Related Manuals for Vidikron Vision 120
Summary of Contents for Vidikron Vision 120
- Page 1 I N S T A L L A T I O N / O P E R A T I O N M A N U A L 1080p Digital Light Processing (DLP™) Projector Vision 120 Vision 120/CineWide™ Vision 120/CineWide™ with AutoScope™ VERSION 1.1...
-
Page 3: Two Year Limited Warranty
(6) months or 1000 hours, whichever comes first, from the effective date of delivery to the end user. In addition, Vidikron will provide a new or rebuilt replacement lamp for the lamp that fails due to defects in materials or workmanship for a period of six (6) months or 1000 hours, whichever comes first, from the effective date of delivery to the end user. -
Page 4: Copyright And Trademarks
IMPORTANT -- WARRANTY REGISTRATION: Please fill out and mail your warranty registration card. It is imperative that Vidikron knows how to reach you promptly if we should discover a safety problem or product update for which you must be notified. -
Page 5: Additional Information
ADDITIONAL INFORMATION: To locate the name and address of the nearest Vidikron Authorized Service Center, or for additional information about this Limited Warranty, please call or write: VIDIKRON PRODUCT INFORMATION RETAIN THIS INFORMATION FOR YOUR RECORDS _________________________________________________________ Model Purchased ____________________________________________________________________________________________________________... -
Page 6: Important Safety Instructions
Important Safety Instructions Thank you for your purchase of this quality Vidikron video projector! It has been designed to provide you with the quality of video that is expected in a home theater. For the best performance, please read this manual carefully as it is your guide through the menus and operation. -
Page 7: Compliance Information
Manufacturer’s Name: Vidikron, a subsidiary of Planar Systems, Inc. Manufacturer’s Address: 2900 Faber Street, Union City, CA 94587 hereby declares that the products Model Numbers: Vision 120, Vision 120/CineWide and Vision 120/CineWide with AutoScope conform with the provisions of: Council Directive 2004/108/EC on Electromagnetic Compatibility;... -
Page 8: Fcc Part
This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. viii Vidikron Vision Model 120 Installation/Operation Manual... -
Page 9: Table Of Contents
Using This Manual ... 2 Description, Features and Benefits ... 3 Key Features and Benefits... 3 Parts List ... 4 Vision 120 at a Glance ... 5 Vision 120 Rear Panel ... 6 VHD Controller Front Panel ... 8 VHD Controller Rear Panel ...10 Vision 120 Remote Control ...12... - Page 10 Table of Contents 4. Operation ... 49 Installing the Optional CineWide Lens Mount ...24 Installing the AutoScope Lens Motor (Vision 120/CineWide with AutoScope) ...25 Installing the Fixed CineWide Base Plate (Vision 120/CineWide)...29 Mounting the Vision 120 ...30 Floor Mounting (Upright) ...30 Ceiling Mounting (Inverted) ...30...
- Page 11 5. Maintenance and Troubleshooting ... 63 6. Serial Communications ... 67 7. Specifications ... 71 Vidikron Vision Model 120 Installation/Operation Manual Lamp Replacement ...63 Filter Replacement ...64 Troubleshooting Tips ...65 RS-232 Connection and Port Configuration ...67 Serial Command Syntax ...67 Vision 120 Specifications ...71...
- Page 12 Table of Contents Notes: Vidikron Vision Model 120 Installation/Operation Manual...
- Page 13 3-7. Vision 120 with Ceiling Mount Adapters/Projector Stands ....... 27...
