Specifications Summary; Hardware Introduction - Asus Xg Station Pro Quick Start Manual

2.

Specifications summary

Model
Connection to PC
Input / Output
RGB Lighting Control
Power Supply
Dimension
Weight
Graphics Card Support
Internal Graphics Slot
Specification
Graphics output
Accessories
3.

Hardware introduction

Rear view
4
XG Station PRO
Thunderbolt™ 3
1 x USB 3.1 Gen 2 port
ASUS ROG AURA supported
330W
109mm x 205mm x 375mm
3.6KG
NVIDIA GeForce GTX 900 series and later
® ®
AMD Radeon R9 series and later
Provides support for a single full length, 2.5 slot, PCI-Express
x16 graphics card
1 x PCI-Express x16 (electrical spec: x16)
Defined by the graphics card installed
1 x Thunderbolt™ 3 Type-C cable
1 x Power cord
1 x 330W Adapter
Important product information guides
Cover lock
Power button
Power (DC) input port
Thunderbolt™ 3 Type-C port
USB 3.1 Gen 2 Type-C™ port
