PRINCIPAL GRAND - Subwoofer
Owner´s Manual
Thank you for your investment in our PRINCIPAL
GRAND Subwoofer, we trust that you will enjoy the
musical performance this product offers!
Please read this manual carefully and utilize the setup
suggestions discussed. Ultimately, the most important
part of the process is to listen to music and enjoy. Our
suggestions are just that, suggestions.
If you find in your listening environment that a slightly
different adjustment in setup results in a more
enjoyable sonic picture, then follow it. All rooms are
different and thus, we cannot give an accurate, single
installation instruction guide that will cover all possible
environ-ments. Please feel free to contact us or your
local distributor with any setup related questions. It is
our collective goal to ensure that you achieve the best
possible performance out of this sophisticated product.
Thank you again and happy listening.
Sincerely,
Vienna Acoustics
Advertisement
Related Manuals for Vienna Acoustics Principal Grand
Summary of Contents for Vienna Acoustics Principal Grand
- Page 1 PRINCIPAL GRAND - Subwoofer Owner´s Manual Thank you for your investment in our PRINCIPAL GRAND Subwoofer, we trust that you will enjoy the musical performance this product offers! Please read this manual carefully and utilize the setup suggestions discussed. Ultimately, the most important part of the process is to listen to music and enjoy.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION Explanation of symbols used in this manual and on the product: This symbol is intended to alert the user to the presence of uninsulated dangerous voltages within the enclosure of sufficient magnitude to cause electric shock. This symbol is intended to alert the user to the presence of important maintenance and servicing information in the instruction and service manuals. - Page 3 EXPOSE MOISTURE. PLEASE READ THE FOLLOWING SAFETY INSTRUCTIONS VERY CAREFULLY BEFORE OPERATING THE PRINCIPAL GRAND SUBWOOFER 1. Observe all warnings: Observe all warnings on the subwoofer and in the operating instructions. 2. Follow instructions: Follow all operating, in- stallation and use instructions.
- Page 4 10° – 40°C (50° – 105°F). 6. Objects and liquid damage: Do not let objects or liquids fall into the Principal Grand. Do not place a container with liquid on top of this product. 7. Water...
- Page 5 For this reason it is not recommended to build the Principal Grand into any cabinetry that does not contain special cooling capabilities. 10. Heat: Position the Principal Grand away from heat sources such as radiators, heaters, stoves or other appliances (including heat.
- Page 7 Principal Grand is being used exclusively for LFE. In such an application the crossover should be set to the highest point, thus relying exclusively on the base...
- Page 8 7 – Volume Control: This adjusts the overall volume level of the Principal Grand relative to the main loudspeakers regard-less of whether the High-Level or the Line-Level inputs are used. 8 – Phase Switch: This critical switch allows for the timing of the subwoofer to be in phase (in time) with the main loudspeakers.
- Page 9 Setup procedure for the Principal Grand subwoofer 1. In order to prevent scratches and finger-prints we have supplied with each Principal Grand a pair of our special cloth gloves. We highly recommend using these throughout the entire setup process. 2. Connect the Principal Grand subwoofer using either...
- Page 10 Phase: 0° 6. Listen: It is important that you listen to music while making the final proper adjustments to the Principal Grand. Start with a piece of music that has an abun-dance of consistent and rhythmic low bass. A recording with recorded should work quite well for this process.
- Page 11 The only way to properly setup this device, or any other piece of a fine audio or audio/video equipment, is by listening. Thank you and Happy Listening! Vienna Acoustics...
-
Page 12: Specifications
Specifications Bass System Frequency Response Driver Design Amplifier Inputs Controls Weight Dimensions (w x h x d) Bass-Reflex Design – Bottom vented (requires 25mm/1” to 50mm/2” from vent to floor) 20Hz – 100 Hz Proprietary Pulp-Paper Carbon filled cone manufactured by ScanSpeak, designed by Vienna Acoustics 300 Watts...
