Install the latch

1
A
Extend the latch bolt.
B UP is on top.
C
If the D-shaped hole
is not centered in the
door hole, rotate the
latch face to extend
the latch.
8
If your door requires
a drive-in latch,
please contact
Kwikset at
1-800-327-5625.
screws if the holes
You will have two
[OUTSIDE]
03809*
(2X)
*Use the longer
are worn out.
extra screws.
