Summary of Contents for VIORE PLC10V49
-
Page 3: Table Of Contents
Safety Precautions - Power Supply - Installation - Use and Maintenance - Important Safety Instructions User Guidance Information - Accessories - Names of each part - Remote Control Connection - Power connection - Antenna connection - Input connections - Headphone connection Basic Use - Powering the LCD TV - Selecting input source... -
Page 4: Safety Precautions
Safety Precautions Power Supply Warnings Do not touch the power Do not use a damaged plug with wet hands. power cord or plug or a loose outlet. . Doing so may result in electric shock. . Doing so may result in fire or electric shock. -
Page 5: Installation
Safety Precautions Installation Warnings Do not place the unit where it Do not use or store flamm is exposed to rain, excessive able or combustible materials moisture or grease. near the unit. . Doing so may result in fire . Doing so may result in fire electric shock, malfunction, or explosion. -
Page 6: Use And Maintenance
Safety Precautions Use and Maintenance Warnings Disconnect the power Do not insert any metal objects, cord from the wall outlet such as a screwdriver, paper clip, or A/V terminals.. during an electric storm. . Not doing so may result . Doing so poses a serious in fire or electric shock. -
Page 7: Important Safety Instructions
Safety Precautions Important Safety Instructions Servicing is required when the apparatus has been damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, the apparatus does not operate normally, or the apparatus has been dropped. -
Page 8: Important Safety Instructions
Safety Precautions Important Safety Instructions Servicing is required when the apparatus has been damaged in any way. Your TV could require servicing if any of the following occur: • Supply cord or plug is damaged • Objects have fallen into the apparatus •... -
Page 9: User Guidance Information
User Guidance Information Accessories The following accessories are included in the package STANDBY STANDBY INPUT TV/AV MUTE MUTE DISPLAY DISPLAY LANG LANG AB/EPG SUBTITLE -/-- ANGLE ZOOM EXIT SLEEP VOL- VOL- VOL+ VOL+ LCD MENU TITLE MENU LCD MENU DVD SETUP MENU TEXT ZOOM... - Page 10 User Guidance Information Names of each part Disassembly of TV Base Wall-Hanging slots Standing the TV with Bracket...
-
Page 11: How To Use The Remote Control
User Guidance Information Remote Control Function of remote control buttons The remote control uses infra-Red(IR). Point it towards the front of the LCD TV. The remote control may not work correctly if it is operated out of range or out of angle. STANDBY TV/AV MUTE... -
Page 12: Connection
Power connection Power Connecting 1. Connect the small round plug on the power adapter cable to the power input socket at the rear of the set. 2. Connect the power adapter to the main supply. Note: This model has a built-in rechargeable Li-ion battery. You can enjoy watching TV for approximately 2 hours using battery power after a full charge. -
Page 13: Input Connections
Input Connections Composite Cable (Not included) Connection Cable (Included) * Connect the LCD TV’s AV IN/OUT terminal to the output/input terminals with a Composite Cable and an AV Connection Cable(supplied) as the picture shows. Watching Video Signal 1. Connecting the DC power supply, pushing the power switch “OFF/ON” up, and press “STANDBY”... -
Page 14: Basic Use
Powering the LCD TV To turn on the LCD TV. Connect the DC power supply. Push the switch up, and then press STANDBY on the LCD TV. To turn off the LCD TV. Press the STANDBY button on the LCD TV, and push the switch down. To turn on/off the LCD TV by remote control STANDBY Pressing... -
Page 15: Application
Operating the menu 1. Press STANDBY button to turn the LCD TV on. 2. Press LCD-MENU button on the remote control; the on-screen menu will appear on the screen. 3. Use buttons to select your main menu option. 4. If you do not have a remote, use the following buttons to select an option from the sub-menu: LCD-Menu = menu or exit CH+/- = Scroll up and down Vol. -
Page 16: Customizing The Picture Settings
Customizing the PICTURE Settings Press LCD-MENU button on the TV set to display the OSD MENU. The OSD menu includes the following options: Brightness Controls the overall brightness of the picture Contrast Controls the difference between the brightest and darkest regions of the picture. Saturation Controls the saturation of the picture. -
Page 17: Customizing The Function Settings
Customizing the FUNCTION Settings Press LCD-MENU button twice on the TV set to display the OSD MENU. The FUNCTION menu includes the following options: Language Select the OSD menu language. Blue Screen Turn on/off the blue screen display when there’s no signal. Wide Screen Control the OSD menu display mode on the screen: 16:9, 4:3. -
Page 18: Customizing The Tuning Settings
Customizing the TUNING Settings Tuning menu in TV mode Press LCD-MENU button thrice on the TV set to display the OSD MENU. The TUNING menu includes the following options: Skip Skip the channel when you scan the channels with (in TV mode) the function. -
Page 19: Epg Menu
EPG menu Press button on the remote control in DTV mode, the screen will display the Guide menu as below. Press button to cancel. Note: The content shown in the picture above is just an example. Closed Caption Press button on the remote control in DTV mode, the screen will display the Closed Caption as below. -
Page 20: Media Operation
Playing media files from the USB and SD card slots - The following files formats are supported by this TV: JPG, MP3, WMA, MP4 (DivX3.11-5.11, Xvid), MPEG1 (DAT, MPG, MPEG), MPEG2 (mpeg, mpg). - File formats including the following are not supported by this TV: BMP, PNG, AAC, DivX 6, DivX HD, Vob, ts. -
Page 21: Playing Media Files From The Usb And Sd Card Slots
Playing media files from the USB and SD card slots (3) - Music, (4) - Photo or (5) - Movie in area (1). (2). ENTER NOTE: STOP 4) Buttons for MEDIA playing DISPLAY SLEEP ZOOM VOL+/- THUMBSTICK ENTER SLOW SETUP PROG REPEAT GOTO... -
Page 22: System Settings For Media
System Settings for Media System operation will define the setting of the set; these definitions will be stored until you change them again. General Steps of Setup Menu 1. Press SETUP on the remote control. The main menu will be shown as below. 2. -
Page 23: Media Operation
Media Operation System Settings for Media 2. LANGUAGE SETUP The language setup options are illustrated below: - OSD LANGUAGE: The OSD will display in the language you choose. 3. AUDIO SETUP -TONE: Use the button to move the scroll and adjust the tone. -
Page 24: Maintenance And Service
Maintenance and service Trouble shooting - Do not use other functions that are not mentioned in this user’s manual. - In case a problem occurs with your LCD TV, please take the following steps first. - If the problem still occurs, turn the power off and contact your dealer or an authorized service center. The screen does not appear. -
Page 27: Viore Limited Warranty
VIORE or VIORE's authorized service center. VIORE will repair or if repairs cannot be made, VIORE will replace this Product at no charge if the Product is defective as specified in this limited warranty during the limited warranty period. - Page 28 VIORE, Inc. 7801 Hayvenhurst Avenue, Van Nuys, California 91406 Printed in China...
