Summary of Contents for Intelbras IWR 3000N

  • Page 1 User guide IWR 3000N...
  • Page 2 Congratulations, you have just purchased a product with Intelbras quality and security. The IWR 3000N is ideal for those who need Wi-Fi for simple day-to-day tasks, such as using social networks and accessing websites. Its installation and management can be...
  • Page 3 Care and safety Adjust the position of the antennas: normally the vertical position is the most indicated. Prefer to install your router in the central part of the environment and preferably in a higher location, for example on top of a furniture.

  • Page 4: Table Of Contents

    Summary 1. Technical specifications 2. Accessories 3. Installation 4. Configuration 4.1. Installation Wizard ................6 4.2.

  • Page 5: Technical Specifications

    1. Technical specifications Hardware Chipset (CPU) RTL8676S Chipset wireless RTL8192ER Flash memory 2 MB SDRAM memory 8 MB 2 fixed antennas 5 dBi 4 LAN ports (100 Mbps each) 1 WAN port (100 Mbps) Wireless parameters Standards IEEE 802.11b/g/n Radio mode MiMo Mode of operation AP Router/Wireless Repeater...

  • Page 6: Installation

    1. Connect the computer to one of the LAN (yellow) ports on the router using a network cable; Note: if you wish to access your router via Wi-Fi, connect to the network under the INTELBRAS name, after performing steps 2 and 3.
  • Page 7 Installation wizard home screen » Skip: this option allows you to bypass the installation wizard. You will be taken to the router’s main configuration page. In this case, you will have to perform all settings manually. » Start wizard: by selecting this option, the installation wizard starts the detection of your internet connection and the step-by-step guide to make the main settings of your router.
  • Page 8 From there you will have to make the settings according to the following information. Note: if you have any questions about which connection mode to use, please contact your operator or internet provider for more information. » DHCP: if your connection to the Internet is made through an automatic IP address delivery connection, select the DHCP mode in the checkbox.

  • Page 9: Scenarios For Product Use

    1. Access the product web interface (default address is http://10.0.0.1 ), switch to Advanced mode, navigate to the Local Area Network (LAN)>DHCP server menu . Then disable the DHCP server and save the changes; we also recommend changing the IP of your IWR 3000N’s local network, through the Local Area Note: Network (LAN)>IP Address menu, to an address available on the network it will be part of.

  • Page 10: Summary Of Information

    IP addresses will be performed by your main router. » Use as a Switch: in this mode of use, you can connect devices to the local network of the IWR 3000N (via cable, through the LAN ports) and allow them to communicate. For this, you must: 1.

  • Page 11: Name And Passwords

    2. Connection Status: indicates the current connection status of your router as shown in the following scheme: » Disconnected device. » Device connected via Wi-Fi. » Device connected via cable. 3. Addresses: displays the IP and MAC addresses of the device. 4.
  • Page 12 Click on the Wi-Fi Network Name area, fill in the field with the desired name for your network, click on Save and wait for the completion of the configuration following the guidelines that will be displayed on screen. The configuration interface will inform you if an invalid name is entered for your network. In this case, you must enter a different name.
  • Page 13 To set a password for your Wi-Fi network, keep the Leave Wi-Fi network without password box unchecked and fill in the New Wi-Fi password and Confirm new password fields with the desired password. Then click on Save , and wait for the configuration to complete, following the directions that will appear on the screen.

  • Page 14: Signal Repeater Mode

    , located next to the Signal Repeater Mode key. Attention: » The IWR 3000N will not display Wi-Fi networks that have SSID hidden. » Repeater mode is compatible with Wi-Fi networks that have names containing only the following characters, and do not end with the space character.

  • Page 15: Wps

    IP address that the IWR 3000N Note: obtained on your network. Write down this address, because from there it will be the one you will use whenever you want to access the product settings again.

  • Page 16: Maintenance

    To update the firmware of your router, you must access the Maintenance>Update menu. The latest version of the software for your router can be found at our website www.intelbras.com.br/downloads . to select it. Once the file is selected, click Start update and wait for the After downloading the file, click the button update following the on-screen guidelines.

  • Page 17: Port Forwarding

    Backup So that your settings are not lost or to recover them in the future, you can use the backup and restore options. The backup allows a file to be generated to save your settings on your computer, for example. The restore function retrieves this information when necessary.

  • Page 18: Switch Configuration Mode

    4.10. Switch configuration mode Some settings of your router are separated in an advanced configuration mode. This mode can be activated by clicking on the Go to Advanced mode field in the menu. Option to switch the interface mode Once in Advanced mode, you can return to basic mode by clicking the same field again. 4.11.
  • Page 19 DDNS Through this feature, you can add dynamic No-IP and DynDNS service hosts directly to your router. You must register ® ® your information directly on the website of one of the services, and then inform in the router the parameters for authentication.

  • Page 20: Local Area Network (Lan)

    Band control Band control allows rules to be created to set your Internet speed use priorities. In order to have maximum efficiency control of your Internet band use, it is important that you inform the router of the speed contracted with your operator. You can enter this information in the router through the section Contracted Internet Speed .
  • Page 21 DHCP Server You can change various details of the DHCP server operation of your router, as well as disable it if you wish, for example, to use the product as a switch or as an access point. DHCP server configuration form »...

  • Page 22: Wi-Fi Settings

    4.13. Wi-Fi Settings The Wi-Fi Settings menu, accessible through the Advanced settings mode, groups all the advanced options related to the router’s Wi-Fi network. The description of each submenu appears below. Channels In this submenu, you can change the channel, band and extension channel of your router. To perform the configuration, select the options in the checkboxes, click Save and wait for the configuration to be completed following the on-screen instructions.

  • Page 23: Ipv6

    Important: » If you perform any blocking, unblocking, or global policy change operation, your router’s Wi-Fi network will restart, causing a momentary disconnection in the Wi-Fi network. » If you perform these operations through a device connected via Wi-Fi, you may need to reconnect to the network and access the configuration page again if you wish to add new devices.

  • Page 24: Warranty Term

    If you have any questions about the reverse logistics process, please contact us at (48) 2106-0006 or 0800 704 2767 (Monday to Friday from 8 am to 8 pm and Saturdays from 8 am to 6 pm) or via e-mail suporte@intelbras.com.br.
  • Page 25 Support via e-mail: suporte@intelbras.com.br Customer Service: 0800 7042767 Where to buy? Who installs it? 0800 7245115 Intelbras S/A – Indústria de Telecomunicação Eletrônica Brasileira Produced by: Rodovia SC 281, km 4,5 – Sertão do Maruim – São José/SC – 88122-001 01.20...
