Viking DFC180 Specification Manual

Standard Features & Accessories
All models include
• Trash drawer capacity—1.7 cu. ft.—
the largest capacity trash drawer on
the market
o Allows random loading of bulky
items
• Machine easily compacts and holds
the weekly trash of a family of four
• Commercial-type construction—the
most powerful home compactor
• Professional styling
• Built-in small litter area
o Allows loading of small items
without opening large drawer
o May be opened during operation
• Built-in storage compartment
• Easy-glide drawer allows for smooth
opening and closing
• Breakaway trash basket with pressure
release handle/plate for easy removal
Model Options
VUC181
Professional
FINISH DETAILS FOR VUC MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Finish designates door and drawer
panels. Stainless steel control panel
(with black graphics), litter door pull,
handle (with chrome-plated brackets);
black control panel switches.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and litter door pull.
Brass components have a durable
protective coating for maintenance-free
normal use.
ORDERING INSTRUCTIONS
First specify model number, followed by color code (VUC181SS). If ordering optional brass trim, specify code at end (VUC181SSBR).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Undercounter 18"W. Trash Compactor
o Easy to empty and clean
o May be used with or without bags
• Activated charcoal filter and fan with
control panel switch (shipped with one
filter)
o Removes odors
o Eliminates the need for perfumed
deodorizers
o A control panel light indicates fan is
operating
• 1⁄2 horsepower, high-torque motor
with 3,000 lbs. of force (delivered at
all positions and at all points of the
ram head)
• 3-Point Drive System avoids jamming,
which can result from uneven loading
o In 35 seconds, this system reduces
trash to 1/4 its original size
• 3-Piece Ram encloses motor and drive
DUC180
Designer
FINISH DETAILS FOR DUC MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
• Finish designates door and control
panel. Cast stainless steel handle.
• Brass Trim Option (BR)—handle and
release lever. Brass components have a
durable protective coating for
maintenance-free normal use.
• 1 - 8 8 8 - V I K I N G 1
KITCHEN CLEANUP
system, for quiet operation
• Durable, heavy-gauge steel frame and
double-reinforced base withstand
heavy loads
• Key-start operation with safety lock
o Positive drawer closing—compactor
will not operate while drawer is
open
• Shipped with five grip/slip plastic bags
with ties
o Outside grips to hold bag in place;
inside slips for easy compacting
o Specifically designed to fit 18"W.
compactor
o A tough 3.5 mil. thick
o Punched holes match bag retainer
buttons
DFC180
Custom Front
FINISH DETAILS FOR DFC MODEL
• Stainless Steel control panel.
• Handle not included—opt for a custom
handle, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories)
• Accepts 3/4"-thick custom panel
• See Custom Panels section for more
information and additional
specifications.
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 1 2 / 1 / 0 7