- Page 14 List of Figures Notes: Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 15: Introduction
Vidikron has prepared this manual to help home theater installers and end users get the most out of the Vision 120. Vidikron has made every effort to ensure that this manual is accurate as of the date it was printed. However, because of ongoing product improvements and customer feedback, it may require updating from time to time. -
Page 16: Using This Manual
If you need... Information about obtaining service General information about the Vision Model 120 DLP Projector and VHD Controller Installation instructions First-time configuration instructions Advanced configuration instructions Troubleshooting tips Product specifications ... Turn to page: Vidikron Vision Model 120 Installation/Operation Manual... -
Page 17: Description, Features And Benefits
The Vision 120’s 16:9 native aspect ratio DMD array makes it ideal for widescreen viewing, while its 3-chip, 1920 x 1080 native resolution produces crisp, crystal clear high-definition images with richly saturated colors, deep black levels and natural, highly refined detail. -
Page 18: Parts List
➤ Parts List Your Vision 120 is shipped with the following items. If any items are missing or damaged, please contact your Vidikron dealer or Vidikron Customer Service at (888) 4VIDIKRON. • Vision Model 120 DLP Projector and VHD Controller •... -
Page 19: Exhaust Vents
Figure 2-1 shows the key Vision 120 components. Figure 2-1. Vision 120 Front/Bottom/Side View PRIMARY PROJECTION LENS VIDIKRON LOGO The logo can be rotated to match the projector orientation: inverted (ceiling-mounted) or upright. To rotate the logo, grip it at the sides, pull it away from the projector and rotate it 180 degrees. -
Page 20: Vision 120 Rear Panel
Lights orange to indicate that the projector is in standby mode. SOFT POWER BUTTON Press once to turn on the Vision 120. Press it again to put the projector into Standby mode. For a discrete on or off command, you can use the direct access buttons on the remote control (see Figure 2-5). -
Page 21: Service Port
Press SELECT to confirm your selection of a highlighted choice on the On-Screen Display (OSD). 15. MENU BUTTON Pressing the MENU button brings up the main Vision 120 menu. Also, if you are in an adjustment mode or function, pressing MENU brings the menu back one level. Vidikron Vision Model 120 Installation/Operation Manual... -
Page 22: Vhd Controller Front Panel
Use to direct-select aspect ratios or move the menu cursor down in the OSD. When no menu is present on-screen, the DOWN button toggles through the different aspect ratios, in this order: IntelliWide 2.35 - Cinema - IntelliWide - Letterbox - 4:3 - 16:9 Please check issue(s) Communication Error Vidikron Vision Model 120 Installation/Operation Manual... -
Page 23: Stand-By Led
Lights orange to indicate that the projector is in standby mode. 13. SOFT POWER BUTTON Press once to turn on the Vision 120. Press it again to put the projector into Standby mode. For a discrete on or off command, you can use the direct access buttons on the remote control (see Figure 2-5). -
Page 24: Vhd Controller Rear Panel
This is the main AC input fuse (5mm x 20mm, 500 mA, 250V slow-blow). MAIN POWER SWITCH Disconnects or applies power to the VHD Controller. DVI-DL (DUAL-LINK) OUTPUT (1080p) Connect this to the VHD Input at the rear of the Vision 120 (see Figure 2-2). SERVICE ONLY For future use. WIRED REMOTE Wired input from an external remote control or infrared receiver. -
Page 25: Composite Video Input
Five RCA-type connectors for either RGB or component high-definition sources (up to 1080p). The VHD Controller automatically detects the input signal resolution. For best results, do not run your DVD player in progressive mode. Vidikron Vision Model 120 Installation/Operation Manual Controls and Functions... -
Page 26: Vision 120 Remote Control
Controls and Functions Vision 120 Remote Control Figure 2-5 shows the Vision 120 remote control, and the paragraphs that follow describe its functionality. LIGHT S-VID INFO EXIT CONT PICTURE MEMORY CUST1 NIGHT ASPECT RATIO 16:9 CINEMA FOCUS FOCUS ZOOM ZOOM Figure 2-5. - Page 27 Picture Adjustment Buttons: BRT (Brightness) Press to adjust black level. CONT (Contrast) Press to adjust white level. COL (Color) Press to adjust color intensity. TNT (Tint) Press to adjust color hues. Vidikron Vision Model 120 Installation/Operation Manual Controls and Functions...
