- Page 1 I N S T A L L A T I O N / O P E R A T I O N M A N U A L 1080p Digital Light Processing (DLP™) Projector Vision 110 Vision 110/CineWide™ Vision 110/CineWide™ with AutoScope™ VERSION 1.1...
-
Page 3: Two Year Limited Warranty
(6) months or 1000 hours, whichever comes first, from the effective date of delivery to the end user. In addition, Vidikron will provide a new or rebuilt replacement lamp for the lamp that fails due to defects in materials or workmanship for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to the end user. -
Page 4: Copyright And Trademarks
IMPORTANT -- WARRANTY REGISTRATION: Please fill out and mail your warranty registration card. It is imperative that Vidikron knows how to reach you promptly if we should discover a safety problem or product update for which you must be notified. -
Page 5: Additional Information
ADDITIONAL INFORMATION: To locate the name and address of the nearest Vidikron Authorized Service Center, or for additional information about this Limited Warranty, please call or write: VIDIKRON PRODUCT INFORMATION RETAIN THIS INFORMATION FOR YOUR RECORDS _________________________________________________________ Model Purchased ____________________________________________________________________________________________________________... -
Page 6: Important Safety Instructions
Important Safety Instructions Thank you for your purchase of this quality Vidikron video projector! It has been designed to provide you with the quality of video that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the menus and operation. -
Page 7: Compliance Information
Manufacturer’s Name: Vidikron, a subsidiary of Planar Systems, Inc. Manufacturer’s Address: 2900 Faber Street, Union City, CA 94587 hereby declares that the products Model Numbers: Vision 110, Vision 110/CineWide and Vision 110/CineWide with AutoScope conform with the provisions of: Council Directive 2004/108/EC on Electromagnetic Compatibility;... -
Page 8: Fcc Part
This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. viii Vidikron Vision Model 110 Installation/Operation Manual... -
Page 9: Table Of Contents
Description, Features and Benefits ... 3 Key Features and Benefits... 3 Parts List ... 4 Vision 110 at a Glance ... 5 Vision 110 Rear Panel ... 6 Vision 110 Rear Connector Panel ... 8 Vision 110 Remote Control ...10 Remote Control ...13... - Page 10 Table of Contents 4. Operation ... 45 Installing the Optional CineWide Lens Mount ...22 Installing the AutoScope Lens Motor (Vision 110/CineWide with AutoScope) ...23 Installing the Fixed CineWide Base Plate (Vision 110/CineWide)...27 Mounting the Vision 110 ...28 Floor Mounting (Upright) ...28 Ceiling Mounting (Inverted) ...28...
- Page 11 5. Maintenance and Troubleshooting ... 59 6. Serial Communications ... 63 7. Specifications ... 67 Vidikron Vision Model 110 Installation/Operation Manual Lamp Replacement ...59 Filter Replacement ...60 Troubleshooting Tips ...61 RS-232 Connection and Port Configuration ...63 Serial Command Syntax ...63 Vision 110 Specifications ...67...
- Page 12 Table of Contents Notes: Vidikron Vision Model 110 Installation/Operation Manual...
- Page 13 3-7. Vision 110 with Ceiling Mount Adapters/Projector Stands ....... 25...
