Viking VGRC485-4GD Series Specifications

Standard Features & Accessories
All models include
• Right oven—convection bake/broil
o Overall capacity—4.2 cu. ft.
(24-1/8"W. x 14-1/8"H. x 21-1/4"D.)
o AHAM Standard capacity—3.8 cu. ft.
(24-1/8"W. x 14-1/8"H. x 19-1/4"D.)
o Exclusive combination of dual bake
burners and infrared broil burner, all
with automatic ignition
o Six functions—natural airflow bake,
convection bake, infrared broil,
convection infrared broil, convection
dehydrate, and convection defrost
o Three heavy-duty racks/five rack
positions
o Two lights
• Left oven—bake, with auto. ignition
o Overall capacity—2.3 cu. ft.
(13-3/8"W. x 14-1/8"H. x 21-1/4"D.)

Model Options

VGRC485-6GD*
Six-Burner/Griddle Range
FINISH DETAILS FOR ALL MODELS
• Stainless Steel (SS), Black (BK), White
(WH), Metallic Silver (MS), Graphite Gray
(GG), Stone Gray (SG), Taupe (TP), Biscuit
(BT), Cotton White (CW), Oyster Gray
(OG), Golden Mist (GM), Lemonade (LE),
Sage (SA), Mint Julep (MJ), Sea Glass
(SE), Iridescent Blue (IB), Viking Blue (VB),
Pumpkin (PM), Racing Red (RR), Apple
Red (AR), Burgundy (BU), Plum (PL),
Chocolate (CH), and Cobalt Blue (CB).
o Finish designates door front, lower
front panel, and side panels.
*Shown throughout with 6"H. backguard. See Installation Notes & Accessories for details.
ORDERING INSTRUCTIONS
First specify model number, and then color code (VGRC485-6GDSS). If ordering optional brass trim, specify code at end (VGRC485-6GDSSBR).
If ordering optional LP conversion, specify code at end (VGRC485-6GDSSBRLP).
P L A N N I N G A N D D E S I G N G U I D E
V I K I N G R A N G E . C O M
Professional Freestanding Gas 48"W.
Commercial Depth Open Burner Range
o AHAM Standard capacity—2.3 cu. ft.
(13-3/8"W. x 14-1/8"H. x 21-1/4"D.)
o Two heavy-duty racks/five
rack positions
• Exclusive VariSimmer™ setting for all
burners
• Removable porcelain burner bowls
• Drip tray with roller bearing glides and
two-quart drip pan
o Standard kickspace height
6GD models include
• Six 15,000 BTU stainless steel burners
with porcelain/cast iron caps and
automatic ignition/re-ignition
• 12"W. thermostatically controlled steel
griddle/simmer plate
6QD models include
• Six 15,000 BTU stainless steel burners
with porcelain/cast iron caps and
VGRC485-6QD*
Six-Burner/Grill Range
o Has black porcelain grates, black
porcelain burner caps, black
porcelain grate supports/burner
bowls, and black knobs/switches.
• White (WH)
o Finish designates door front, lower
front panel, side panels, porcelain
grate supports/burner bowls,
porcelain center worktop, and
knobs/switches.
o Has black porcelain grates and black
porcelain burner caps.
• 1 - 8 8 8 - V I K I N G 1
automatic ignition/re-ignition
• 12"W. grill with flavor generator plates
and automatic ignition/re-ignition
4GD models include
• Four 15,000 BTU stainless steel
burners with porcelain/cast iron caps
and automatic ignition/re-ignition
• 24"W. thermostatically controlled steel
griddle/simmer plate (separate burner/
control for the left and right side)
4GQD models include
• Four 15,000 BTU stainless steel
burners with porcelain/cast iron caps
and automatic ignition/re-ignition
• 12"W. thermostatically controlled steel
griddle/simmer plate
• 12"W. grill with flavor generator plates
and automatic
VGRC485-4GD*
Four-Burner/
Double Griddle Range
• All finishes have stainless steel
handles/chrome-plated brackets and
stainless steel drip tray pull, control
panel, and landing ledge.
• Brass Trim Option (BR)—nameplate,
window trim, handle, drip tray pull,
knob bezels, thermal-convection switch
bezel, and grate support side trim.
Brass components have a durable
protective coating for maintenance-
free normal use.
© 2 0 0 7 V R C — I N F O R M AT I O N S U B J E C T T O C H A N G E
COOKING
ignition/re-ignition1
VGRC485-4GQD*
Four-Burner/
Griddle/Grill Range
R E L E A S E D 1 2 / 1 / 0 7