- Page 28 (enlarge) or the DOWN button to zoom out (reduce). When finished, press MENU or EXIT. LENS (Lens Shift) To adjust the lens position, press LENS. Then, press and hold the RIGHT, LEFT, UP or DOWN button. When finished, press MENU or EXIT. Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 29: Installation
• Ambient conditions may possibly impede the operation of the remote control. If this happens, point the remote control at the projector, and repeat the operation. Vidikron Vision Model 120 Installation/Operation Manual Remote Control Installation Notes on Batteries... -
Page 30: Quick Setup
Installation Quick Setup Table 3-1 gives a quick overview of the Vision 120 installation process. The sections following this one provide detailed instructions. Installation should be performed by a qualified custom video installation Note specialist. Table 3-1. Installation Overview Step... -
Page 31: Installation Considerations
Images may then appear washed out and less vibrant. Vidikron Vision Model 120 Installation/Operation Manual Considerations • Shares floor space with audience •... -
Page 32: Throw Distance
Throw Distance (TD) = Screen Width (w) x Lens Throw Ratio Figure 3-1. Estimating Throw Distance Table 3-3 lists the available lens options for the Vision 120 and their associated throw ratios. Table 3-3. Vision 120 Lens Options and Throw Ratios... -
Page 33: Vertical And Horizontal Position
Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example. Figure 3-3. Vertical Lens Shift (EXAMPLE ONLY) Vidikron Vision Model 120 Installation/Operation Manual Ceiling Lens Center... -
Page 34: Horizontal Lens Shift (Example Only)
Screen Width (W) Note: This is a general example of lens shift. Lenses vary in their shift capabilities. No particular lens or projector is used in this example. Figure 3-4. Horizontal Lens Shift (EXAMPLE ONLY) Vidikron Vision Model 120 Installation/Operation Manual... -
Page 35: Folded Optics
Table 3-4 lists the lens shift limits for each available Vision 120 lens, as percentages and absolute measurements with a 100 x 56 inch (1.78:1) screen. Table 3-4. Vision 120 Vertical and Horizontal Lens Shift Limits Lens Shift Limits, as Percentages of Screen Height or Width (Notes 1 and 2) -
Page 36: Other Considerations
The projection lens is shipped separately from the projector. To install it, proceed as follows: Using a 2.5-mm hex wrench, loosen the two hex screws holding the Projector Front Jewelry in place. Remove the jewelry. Vidikron Vision Model 120 Installation/Operation Manual... - Page 37 Make sure to route the wire harness in its original position and away Caution from the moving lens stages and Motor Assembly, to prevent unexpected disconnection or lens damage. Vidikron Vision Model 120 Installation/Operation Manual Installation...
-
Page 38: Installing The Optional Cinewide Lens Mount
Tighten the hex screws at the top and bottom of the jewelry to secure it. If you are installing a standard (non-CineWide) Vision 120, skip this step and proceed with Mounting the Vision 120 (page 30). If you are installing a Vision 120/CineWide, proceed with Installing the Fixed CineWide Base Plate (Vision 120/CineWide) (page 29). -
Page 39: Installing The Autoscope Lens Motor (Vision 120/Cinewide With Autoscope)
Figure 3-6 shows the Vision 120/CineWide with AutoScope motor assembly. Screw, Phillips Pan-Head, M6-1.0 x 12mm (14x) AutoScope Lens Motor Figure 3-6. Vision 120/CineWide with AutoScope Motor Assembly - Exploded View Vidikron Vision Model 120 Installation/Operation Manual CineWide with AutoScope Ceiling Mt. Adapter/ Projector Stand, Right CineWide with AutoScope Ceiling Mt. - Page 40 Using six (6) each of the supplied, M6 x 12mm Pan-Head Phillips screws (item #2), attach the AutoScope Ceiling Mount Adapters/Projector Stands (items #3 and #4) to the projector as shown in Figure 3-7. Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 41: Vision 120 With Ceiling Mount Adapters/Projector Stands
Installation Figure 3-7. Vision 120 with Ceiling Mount Adapters/Projector Stands DO NOT OVER-TIGHTEN THE SCREWS. Caution Vidikron Vision Model 120 Installation/Operation Manual... -
Page 42: Autoscope Lens Motor Installation
Secure the motor to the projector with the eight (8) remaining M6 x 12mm Pan-Head Phillips screws (item #2). Figure 3-8. AutoScope Lens Motor Installation After you have installed the AutoScope lens motor, proceed with Mounting the Vision 120 (page 30). Vidikron Vision Model 120 Installation/Operation Manual... -
Page 43: Installing The Fixed Cinewide Base Plate (Vision 120/Cinewide)
To install the fixed CineWide base plate on a Vision 120/CineWide: Place the projector upside down on a blanket or other soft surface. Line up the mounting holes on the lens mount base plate with those on the bottom of the projector, directly below the primary lens (see Figure 3-9). -
Page 44: Mounting The Vision 120