- Page 14 List of Figures Notes: Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 15: Introduction
Vidikron has prepared this manual to help home theater installers and end users get the most out of the Vision 110. Vidikron has made every effort to ensure that this manual is accurate as of the date it was printed. However, because of ongoing product improvements and customer feedback, it may require updating from time to time. -
Page 16: Using This Manual
Use the following table to locate the specific information you need in this manual. If you need... Information about obtaining service General information about the Vision Model 110 DLP Projector Installation instructions First-time configuration instructions Advanced configuration instructions Troubleshooting tips Product specifications ... Turn to page: Vidikron Vision Model 110 Installation/Operation Manual... -
Page 17: Description, Features And Benefits
The Vision 110’s 16:9 native aspect ratio DMD array makes it ideal for widescreen viewing, while its 3-chip, 1920x1080 native resolution produces crisp, crystal clear high-definition images with richly saturated colors, deep black levels and natural, highly refined detail. -
Page 18: Parts List
Introduction ➤ Parts List Your Vision 110 is shipped with the following items. If any items are missing or damaged, please contact your Vidikron dealer or Vidikron Customer Service at (888) 4VIDIKRON. • Vision Model 110 DLP Projector • Remote Control Unit and two (2), AAA-size batteries •... -
Page 19: Controls And Functions
Figure 2-1 shows the key Vision 110 components. Figure 2-1. Vision 110 Front/Bottom/Side View PRIMARY PROJECTION LENS VIDIKRON LOGO The logo can be rotated to match the projector orientation: inverted (ceiling-mounted) or upright. To rotate the logo, grip it at the sides, pull it away from the projector and rotate it 180 degrees. -
Page 20: Vision 110 Rear Panel
Remove Remove the screw to pull off the lamp cover. Figure 2-2. Vision 110 Rear Panel Figure 2-2 shows the Vision 110 rear panel. WIRED REMOTE REMOTE WIRED Service port. Not for user access HD1 (RCA) -
Page 21: Down Button
Lights orange to indicate that the projector is in standby mode. 10. SOFT POWER BUTTON Press once to turn on the Vision 110. Press it again to put the projector into Standby mode. For a discrete on or off command, you can use the direct access buttons on the remote control (see Figure 2-4). -
Page 22: Vision 110 Rear Connector Panel
Controls and Functions Vision 110 Rear Connector Panel Figure 2-3 shows the rear connector panel on the Vision 110, and the paragraphs that follow describe them. HD3 (VGA / Y-Pb-Pr) Y-Pb-Pr) (VGA HD2 (BNC) (BNC) Figure 2-3. Rear Connector Panel... -
Page 23: Composite Video Input
(up to 1080p) with a DVI or HDMI output. HD3 INPUT Provides a standard, 15-pin VGA-style connection to either an RGB or component high-definition source, or to a personal computer. The Vision 110 automatically detects the input signal resolution. COMPOSITE VIDEO INPUT Standard composite video input for connecting a VCR, laser disc player or other composite video source. -
Page 24: Vision 110 Remote Control
Controls and Functions Vision 110 Remote Control Figure 2-4 shows the Vision 110 remote control, and the paragraphs that follow describe its functionality. LIGHT S-VID INFO EXIT CONT PICTURE MEMORY CUST1 NIGHT ASPECT RATIO 16:9 CINEMA FOCUS FOCUS ZOOM ZOOM Figure 2-4. - Page 25 Picture Adjustment Buttons: BRT (Brightness) Press to adjust black level. CONT (Contrast) Press to adjust white level. COL (Color) Press to adjust color intensity. TNT (Tint) Press to adjust color hues. Vidikron Vision Model 110 Installation/Operation Manual Controls and Functions...
- Page 26 (enlarge) or the DOWN button to zoom out (reduce). When finished, press MENU or EXIT. LENS (Lens Shift) To adjust the lens position, press LENS. Then, press and hold the RIGHT, LEFT, UP or DOWN button. When finished, press MENU or EXIT. Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 27: Installation
• Ambient conditions may possibly impede the operation of the remote control. If this happens, point the remote control at the projector, and repeat the operation. Vidikron Vision Model 110 Installation/Operation Manual Remote Control Installation Notes on Batteries... -
Page 28: Quick Setup
Installation Quick Setup Table 3-1 gives a quick overview of the Vision 110 installation process. The sections following this one provide detailed instructions. Installation should be performed by a qualified custom video installation Note specialist. Table 3-1. Installation Overview Step... -
Page 29: Installation Considerations
Images may then appear washed out and less vibrant. Vidikron Vision Model 110 Installation/Operation Manual Considerations • Shares floor space with audience •... -
Page 30: Throw Distance
Throw Distance (TD) = Screen Width (w) x Lens Throw Ratio Figure 3-1. Estimating Throw Distance Table 3-3 lists the available lens options for the Vision 110 and their associated throw ratios. Table 3-3. Vision 110 Lens Options and Throw Ratios... -
Page 31: Vertical And Horizontal Position
Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example. Figure 3-3. Vertical Lens Shift (EXAMPLE ONLY) Vidikron Vision Model 110 Installation/Operation Manual Ceiling Lens Center... -
Page 32: Horizontal Lens Shift (Example Only)
Screen Width (W) Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example. Figure 3-4. Horizontal Lens Shift (EXAMPLE ONLY) Vidikron Vision Model 110 Installation/Operation Manual... -
Page 33: Folded Optics
Table 3-4 lists the lens shift limits for each available Vision 110 lens, as percentages and absolute measurements with a 100 x 56 inch (1.78:1) screen. Table 3-4. Vision 110 Vertical and Horizontal Lens Shift Limits Lens Shift Limits, as Percentages of Screen Height or Width (Notes 1 and 2) -
Page 34: Other Considerations
The projection lens is shipped separately from the projector. To install it, proceed as follows: Using a 2.5-mm hex wrench, loosen the two hex screws holding the Projector Front Jewelry in place. Remove the jewelry. Vidikron Vision Model 110 Installation/Operation Manual... - Page 35 Make sure to route the wire harness in its original position and away Caution from the moving lens stages and Motor Assembly, to prevent unexpected disconnection or lens damage. Vidikron Vision Model 110 Installation/Operation Manual Installation...
