- Page 1 V I S I O N F I T N E S S A s s e m b l y G u i d e M O D E L X 6 6 0 0 H R C E L L I P T I C A L T R A I N E R...
-
Page 2: Before You Begin
Before you begin… To avoid possible damage to this Elliptical Trainer, please follow these assembly steps in the correct order. Before proceeding though, enter your new Elliptical Trainer’s serial number here: Refer to this number when calling for service, and also enter this serial number on your Warranty Card and in your own records. Be sure to read your Owner’s Guide before using your new Elliptical Trainer. - Page 3 TOOLS & HARDWARE INCLUDED Allen Wrench Wrench L-Shaped Wrench Screwdriver ORANGE BAG L x 8 Quantity: 2 Allen Wrench BLUE BAG L x 8 D Bolt Quantity: 6 D Bolt NyLock Nut Quantity: 2...
- Page 4 ORANGE BAG STEP • Slide the rubber cover onto the console mast. • Unfold the console cable and attach it to the string located inside the console mast. Guide the wire up through the mast while simultaneously sliding the console mast onto the frame bracket.
- Page 5 BLUE BAG STEP • Mount the upper right handlebar to the frame and lower portion of handlebar using two of the bolts in the bag. RUBBER BOOT STEP • Install the rubber boot over the top of the lower left handlebar and slide to the bottom corner.
- Page 6 Do not pinch the cable! 621-D East Lake Street • P.O. Box 280 • Lake Mills. WI 53551 toll free 1.800.335.4348 • phone 1.920.648.4090 • fax 1.920.648.3373 www.visionfitness.com 1999 Vision Fitness. All Rights Reserved. 7.99 STEP STEP...
