Standard Features & Accessories
All models include
• Capacity—15.9 cu. ft. (450.0 L)
o 84"H./24"D.
• ProChill™ Temperature Management
System
o Variable-speed single compressor
system includes the quietest, most
technologically advanced
compression available
o Electronic controls maintain the
temperature selection within 1ºF
o Multi-channel airflow system
removes odors and excess humidity
• Six adjustable half-width wire shelves
• One full-width metal shelf
• Two full-width slide-out wire baskets
• Factory-installed automatic ice maker
• One full-width ice storage drawer with
two metal ice bins
Model Options
VCFB304
Professional
FINISH DETAILS FOR VCFB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door front.
Stainless steel upper grille, side trim,
and handle (with chrome-plated
brackets); black lower kickplate.
• Brass Trim Option (BR)—nameplate,
handle/brackets, and side trim. Brass
components have a durable protective
coating for maintenance-free normal
use.
ORDERING INSTRUCTIONS
First specify model number, followed by hinge preference ("R" for right or "L" for left), and then color code (VCFB304RSS).
If ordering optional brass trim, specify code at end (VCFB304RSSBR).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
• Full-extension precision ball-bearing
glides on all baskets and drawers
• Three adjustable aluminum door bins
with tempered glass front
• Adaptive defrost
• All-metal freezer interior
• Top-mounted and front-venting sealed
refrigeration system
• Dual magnet and spring-assisted door
closer mechanism
• Robust, heavy-duty door hinges
• Power interruption switch to turn off
all power
• Automatic energy-saving exterior
moisture control
• Open door alarm sounds and glows to
warn that door has been ajar for three
minutes
DDFB304
Designer
FINISH DETAILS FOR DDFB MODEL
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite
Gray (GG), Stone Gray (SG), Taupe
(TP), Biscuit (BT), Cotton White (CW),
Oyster Gray (OG), Golden Mist (GM),
Lemonade (LE), Sage (SA), Mint Julep
(MJ), Sea Glass (SE), Iridescent Blue
(IB), Viking Blue (VB), Pumpkin (PM),
Racing Red (RR), Apple Red (AR),
Burgundy (BU), Plum (PL), Chocolate
(CH), and Cobalt Blue (CB).
• Finish codes designate door front.
Stainless steel upper grille, side trim,
and handle, with black lower kickplate.
• Brass Trim Option (BR)—handle. Brass
components have a durable protective
coating for maintenance-free normal
use.
•
1 - 8 8 8 - V I K I N G 1
REFRIGERATION
Built-In 30"W. All Freezer
• Adjustable door stops standard—90°,
110°, or 120° swing
• Sabbath Mode
• For installation of two units together,
separate grille kit must be purchased
• Must be ordered right or left hinge.
(As you face unit, RIGHT has hinge on
right side and handle on left side;
LEFT has hinge on left side and
handle on right side.)
DFFB304
Custom Front
FINISH DETAILS FOR DFFB MODEL
• Handle not included—opt for custom
handle, or purchase a Viking
Professional Series or Designer Series
handle kit (see Installation Notes &
Accessories).
• See Custom Panels section for more
information and additional
specifications.
© 2 0 0 7 V R C — INFORMATION SUBJECT TO CHANGE
R E L E A S E D 1 2 / 1 / 0 7