-
Page 36: Installing The Optional Cinewide Lens Mount
Tighten the hex screws at the top and bottom of the jewelry to secure it. If you are installing a standard (non-CineWide) Vision 110, skip this step and proceed with Mounting the Vision 110 (page 28). If you are installing a Vision 110/CineWide, proceed with Installing the Fixed CineWide Base Plate (Vision 110/CineWide) (page 27). -
Page 37: Installing The Autoscope Lens Motor (Vision 110/Cinewide With Autoscope)
Figure 3-6 shows the Vision 110/CineWide with AutoScope motor assembly. Screw, Phillips Pan-Head, M6-1.0 x 12mm (14x) AutoScope Lens Motor Figure 3-6. Vision 110/CineWide with AutoScope Motor Assembly - Exploded View Vidikron Vision Model 110 Installation/Operation Manual CineWide with AutoScope Ceiling Mt. Adapter/ Projector Stand, Right CineWide with AutoScope Ceiling Mt. - Page 38 Using six (6) each of the supplied, M6 x 12mm Pan-Head Phillips screws (item #2), attach the AutoScope Ceiling Mount Adapters/Projector Stands (items #3 and #4) to the projector as shown in Figure 3-7. Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 39: Vision 110 With Ceiling Mount Adapters/Projector Stands
Installation Figure 3-7. Vision 110 with Ceiling Mount Adapters/Projector Stands DO NOT OVER-TIGHTEN THE SCREWS. Caution Vidikron Vision Model 110 Installation/Operation Manual... -
Page 40: Autoscope Lens Motor Installation
Secure the motor to the projector with the eight (8) remaining M6 x 12mm Pan-Head Phillips screws (item #2). Figure 3-8. AutoScope Lens Motor Installation After you have installed the AutoScope lens motor, proceed with Mounting the Vision 110 (page 28). Vidikron Vision Model 110 Installation/Operation Manual... -
Page 41: Installing The Fixed Cinewide Base Plate (Vision 110/Cinewide)
To install the fixed CineWide base plate on a Vision 110/CineWide: Place the projector upside down on a blanket or other soft surface. Line up the mounting holes on the lens mount base plate with those on the bottom of the projector, directly below the primary lens (see Figure 3-9). -
Page 42: Mounting The Vision 110
For fixed installations, and for those that want the projector out of sight or have a limited space for projector and audience, you can invert the Vision 110 and suspend it from the ceiling using a specially-designed ceiling mount fixture. -
Page 43: Connections To The Vision 110
Proceed as follows to connect the Vision 110 to your video sources, external controller(s) – if present – and AC power. When connecting your equipment: • Turn off all equipment before making any connections. • Use the correct signal cables for each source. -
Page 44: Digital (Dtv) Rgb Or Component Video Connections (Hd1, Hd2)
DTV or Progressive Component (YPbPr) Source Figure 3-11. Digital (DTV) RGB or Component Video Connections (HD1, HD2) HD1 (RCA) (RCA) Vert Horiz Red/Pr Blue/Pb Green/Y DTV or Progressive Component (YPbPr) Source Vidikron Vision Model 110 Installation/Operation Manual WIRED REMO REMOTE... -
Page 45: Digital (Dtv) Rgb Or Component Video Connections (Hd3)
HD3 (VGA / Y-Pb-Pr) Y-Pb-Pr) (VGA Figure 3-12. Digital (DTV) RGB or Component Video Connections (HD3) Vidikron Vision Model 110 Installation/Operation Manual Green/Y Blue/Pb Red/Pr Horiz DTV or Progressive Component (YPbPr) Source Vert Installation... -
Page 46: Analog Rgb Connections
