUCTIONS To avoid possible damage to this Fitness Cycle, please follow these assembly instructions. Carefully remove all its parts from the box, lay them out and review the parts list. If any parts are missing, please call 1-800-335-4348, Ext 12 Before proceeding, find your Fitness Cycle’s serial number, located on the underside of main frame, and enter here: ______________________________... - Page 2 E3100/3200 Parts Diagram E3100 Console E3200/E3200HRC Console...
- Page 3 VISION FITNESS E3100/3200 Parts Description Part # Description Front Wheel Parts Front Foot Wheel Axle Front Transport Wheels #142 Inside Wheel Washers #141 Outside Wheel Washers #137 Wheel Fixing Bolts Rear Foot Parts Rear Foot Assembly Rear Foot Attachment Bolts...
- Page 4 E3100/3200 Assembly NOTE: During assembly, it is recommended that all bolt threads are greased to ensure proper tightening and prevent seizing due to corrosion. Step 1 • Front Wheel Assembly 1: Slide the Front Foot Axle (60) through the Front Foot Nylon Sleeves (59).
- Page 5 E3100/3200 Step 3 • Seat and Seat Post 1: Slide the Seat Post (65) through the Rubber Seat Post Cover (84) and into the frame Seat Post receiver tube. The Seat Post numbers should be facing the right or Seat Pin side of the Fitness Cycle. Be sure to liberally grease the threads on the Seat Clamp Bolt.
- Page 6 Console Mast. 2: Slide the Top Cap (82) over the bottom of the Console Mast (70). The VISION FITNESS decal on the Console Mast should be facing forward, away from the rider. 3: Locate the Console Cable (64) that is folded into the Frame. Attach the bottom end of the wire in the Console Mast to this Console Cable.
- Page 7 E3100/3200 Step 5 • Handlebars 1: Bolt the Handlebars (77) to the Console Mast (70) using the two 1 1/2” Allen Bolts (139) and Lock Washers (140). Step 6 • Pedals 1: Attach the left and right Pedal Straps (90) to the matching pedal (91). The Straps are marked L and R for Left and Right.
- Page 8 Final Assembly NOTE: Assembly Steps 7, 8 and 9 refer to Model E3100 only. For Models E3200/E3200HRC proceed to Step 10 for Console installation. Step 7 • Console 1: Insert Upper Magnet Shift Cable (102) into the top of the Console mast (70).
- Page 9 NOTE: Assembly Steps 10 and 11 refer to Models E3200/E3200HRC only. • • Step 10 Console - Models E3200/E3200HRC only 1: Plug the Console Cable (96) into the Console (93). NOTE: These connections are slotted and will only fit properly one way. DO NOT FORCE the connection. Make sure you DO NOT PINCH the Console Cable between the Console and the Console Mast.
- Page 10 2: You will get the best results if you wear the transmitter directly against your skin. Once these electrodes are moistened, center the transmitter just below the breast or pectoral muscles with the Vision Fitness logo centered on the chest and facing out. Adjust the length of the elastic belt so that the transmitter presses firmly against your skin, but not so tight as to be uncomfortable.
- Page 11 FITNESS VISION 621-D East Lake Street P.O. Box 280 Lake Mills, WI 53551 (920) 648-4090...
