Summary of Contents for vollara CLASSIC AIR
- Page 1 CLASSIC ELECTRONIC AIR PURIFICATION USER’S MANUAL 100, 110, and 220 Volt Systems Installation | Operation | Specifications | Warranty CAUTION: Read manual carefully for proper procedures and operation.
-
Page 2: Table Of Contents
Warranty ............. 12 Please record the serial number of your ClassicAir: Serial # ______________________________________________________________ Please record the name and phone of your Vollara Independent Business Owner: Name _______________________________________________________________ Phone _______________________________________________________________ To reduce the risk of electric shock, this equipment has a grounding type plug that has a third (grounding) pin. -
Page 3: Notable Features
NOTABLE FEATURES • Compact • Portable • No Duct Work Required • No Chemicals • Low Maintenance • Low Electrical Use • Complete User Control • No Residual Contamination • Plugs into 110 (100 or 220) volt outlet SPECIFICATIONS • Positive/Negative Ion Generation Technology •... -
Page 4: Principles Of Operation
PRINCIPLES OF OPERATION Nature cleanses the air with lightning and rain. Lightning bolts produce ozone, as well as positive and negative ions which cleanse the air naturally. Rain helps bring the ozone and ions closer to the earth's surface. They are then attracted to atmospheric contaminants that are either removed from the air and attached to grounded objects or are oxidized. -
Page 5: Purification Plate/Lint Screen Install
PURIFICATION PLATE INSTALLATION The ClassicAir utilizes one purification plate. 1. Rotate the Lint Screen retainer out of the way. 2. Remove the Lint Screen. 3. Fully insert purification plate (a) between the guide-grooves in the top and bottom of the plate cage (between the posts and clips) making sure the metal clip on each side of the plate is in contact with the metal screen on... -
Page 6: Placing The Unit
PLACING THE UNIT Place the unit as high as possible to insure complete purification. If raised placement is not available, place unit as high as possible and elevate front of unit so fan blows towards ceiling. Some pollutants rise, such as smoke, and an elevated unit can oxidize the pollutants more effectively. -
Page 7: Setting/Adjusting Controls
SETTING AND ADJUSTING CONTROLS 1. FAN CONTROL The disbursement of treated air is best accomplished with good air circulation. The FAN control should be set as high as reasonably possible without creating an undesirable noise level. This will be determined by personal preference and the distance you wish the cleansing properties to be dispersed. -
Page 8: Maintenance
MAINTENANCE Periodic maintenance is required to insure that the ClassicAir operates properly. A severely polluted environment can foul a purification plate in as little as two weeks or as long as a year. Shown here are basic maintenance procedures that should be carried out to keep your unit running at top performance. -
Page 9: Troubleshooting
Fan Blade and Front Grill Wipe off fan blade and front grill, if dirty, with damp washcloth. The fan requires no maintenance (with the exception of the first time it is used, when it may be necessary to give it a gentle push to get it started). If the fan squeaks, a drop of lightweight oil may be needed on the fan shaft. - Page 10 TROUBLESHOOTING - What to look for first. 1. I have plugged in the unit, turned "ON" the power switch, and nothing happens… what's wrong? • Make sure the electrical outlet is capable of providing power to the unit. • Check the Lint Screen located at the back of the machine to ensure that the safety switch activator clip depresses the safety switch.
- Page 11 • Is the unit properly placed away from objects that may obstruct air flow? • Are the filter and fan housing clean? If your unit fails to operate properly after performing troubleshooting, contact your Vollara Independent Business Owner for further assistance, contact us at the address located on the front of the manual, or visit www.vollara.com for additional technical support.
-
Page 12: Warranty
In such states, will be voided. Vollara products the above limitations may not apply are authorized for sale through INSTALLATION AND MAINTENANCE to you.