Installation Analog (Computer) RGB Connections: See Figure 3-13. HD3 (VGA / Y-Pb-Pr) Y-Pb-Pr) (VGA HD2 (BNC) (BNC) Vert Horiz Red/Pr Blue/Pb Figure 3-13. Analog RGB Connections Green/Y Vidikron Vision Model 110 Installation/Operation Manual Personal Computer... -
Page 47: S-Video And Composite Video Connections
S-Video/Composite Video Connections: See Figure 3-14. HD3 (VGA / Y-Pb-Pr) Y-Pb-Pr) (VGA Figure 3-14. S-Video and Composite Video Connections Vidikron Vision Model 110 Installation/Operation Manual DVD Player, VCR, Satellite Receiver, Laser Disc etc. Installation... -
Page 48: Rs-232 Controller Connection
Use a “null-modem” 9-pin RS-232 cable to connect a PC or home theater control/automation system (if present) to the RS-232/485 port on the Vision 110; see Figure 3-15. For more information about using this connection, refer to Serial Communications on page 63. -
Page 49: Connecting 12-Volt Trigger Outputs To External Equipment
If your Vision 110 is equipped with a CineWide with AutoScope system, connect the AutoScope lens motor to a 12-volt trigger output on the Vision 110; see Figure 3-16. Similarly connect other 12-volt trigger-activated equipment (such as retractable screens or screen masks) to the other trigger outputs. -
Page 50: Connecting An External Ir Receiver To The Vision 110
If infrared signals from the remote control cannot reach the projector due to excessive distance or obstructions such as walls or cabinet doors, you can connect an external IR receiver to the WIRED REMOTE input on the Vision 110 to extend the range of the remote control. See Figure 3-17. -
Page 51: Turning On The Power
16:9 Aspect Ratio By default, the Vision 110 is configured for a “floor/front” installation, in which the projector is installed upright and in front of the screen. If it is installed behind the screen and/or inverted, you must change the picture orientation. To do this: Press MENU. -
Page 52: Primary Lens Adjustments
To change the projected image position, use the cursor buttons to highlight “Left,” “Right,” “Up” or “Down” in the Lens menu. Then, press and hold the ENTER button to shift the image in that direction. Vidikron Vision Model 110 Installation/Operation Manual... -
Page 53: Installing And Adjusting The Cinewide Anamorphic Lens
Ensure that the image from the primary lens is perfectly centered on the screen. The Vision 110 Anamorphic lens mount kit consists of everything shown in Figure 3-18. Some components shipped with your projector may differ slightly from what is shown in these instructions. -
Page 54: Attaching The Anamorphic Lens To The Lens Adapter Ring
Anamorphic Lens Holder. The Yoke should be as close to the primary lens as possible. Attach the lens to the Lens Adapter Ring by threading it clockwise. Lens threads into ring Figure 3-19. Attaching the Anamorphic Lens to the Lens Adapter Ring Vidikron Vision Model 110 Installation/Operation Manual... -
Page 55: Configure Lens Motor Trigger
To save the trigger settings, press Select the Cinema aspect ratio to move the anamorphic lens into position, if it isn’t already. To do this, press CINEMA on the Vision 110 remote control (Figure 2-4), or press repeatedly with no menus visible on-screen. - Page 56 There may be some pincushion distortion even after the lens is properly Note adjusted, especially at shorter throw distances. If this is the case, Vidikron recommends that you slightly over-scan the image into the screen frame area to mask the distortion.