For fixed installations, and for those that want the projector out of sight or have a limited space for projector and audience, you can invert the Vision 120 and suspend it from the ceiling using a specially-designed ceiling mount fixture. -
Page 45: Connections To The Vision 120 And Vhd Controller
Proceed as follows to connect the VHD Controller to the Vision 120, your video sources, external controller(s) – if present – and AC power. When connecting your equipment: • Turn off all equipment before making any connections. • Use the correct signal cables for each source. -
Page 46: Connecting Source Components To The Vhd Controller
HD2 (BNC) Y / G Pb / B Pr / R HD3 (VGA / Y-Pb-Pr) HDMI Figure 3-11. HDMI Source Connections COMPOSITE S-VIDEO HDMI Source (HD-DVD/BD/DVD Player or HD Tuner with HDMI or DVI out) Vidikron Vision Model 120 Installation/Operation Manual... -
Page 47: Digital (Dtv) Rgb Or Component Video Connections (Hd1, Hd2)
B/Pb R/Pr DTV or Progressive Component (YPbPr) Source Figure 3-12. Digital (DTV) RGB or Component Video Connections (HD1, HD2) Vidikron Vision Model 120 Installation/Operation Manual HD2 (BNC) Y / G Pb / B Pr / R HD3 (VGA / Y-Pb-Pr) -
Page 48: Digital (Dtv) Rgb Or Component Video Connections (Hd3)
Y / G Pb / B Pr / R HD3 (VGA / Y-Pb-Pr) COMPOSITE S-VIDEO Green/Y Blue/Pb Red/Pr Horiz Vert DTV or Progressive Component (YPbPr) Source Figure 3-13. Digital (DTV) RGB or Component Video Connections (HD3) Vidikron Vision Model 120 Installation/Operation Manual... -
Page 49: Analog Rgb Connections
Analog (Computer) RGB Connections: See Figure 3-14. Green/Y Blue/Pb Red/Pr Horiz Vert Personal Computer HD2 (BNC) Y / G Pb / B Pr / R HD3 (VGA / Y-Pb-Pr) COMPOSITE S-VIDEO HDMI Figure 3-14. Analog RGB Connections Vidikron Vision Model 120 Installation/Operation Manual... -
Page 50: S-Video And Composite Video Connections
S-Video/Composite Video Connections: See Figure 3-15. HD2 (BNC) Y / G Pb / B Pr / R HD3 (VGA / Y-Pb-Pr) COMPOSITE HDMI DVD Player, VCR, Satellite Receiver, Laser Disc etc. Figure 3-15. S-Video and Composite Video Connections S-VIDEO Vidikron Vision Model 120 Installation/Operation Manual... -
Page 51: Rs-232 Controller Connection
RS-232 / 485 SYSTEM CONTROL INTERFACE to Automation/ Control System or PC Figure 3-16. RS-232 Control System Connection Vidikron Vision Model 120 Installation/Operation Manual Y / G Pb / B Pr / R TRIGG (none of the other pins are used) -
Page 52: Connecting 12-Volt Trigger Outputs To External Theater Equipment
Outputs to External Theater Equipment If your Vision 120 is equipped with a CineWide with AutoScope system, connect the AutoScope lens motor to a 12-volt trigger output on the VHD Controller; see Figure 3-17. Similarly connect other 12-volt trigger-activated equipment (such as retractable screens or screen masks) to the other trigger outputs. -
Page 53: Connecting An External Ir Receiver To The Vhd Controller
Figure 3-18. External IR Receiver Connection When an external IR receiver is connected to the wired IR input, the Note built-in IR sensor on the VHD Controller is disabled. Vidikron Vision Model 120 Installation/Operation Manual VHD Controller Rear Panel Y / G... -
Page 54: Connecting To Ac Power
Orientation Projector/VHD Controller: Plug the female end of one power cord into the AC receptacle on the rear of the Vision 120 (AC 100V ~ 240V). Then, connect the other end to your AC power source. Similarly connect the VHD Controller to a nearby AC outlet. -
Page 55: Primary Lens Adjustments
To change the projected image position, use the cursor buttons to highlight “Left,” “Right,” “Up” or “Down” in the Lens menu. Then, press and hold the ENTER button to shift the image in that direction. Vidikron Vision Model 120 Installation/Operation Manual 3.10 Primary Lens Adjustments... -
Page 56: Installing And Adjusting The Cinewide Anamorphic Lens
Ensure that the image from the primary lens is perfectly centered on the screen. The Vision 120 Anamorphic lens mount kit consists of everything shown in Figure 3-19. Some components shipped with your projector may differ slightly from what is shown in these instructions. -
Page 57: Attaching The Anamorphic Lens To The Lens Adapter Ring
Anamorphic Lens Holder. The Yoke should be as close to the primary lens as possible. Attach the lens to the Lens Adapter Ring by threading it clockwise. Lens threads into ring Figure 3-20. Attaching the Anamorphic Lens to the Lens Adapter Ring Vidikron Vision Model 120 Installation/Operation Manual Installation... -
Page 58: Configure Lens Motor Trigger
Too Far Left Too Far Right When the horizontal position is properly set, tighten the Yaw/X-Adjustment Levers to secure the lens in place. repeatedly to highlight “Save.” Then, press ENTER. Correct position Vidikron Vision Model 120 Installation/Operation Manual... - Page 59 There may be some pincushion distortion even after the lens is properly Note adjusted, especially at shorter throw distances. If this is the case, Vidikron recommends that you slightly over-scan the image into the screen frame area to mask the distortion.
