Vision Fitness X6000 Assembly Manual

Vision fitness elliptical trainer assembly guide
Hide thumbs


Advertisement

SIMPLE
DELUXE
CONSOLES
CONSOLE
7
STEP
• Refer to Product Selection and Model Configuration decal on
console or follow these steps.
• Once the product is plugged in turn on the console
• Select product (Bike (BK) or Elliptical (EP)) using the resistance
arrow keys. Press ENTER to select.
• Select model number (Bike (1500, 2050, 2250, 3200) or
Elliptical (1500, 6000, 6200)) using the RESISTANCE arrow
keys. Press ENTER to select. Console will reset to start-up screen.
• The product selection and model configuration is now complete.
©2008 Vision Fitness. All Rights Reserved. May be covered by one or more patents or patents pending: US 5540637, US 5573480,
US 5813949, US 5813949, US 5924962, US 5938567, US 6135927, US 6149551, US 7316633, TW 364373, TW 371899, CN 99808486.7
PARTS BOX
Console Mast Boot
Dual-Action Link Arm Covers
Dual-Action Axle Covers
Rear Stabilizers
Pedal Arm Bracket Covers
Pedal Support Bracket
PREMIER
Water Bottle & Cage
Power Supply
Color-coded Hardware Bags
Assembly Guide
Warranty Card
500 South CP Avenue • P .O. Box 280 • Lake Mills, WI 53551
toll free 800.335.4348 • phone 920.648.4090 • fax 920.648.3373
www.visionfitness.com
AG18.19PRD
ASSEMBLY
9.08
REV9
X6000
ELLIPTICAL TRAINER

Advertisement

Table of Contents
loading

  Summary of Contents for Vision Fitness X6000

  • Page 1 800.335.4348 • phone 920.648.4090 • fax 920.648.3373 ©2008 Vision Fitness. All Rights Reserved. May be covered by one or more patents or patents pending: US 5540637, US 5573480, US 5813949, US 5813949, US 5924962, US 5938567, US 6135927, US 6149551, US 7316633, TW 364373, TW 371899, CN 99808486.7...
  • Page 2 TOOLS & PARTS INCLUDED Screwdriver 5mm T-Shaped Wrench 6mm L-Shaped Wrench 5mm L-Shaped Wrench YELLOW BAG GREEN BAG 8x17x1T Arc Washer M8x25L Bolt Quantity: 4 Quantity: 4 PINK BAG 20x29x1.5T Wavy Washer 8x15x2T Washer Quantity: 3 M8x60L Socket Head Bolt Quantity: 3 13mm/15mm Wrench Quantity: 2...
  • Page 3: Assembly

    A s s e m b l y G u i d e X6000 ELLIPTICAL TRAINER To avoid possible damage to this Elliptical Trainer, please follow these assembly steps in the correct order. Before proceeding, find your new Elliptical Trainer’s serial number located on the front axle tube, and enter...
