- Page 1 ViewSonic Digital Photo Frame VFM835-52G VFM835-72G - 使用手冊 - User Guide Model No.: VS12674...
-
Page 2: Important Safety Instructions
Important Safety Instructions Do not use the equipment near water. Wipe the machine with a soft and dry cloth. Do not block any vent holes. Please install the product in accordance with the manufacturer’s instructions. Do not use the product on your legs for a long time because it gets hot and you may be burned. P lease avoid installing the product in a place where the temperature is above 35°C or lower than 5°C, or in a place that is moist or wet. P rotect the power cord plug, outlet, and connections to other equipment from damage by trapping and squeezing. Please only use devices and accessories specified by the manufacturer. T he unit is hot pluggable. However it is recommended that the power be turned off before the memory card is inserted or removed. Do not remove the memory card during data access. The data may be lost and the product could be damaged. 0. Disconnect the power cord if the product will not be used for an extended period. 11. D o not repair, disassemble, or modify the product. Only qualified ViewSonic personnel can check and repair any damage to the machine. 12. T he unauthorized playing of certain audio or image files may infringe the related copyright laws under certain circumstances. 3. W hen you use the internal speakers, do not adjust the volume to a high level, or the sounds may distort and become unpleasant. 4. When you view pictures for an extended period of time your eyes may become strained. 15. Do not touch the screen because it is difficult to remove finger marks. 6. Avoid exposing the digital photo frame to direct sunlight. Adjust the angle to reduce glare. 7. Careful attention should always be paid when moving the digital photo frame. 8. Make sure the place where the digital photo frame is placed is clean and dry. 9. I f there is smoke, a strange smell or an abnormal noise, immediately turn off the digital photo frame and contact your dealer or ViewSonic. 20. -
Page 3: Declaration Of Rohs Compliance
Hexavalent Chromium (Cr 6+ ) Polybrominated biphenyls (PBB) Polybrominated diphenyl ethers (PBDE) Certain components of products as stated above are exempted under the Annex of the RoHS Directives as noted below: Examples of exempted components are: 1. M ercury in compact fluorescent lamps not exceeding 5 mg per lamp and in other lamps not specifically mentioned in the Annex of RoHS Directive. 2. L ead in glass of cathode ray tubes, electronic components, fluorescent tubes, and electronic ceramic parts (e.g. piezoelectronic devices). 3. L ead in high temperature type solders (i.e. lead-based alloys containing 85% by weight or more lead). 4. L ead as an allotting element in steel containing up to 0.35% lead by weight, aluminium containing up to 0.4% lead by weight and as a cooper alloy containing up to 4% lead by weight. ViewSonic Proposed Maximum Concentration 0.% 0.% 0.0% 0.% 0.% 0.% Actual Concentration < 0.% < 0.% < 0.0% < 0.% < 0.% < 0.% VFM835-52G/VFM835-72G... -
Page 4: Copyright Information
No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission from ViewSonic Corporation. Product Name: Model Number: Document Number: Serial Number: Purchase Date: Product disposal at end of product life ViewSonic is concerned about the preservation of our environment. Please dispose of this product properly at the end of its useful life. Your local waste disposal company may provide information about proper disposal. The lamp in this product contains mercury. Please dispose of properly in accordance with environmental laws of your location. ViewSonic For Your Records VFM835-52G/VFM835-72G ViewSonic Digital Photo Frame VS12674 VFM835-52G_72G_UG_ENG Rev. 1A 07-28-09 _______________________________________ _______________________________________ VFM835-52G/VFM835-72G... -
Page 5: Table Of Contents
Introduction...1 Main Features ...2 Controls and Connections ...3 Remote Control...4 Getting Started...6 Attaching the mount ...6 Connecting to the power ...7 Inserting Media...7 Copy files from computer ...8 Viewing Photos...10 Main menu...10 Viewing thumbnails ... 11 Browsing a single photo ...12 Playing a slideshow...12 Using OSD menu ...13 Listening to Music ...14... -
Page 6: Introduction
We also have no responsibility for damages or loss of data caused by improper operation. The instruction manual is subject to change for improvement without notice. Trademarks and trade names used in this user’s manual are owned by their respective companies or organizations. ViewSonic VFM835-52G/VFM835-72G... -
Page 7: Main Features
Clock and Calendar display Alarm setting Auto power On/Off Compatible with SD/MMC/MS memory cards USB Host for connecting to the USB mass storage Controlled either by 7 touch keys on the front panel of the unit, or by infrared remote control ViewSonic VFM835-52G/VFM835-72G... -
Page 8: Controls And Connections
