- Page 1 A s s e m b l y G u i d e R2650HRT COMMERCIAL FITNESS BIKE...
- Page 2 Bike to prevent loosening and noise. Also, during each assembly step, ensure that ALL screws are in place and partially threaded in before completely tightening any ONE screw. STEP STEP STEP STEP G u i d e R2650HRT COMMERCIAL FITNESS BIKE STEP STEP...
- Page 3 TOOLS & PARTS INCLUDED 15mm Pedal Wrench 5mm T-Shaped Wrench Screwdriver 4mm L-Shaped Wrench PARTS BOX Console Mast Cover Water Bottle Heart Rate Chest Strap Color-coded Hardware Bags Pedals/Straps Owner’s Guide Assembly Guide Warranty Card 5mm L-Shaped Wrench...
-
Page 4: Hardware Included
ORANGE BAG M8x65L Screw Quantity: 2 M8 x 20L Screw Quantity: 2 BLUE BAG M8 x 15L Screw M10 x 12L Set Screw Quantity: 6 PINK BAG M8 Lock Washer M8 x 15L Screw Quantity: 2 HARDWARE INCLUDED M8 x 20L Screw M8 Lock Washer Quantity: 4 Quantity: 1... - Page 5 STEP Rear Foot STEP STEP STEP Console Mast Console Mast Boot Frame Bracket ORANGE BAG • Install the rear foot with the four lock washers (M8), two inside screws (M8x65L), and two outside screws (M8x20L). Tighten with the 5mm T-Shaped wrench. BLUE BAG •...
- Page 6 PINK BAG STEP • Mount the upper handlebars to the console mast using two lock washers (M8) and two screws (M8x15L). Tighten with the 5mm T-Shaped wrench. • Remove the four mounting screws from the back of the console. Connect the wire harness and heart rate wires that come from the console mast into the plugs located in the back of the console.
- Page 7 GREEN BAG STEP • Remove the two socket head cap screws from the sliding seat adjustment bracket. Slide the seat adjustment handle between the teeth of the seat adjustment bracket. Re-insert the two socket head cap screws and tighten with the 4mm L-shaped wrench. •...
- Page 8 BLACK BAG STEP • Mount the seat bottom to the seat frame with four screws (M6x55L) and four lock washers (M6). Tighten with the 4mm L-shaped wrench. Seat Bottom STEP...
- Page 9 Pedal STEP 500 South CP Avenue • P.O. Box 280 • Lake Mills. WI 53551 toll free 1.800.335.4348 • phone 1.920.648.4090 • fax 1.920.648.3373 www.visionfitness.com ©2005 Vision Fitness. All Rights Reserved. 6.05 Part #Z26RB79-AG AG18.36PRD REV1 YELLOW BAG STEP • Attach the left and right pedals to the left and right crank arms.