- Page 60 Then, angle the lens to even out any left-right pincushion distortion: Anamorphic Lens (Top View) Correct Position Wrong Position Once the proper lens angle has been set, firmly tighten the Yaw/X-Adjustment Levers to secure the lens in place. Vidikron Vision Model 120 Installation/Operation Manual...
- Page 61 Focus: Finally, rotate the Focus Ring on the anamorphic lens to fine-tune the optical focus. Vidikron Vision Model 120 Installation/Operation Manual Correct Position Installation...
- Page 62 Installation Notes: Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 63: Operation
(or SELECT on the VHD Controller front panel or projector rear panel). The Vision 120 OSD menus are arranged hierarchically, as shown in Figure 4-1. Depending on the selected input source and signal characteristics, some menu options may not be available. -
Page 64: Vhd Controller Osd Menu Structure For Vision 120
Display Device - Configure Service HD Format Triggers Miscellaneous System Reset Restore Saved Settings Figure 4-1. VHD Controller OSD Menu Structure for Vision 120 Note: IntelliWide 2.35 is available only on Vision 120 projectors equipped with the Calibration CineWide option (secondary anamorphic lens). -
Page 65: Main Menu
The currently-selected aspect ratio is indicated by a “ selected. The aspect ratio selection is automatically saved for each input and Note resolution. Vidikron Vision Model 120 Installation/Operation Manual ” to its left; in this example, 16:9 is Operation Main Menu Vision Model 120... - Page 66 4:3 Image on 16:9 Screen (Display) screen. 4:3 Image on 16:9 Screen with IntelliWide On a 2.35:1 screen, the image is 4:3 Image on centered between black bars on 2.35:1 Screen with IntelliWide either side. Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 67: Picture
IWIDE 2.35 Use the controls in the Picture Menu to calibrate your Vision 120 for optimum picture quality. The Vision 120 has been designed to incorporate setup and calibration standards established by the Imaging Science Foundation (ISF). The ISF has developed carefully crafted,... -
Page 68: Typical Pluge Pattern For Adjusting Brightness
Operation Although it may be possible to obtain satisfactory picture quality using the naked eye and regular program material, Vidikron recommends using the following calibration tools for best results: • External test pattern source – Ovation Multimedia, Digital Video Essentials or AVIA test DVD or equivalent. -
Page 69: Typical Gray Bar Pattern For Adjusting Contrast
Color Saturation: On your external test pattern source, select a color bar pattern like the one shown in Figure 4-4. Figure 4-4. Typical Color Bar Pattern for Adjusting Color Saturation and Tint Vidikron Vision Model 120 Installation/Operation Manual Operation... - Page 70 Like the brightness and contrast controls, the color and tint controls are Note interactive. A change to one may require a subtle change to the other in order to achieve the optimum setting. Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 71: Input Position
Height: Select Height from the Input Position menu to change the projected image height. Press to increase the height; press Vidikron Vision Model 120 Installation/Operation Manual to shift it to the left. to shift it downward. to decrease it. -
Page 72: Memory Presets
Use either setting in this case.) For each input, the Vision 120 lets you save image quality settings as presets that you can recall at a later time. You can create up to four presets per input and resolution. Use the ISF Presets menu to recall saved image presets, or to save image settings in the “Custom 1”... -
Page 73: Calibration
Calibration menu passcode. This makes it possible to restore the picture quality settings to what they were when the projector was installed, simply by recalling the “ISF Night” preset. Vidikron Vision Model 120 Installation/Operation Manual ISF Night Display Color... - Page 74 Splash Timer: Select Splash Timer from the Calibration menu to set the amount of time the Vidikron/ISF logo “splash” screen appears when you turn on the projector. The range is from 5 to 60 seconds, in one-second increments.
-
Page 75: Service
You can override this setting by using the OSD to select an HD input (refer to Input Source on page 51). For example, if you select COMP for HD2 here and the input signal changes to RGB, select “RGB BNC” from the Input Source menu to enable the Vision 120 to properly display that signal. - Page 76 Those triggers are then activated by selecting that aspect ratio. If your projector is equipped with the Vidikron CineWide with AutoScope system, assign at least one trigger output (the same one to which the lens motor is connected) to the Cinema and IntelliWide 2.35 aspect ratios.