- Page 57 Then, angle the lens to even out any left-right pincushion distortion: Anamorphic Lens (Top View) Correct Position Wrong Position Once the proper lens angle has been set, firmly tighten the Yaw/X-Adjustment Levers to secure the lens in place. Vidikron Vision Model 110 Installation/Operation Manual...
- Page 58 Focus: Finally, rotate the Focus Ring on the anamorphic lens to fine-tune the optical focus. Correct Position Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 59: Operation
Then, to confirm your selection, press ENTER on the remote control (or SELECT on the projector rear panel). The Vision 110 OSD menus are arranged hierarchically, as shown in Figure 4-1. Depending on the selected input source and signal characteristics, some menu options may not be available. -
Page 60: Vision 110 Osd Menu Structure
Display Device - Configure Service HD Format Triggers Miscellaneous System Reset Restore Saved Settings Figure 4-1. Vision 110 OSD Menu Structure Note: IntelliWide 2.35 is available only on Vision 110 projectors equipped with the Calibration CineWide option (secondary anamorphic lens). -
Page 61: Main Menu
The currently-selected aspect ratio is indicated by a “ selected. The aspect ratio selection is automatically saved for each input and Note resolution. Vidikron Vision Model 110 Installation/Operation Manual ” to its left; in this example, 16:9 is Operation Main Menu Vision Model 110... - Page 62 4:3 Image on 16:9 Screen (Display) screen. 4:3 Image on 16:9 Screen with IntelliWide On a 2.35:1 screen, the image is 4:3 Image on centered between black bars on 2.35:1 Screen with IntelliWide either side. Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 63: Picture
IWIDE 2.35 Use the controls in the Picture Menu to calibrate your Vision 110 for optimum picture quality. The Vision 110 has been designed to incorporate setup and calibration standards established by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted,... -
Page 64: Typical Pluge Pattern For Adjusting Brightness
Operation Although it may be possible to obtain satisfactory picture quality using the naked eye and regular program material, Vidikron recommends using the following calibration tools for best results: • External test pattern source – Ovation Multimedia, Digital Video Essentials or AVIA test DVD or equivalent. -
Page 65: Typical Gray Bar Pattern For Adjusting Contrast
Color Saturation: On your external test pattern source, select a color bar pattern like the one shown in Figure 4-4. Figure 4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint Vidikron Vision Model 110 Installation/Operation Manual Operation... - Page 66 Like the brightness and contrast controls, the color and tint controls are Note interactive. A change to one may require a subtle change to the other in order to achieve the optimum setting. Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 67: Input Position
Height: Select Height from the Input Position menu to change the projected image height. Press to increase the height; press Vidikron Vision Model 110 Installation/Operation Manual to shift it to the left. to shift it downward. to decrease it. -
Page 68: Memory Presets
Use either setting in this case.) For each input, the Vision 110 lets you save image quality settings as presets that you can recall at a later time. You can create up to four presets per input and resolution. Use the ISF Presets menu to recall saved image presets, or to save image settings in the “Custom 1”... -
Page 69: Calibration
Calibration menu passcode. This makes it possible to restore the picture quality settings to what they were when the projector was installed, simply by recalling the “ISF Night” preset. Vidikron Vision Model 110 Installation/Operation Manual ISF Night Display Color... - Page 70 Splash Timer: Select Splash Timer from the Calibration menu to set the amount of time the Vidikron/ISF logo “splash” screen appears when you turn on the projector. The range is from 5 to 60 seconds, in one-second increments.
-
Page 71: Service
You can override this setting by using the OSD to select an HD input (refer to Input Source on page 47). For example, if you select COMP for HD2 here and the input signal changes to RGB, select “RGB BNC” from the Input Source menu to enable the Vision 110 to properly display that signal. - Page 72 Those triggers are then activated by selecting that aspect ratio. If your projector is equipped with the Vidikron CineWide with AutoScope system, assign at least one trigger output (the same one to which the lens motor is connected) to the Cinema and IntelliWide 2.35 aspect ratios.