Infrared sensor [ ] Play/Pause/Confirm button ViewSonic [M] Menu touch key; open OSD menu [ ] Exit touch key [ ] Left touch key [ ] Right touch key [ ] Up touch key [ ] Down touch key VFM835-52G/VFM835-72G... -
Page 9: Remote Control
Select next photo while viewing photos or switch to next page in thumbnail mode. Fast forward within a track/video in music/video mode. Start a slide show with background music. Start or stop playing background music during a slideshow. Decrease the volume. VOL- VFM835-52G/VFM835-72G... -
Page 10: Battery Installation For The Remote Control
Press and hold the battery release tab in the direction of arrow Pull out the battery holder completely in the direction of arrow Remove the old battery, and place a new battery in the holder. Push the holder back into the remote control. as shown in the left. VFM835-52G/VFM835-72G... -
Page 11: Getting Started
Turn the mount counter-clockwise by 90° until it locks. It will now be possible to set the device in the portrait orientation. After the mount has been attached, you can adjust the height of the mount by pushing the mount gradually to the required alignment. ViewSonic VFM835-52G/VFM835-72G... -
Page 12: Connecting To The Power
• Secure Digital Card (SD) • Multimedia Card (MMC) Following is the method of inserting a memory card or attaching a memory stick: ViewSonic Switch the power to the ON marking position to turn on the Digital Photo Frame. • Memory Stick (MS) VFM835-52G/VFM835-72G... -
Page 13: Copy Files From Computer
The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system to finish the installation. When it has finished, several “Removable Disk”, which indicate all drivers of the digital photo frame, will be created in “My computer”. ViewSonic Push a USB memory stick into the USB HOST slot. VFM835-52G/VFM835-72G... - Page 14 The Digital Photo Frame must be plugged in and turned on before connecting to the computer. When connecting with a computer, the USB HOST driver is not available. Do not disconnect the USB cable or remove the card during files coping and transferring. System support: Windows 2000/ XP/ Vista ® ViewSonic VFM835-52G/VFM835-72G...
-
Page 15: Viewing Photos
Appears when you insert a SD, MMC or MS card. Appears when you inserted a USB flash driver. Clock To display the Clock on the screen. Calendar To display the Calendar on the screen. Setup To customize the settings of Digital Photo Frame. VFM835-52G/VFM835-72G... -
Page 16: Viewing Thumbnails
Touch [ ] or [ ] to select Photo, and then touch [ ]. The photos are displayed on the screen as thumbnails. To navigate through the thumbnails or move to the next or previous page of thumbnails, touch [ ], [ ], [ ] or [ ]. VFM835-52G/VFM835-72G... -
Page 17: Browsing A Single Photo
While browsing a single photo, touch [ ] to start a slide show from the current photo. Pause the slideshow and view a single photo, touch [ ]. Resume the slideshow, touch [ ] again. Touch [ ] to exit the slideshow and view photos in thumbnail. Touch [M] to open the OSD menu. ViewSonic VFM835-52G/VFM835-72G... -
Page 18: Using Osd Menu
[ ] repeatedly to magnify a photo in the following sequence: X2, X4, X8, X16. When a and touch [ ]. Adjust volume, highlight and touch [ ]. icon is changed to and touch [ ]. and then touch [ ] to VFM835-52G/VFM835-72G icon. -
Page 19: Listening To Music
[ ]. To resume playback, highlight , and then touch [ ]. , and then touch [ ]. and touch [ ] repeatedly to select: Off, Once, and then touch [ ] to decrease/increase volume. and touch [ ]. VFM835-52G/VFM835-72G and touch... -
Page 20: Watching Videos
, and then touch [ ]. , and then touch [ ]. and touch [ ] repeatedly to select: Off, Once, and touch [ ] repeatedly to magnify the video and then touch [ ] to decrease/increase volume. and touch [ ]. VFM835-52G/VFM835-72G... -
Page 21: Managing Files
Touch [ ] or [ ] to select COPY, and touch [ ]. The memory device connected to the unit is displayed. Touch [ ], [ ], [ ] or [ ] to select a memory device. Touch [ ] to start coping files. is displayed next to VFM835-52G/VFM835-72G... -
Page 22: Deleting Files
The date, time, date format and time format can be adjusted in Setup mode. You can choose to display digital clock or analog clock in Setup mode. You can choose to display photos in thumbnail or not in Setup mode. VFM835-52G/VFM835-72G... -
Page 23: Changing Frame Settings
Set movie repeat mode. The available options include: Repeat off: Play all movies in order once. Repeat one: Repeat the current or selected movie. Repeat all: Repeat all movies. Choose Digital clock or Analog clock while displaying the clock. VFM835-52G/VFM835-72G... - Page 24 Set how long to display the hint for button operation while playing a slideshow. The available options include: 0s, 5s, 10s, 20s. Set the backlight exiting time for touch keys. The available options include: 5s, 10s, 15s, 20s Reset all settings to the default settings. VFM835-52G/VFM835-72G...