-
Page 77: Maintenance And Troubleshooting
For lamp or filter replacement, please contact your nearest Vidikron authorized service center or Vidikron dealer. Do not attempt to replace the lamp yourself! The Vision 120 lamp is under high pressure. Handle it with great care at WARNING all times. Lamps may explode if dropped or mishandled. -
Page 78: Filter Replacement
Do not reuse filters. Insert the new filter with the pleats facing in and the foam-covered side facing out. Replace the filter access panel and tighten the screws to secure it. Vidikron Vision Model 120 Installation/Operation Manual Side Filter Access Panel... -
Page 79: Troubleshooting Tips
Table 5-1 provides some general guidelines for troubleshooting problems you may encounter with the Vision 120. If the suggested solutions fail to resolve the problem or if you encounter an issue not described here, please contact Vidikron Technical Support. Table 5-1. Troubleshooting Chart... - Page 80 Maintenance and Troubleshooting Notes: Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 81: Serial Communications
• When the VHD Controller receives an OFF command, it will not acknowledge or execute any commands for approximately 90 seconds afterwards. This is to prevent hot re-strikes of the lamp, which can damage it. Vidikron Vision Model 120 Installation/Operation Manual Serial Communications RS-232 Connection and... - Page 82 Table 6-1. Serial Commands and Responses Command Description Turns projector off Turns projector on Display system firmware version information: > rev * Vidikron Gennum Scaler Board * * Rev 0.28 (T01) 05 Jan 2007 * File Name: Vidikron_Gennum.ncd Created: 21 Dec 2006 - 10:42:40 Device:...
- Page 83 Vidikron Vision Model 120 Installation/Operation Manual Table 6-1. Serial Commands and Responses (continued) Command Description Image Preset Commands Loads “ISF Night” image preset SISF 0 Loads “ISF Day” image preset SISF 1 Loads “Custom 1” image preset SISF 2 Loads “THX” image preset...
- Page 84 Serial Communications Notes: Vidikron Vision Model 120 Installation/Operation Manual...
-
Page 85: Specifications
Table 7-1 lists the Vision 120 specifications. Table 7-1. Vision 120 Specifications Projector Type: Digital Light Processing (DLP), 3-chip, 16:9 DMD Native Resolution: 1920 x 1080 (16:9) Aspect Ratios: Refer to Table 7-2 Video Standards: Refer to Table 7-2 DTV Compatibility:... - Page 86 CSMS measurements. Industry-Standard Specifications These are typical projector brightness and contrast specifications found in most companies’ sales literature. Vidikron includes these measurements in its literature to allow for direct comparison with other manufacturers’ projectors. These measurements are typically taken at 9,000K to 13,000K to get expected performance data when the projector is used in professional, commercial and industrial displays.
-
Page 87: Vhd Controller Specifications
Limited Warranty: Two (2) years parts and labor from the date of delivery to the end user. Specifications are subject to change without notice. Vidikron Vision Model 120 Installation/Operation Manual 15-pin D-Sub connector Discrete infrared remote Serial commands via RS-232 interface... -
Page 88: Vision 120 Dimensions
Specifications Vision 120 Dimensions Figure 7-1 shows the Vision 120 dimensions (all dimensions are in inches). 23.55 30.29 9.00 36.32 35.41 32.49 30.41 29.66 29.08 23.97 22.90 20.22 15.97 11.72 10.74 7.01 Figure 7-1. Vision 120/CineWide with AutoScope Dimensions 14.73 12.44... -
Page 89: Supported Timings
Table 7-3 lists the signal types supported by each input on the Vision 120. Table 7-3. Supported Signal Timings by Input Refresh Format Resolution Rate (Hz) 640x480 640x480 60.00 72.00 75.00 85.00 800x600 800x600 60.00 72.00 75.00 85.00 1024x768 1024x768 60.00... - Page 90 √ √ √ √ √ √ √ √ √ √ √ √ √ √ – – – Vidikron Vision Model 120 Installation/Operation Manual Composite S-Video √ – √ – – – – – – – – √ √ √ √...
- Page 92 020-0844-00 rev. B December 2007 Vidikron 2900 Faber Street Union City, CA 94587 510-324-5900 Fax 510-324-5905 1-888-4-VIDIKRON www.vidikron.com SE RI A L NUM BE R...