-
Page 73: Maintenance And Troubleshooting
For lamp or filter replacement, please contact your nearest Vidikron authorized service center or Vidikron dealer. Do not attempt to replace the lamp yourself! The Vision 110 lamp is under high pressure. Handle it with great care at WARNING all times. Lamps may explode if dropped or mishandled. -
Page 74: Filter Replacement
Do not reuse filters. Insert the new filter with the pleats facing in and the foam-covered side facing out. Replace the filter access panel and tighten the screws to secure it. Vidikron Vision Model 110 Installation/Operation Manual Side Filter Access Panel... -
Page 75: Troubleshooting Tips
Table 5-1 provides some general guidelines for troubleshooting problems you may encounter with the Vision 110. If the suggested solutions fail to resolve the problem or if you encounter an issue not described here, please contact Vidikron Technical Support. Table 5-1. Troubleshooting Chart... - Page 76 Maintenance and Troubleshooting Notes: Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 77: Serial Communications
S-Video input, type SSRC 1<Enter>. • When you enter a valid command, the Vision 110 executes it. When you send an on/off, input selection, aspect ratio or image preset command, the Vision 110 also responds with an acknowledgment on the command line. - Page 78 Serial Communications Table 6-1 lists the serial commands supported by the Vision 110 and the responses it sends back to the control system or PC. Table 6-1. Serial Commands and Responses Command Description Turns projector off Turns projector on Display system firmware version information: >...
- Page 79 SISF 3 Menu Navigation Commands The following serial commands are meant to emulate buttons on the remote control or Vision 110 front panel. Each button has its own serial command, so effectively it is as if you were using the IR remote only you’ll be doing so via serial commands.
- Page 80 Serial Communications Notes: Vidikron Vision Model 110 Installation/Operation Manual...
-
Page 81: Specifications
Table 7-1 lists the Vision 110 specifications. Table 7-1. Vision 110 Specifications Projector Type: Digital Light Processing (DLP), 3-chip, 16:9 DMD Native Resolution: 1920 x 1080 (16:9) Aspect Ratios: 4:3, Letterbox, 16:9, IntelliWide, Cinema, IntelliWide 2.35 Video Standards: NTSC, NTSC 4.43, PAL B/G/H/I/M/N , SECAM... - Page 82 CSMS measurements. Industry-Standard Specifications These are typical projector brightness and contrast specifications found in most companies’ sales literature. Vidikron includes these measurements in its literature to allow for direct comparison with other manufacturers’ projectors. These measurements are typically taken at 9,000K to 13,000K to get expected performance data when the projector is used in professional, commercial and industrial displays.
-
Page 83: Vision 110 Dimensions
Figure 7-1 shows the Vision 110 dimensions (all dimensions are in inches). 23.55 30.29 9.00 36.32 35.41 32.49 30.41 29.66 29.08 23.97 22.90 20.22 15.97 11.72 10.74 7.01 Figure 7-1. Vision 110/CineWide with AutoScope Dimensions Vidikron Vision Model 110 Installation/Operation Manual 14.73... -
Page 84: Supported Timings
1360x768 60.00 1400x1050 1400x1050 60.00 60.00 75.00 1600x1200 1600x1200 60.00 1920x1200 1920x1200 60.00 Table 7-2 lists the signal types supported by each input on the Vision 110. Horizontal Pixel Frequency Frequency (MHz) (kHz) 31.469 25.175 37.861 31.500 37.500 31.500 43.269 36.000... - Page 85 – 59.94/60.00 PAL-B/G – 50.00 PAL-M – 59.94/60.00 PAL-N – 50.00 PAL-60 – 59.94/60.00 SECAM – 50.00 Vidikron Vision Model 110 Installation/Operation Manual Horizontal Pixel Frequency Frequency (MHz) (kHz) 15.734 13.500 31.469 27.000 15.625 14.750 31.250 29.000 37.500 75.250 45.000 74.250...
- Page 86 Specifications Notes: Vidikron Vision Model 110 Installation/Operation Manual...
- Page 88 020-0834-00 rev. B December 2007 Vidikron 2900 Faber Street Union City, CA 94587 510-324-5900 Fax 510-324-5905 1-888-4-VIDIKRON www.vidikron.com SE RI A L NUM BE R...