-
Page 25: Setting Time & Date
You can set the Digital Photo Frame to run a specified mode automatically when you switch on it. Select the SETUP icon on the main menu and then touch [ ]. The Setup Menu appears on the screen. ViewSonic VFM835-52G/VFM835-72G... -
Page 26: Setting Auto Power On/Off
Once: The Digital Photo Frame only turns on or off at the specified time once. Touch [ ] to confirm or touch [ ] to exit. Note: The current time must be set correctly before setting up this feature. ViewSonic VFM835-52G/VFM835-72G... -
Page 27: Frequently Asked Questions
Note: The rotated photo will return to its original orientation after you power off the Digital Photo Frame. What is the best photo resolution displayed on the screen? • The best resolution is 800*600 and the max photo resolution of this Digital Photo Frame is 8000*8000 pixels. ViewSonic and touch [ ] to rotate a photo. VFM835-52G/VFM835-72G... -
Page 28: Specification
USB Host 2.0 (High Speed) Supports USB flash media SD™ (Secure Digital Card), MMC™ (MultiMedia Card), MS™ (Memory Stick). JPEG, Maximum resolution: 8000*8000 pixels MP3: 32KBps_320KBps(CBR, VBR) MPEG-1(MP@ML), MPEG-4(ASP, Xvid Compliant), M-JPEG(up to VGA, 30fps) Humidity﹤85%, -20~60℃ Humidity﹤85%, -10~40℃ 216*182*28.3mm 603.4g VFM835-52G/VFM835-72G... -
Page 29: Customer Support
Customer Support For technical support or product service, see the table below or contact your reseller. Note: You will need the product serial number. Country/Region Web Site China www.viewsonic.com.cn Hong Kong www.hk.viewsonic.com/support/ ViewSonic Telephone e-mail 800 820 3870 service.cn@cn.viewsonic.com 852 302 2900 service@hk.viewsonic.com VFM835-52G/VFM835-72G... -
Page 30: Limited Warranty
F or information about receiving service under warranty, contact ViewSonic Customer Support (please refer to Customer Support page). You will need to provide your product’s serial number. 2. T o obtain warranted service, you will be required to provide (a) the original dated sales slip, (b) your name, (c) your address, (d) a description of the problem, and (e) the serial number of the product. 3. T ake or ship the product freight prepaid in the original container to an authorized ViewSonic service center or ViewSonic. 4. F or additional information or the name of the nearest ViewSonic service center, contact ViewSonic. Limitation of implied warranties: There are no warranties, express or implied, which extend beyond the description contained herein including the implied warranty of merchantability and fitness for a particular purpose. Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. D amage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages. 2. Any other damages, whether incidental, consequential or otherwise. 3. Any claim against the customer by any other party. 4.3: ViewSonic DPF Warranty DPF_LW0 Rev. A 06-20-08 ViewSonic Limited Warranty VIEWSONIC Digital Photo Frame VFM835-52G/VFM835-72G...
