Summary of Contents for VPI ST-WLHDMI-L-30M
- Page 1 Aurora,Ohio 44202 VIDEO 1275 Danner Drive Tel: 330-562-2622 Fax: 330-562-1999 PRODUCTS www.vpi.us INCORPORATED ST-WLHDMI-L-30M ST-WLHDMI-R-30M Local and Remote HDMI Wireless Extender Installation and Operation Manual Local and Remote Units are each sold separately MAN007 Rev Date 010/28/2009...
- Page 2 COPYRIGHT Copyright © 2009 by Video Products Incorporated. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without the prior written consent of Video Products Incorporated, 1275 Danner Drive, Aurora, Ohio 44202 CHANGES The material in this manual is for information only and is subject to change without notice.
-
Page 3: Table Of Contents
Introduction... 1 Materials ... 2 Operation Controls and Functions ... 3 Local Unit ... 3 Front Panel ... 3 Side Panel... 4 Remote Unit... 4 Front Panel ... 4 Side Panel... 5 Remote Control... 5 Connections... 6 Technical Specifications... 7 Troubleshooting... -
Page 4: Introduction
VPI WIRELESS HDMI EXTENDER INTRODUCTION The ST-WLHDMI-L/R-30M wireless HDMI transmitter (Local Unit) and receiver (Remote Unit) uses 5GHz radio technology to deliver uncompressed high definition video and audio up to 98 ft. (30 m) in open field, while maintaining superb, wire-equivalent quality and robustness. -
Page 5: Materials
HDMI-xx-MM cables for connecting Local Unit and Remote Unit to video source and display (xx = 3,6,9,14,20,30,50, 75, or 100 feet) Cables can be purchased from Video Products Inc by calling (800) 626-7801 in the US and Canada or (330) 562-2622 (worldwide). -
Page 6: Operation Controls And Functions
6. Link LED: When the devices are searching for each other, the Link LED will flash rapidly. While a link is being established, the Link LED will flash slowly. Once the link is established the Link LED stays ON solid. 7. Input indicator: The LED will illuminate to indicate which input source is selected. ST-WLHDMI-L-30M Local Unit- Front Panel Power Link HDMI1... -
Page 7: Side Panel
5. Link LED: When the devices are searching for each other, the Link LED will flash rapidly. While a link is being established, the Link LED will flash slowly. Once a link is established the Link LED will stay ON solid. ST-WLHDMI-L-30M Local Unit- Side Panel HDMI2... -
Page 8: Side Panel
VPI WIRELESS HDMI EXTENDER Side Panel 6. HDMI Input: For connecting to the HDMI input of your display. 7. Power: Plug the 5VDC power supply into this unit and connect the adapter to AC wall outlet. Remote Control 1. Power: Press to turn ON/OFF the device (Local Unit or Remote Unit) 2. -
Page 9: Connections
VPI WIRELESS HDMI EXTENDER CONNECTIONS ST-WLHDMI-L-30M Local Unit PS3, DVD Player, HDMI-xx-MM Blu-Ray ST-WLHDMI-L-30M HDMI-xx-MM Transmitter CWHDI-TX Transmitter PS3, DVD Player, Blu-Ray HDMI Type A HDMI-A-Male Male (3,6,14,20,30,50,75 and 100 foot cables available) UNICAST Configuration ST-WLHDMI-R-30M Remote Unit BROADCAST Configuration... -
Page 10: Technical Specifications
CE, RoHS TROUBLESHOOTING Each and every piece of every product produced by Video Products Inc is 100% tested to exacting specifications. We make every effort to insure trouble-free installation and operation of our products. If problems are experienced while installing this product, please look over the troubleshooting chart below to see if perhaps we can answer any questions that arise. -
Page 11: Warranty Information
VPI WIRELESS HDMI EXTENDER WARRANTY INFORMATION The warranty period on this product (parts and labor) is one (1) year from the date of purchase. Please contact Video Products Incorporated at (800) 626-7801 (800-RGB-TECH) or (330) 562-2622 or visit our website at regarding repairs and/or returns.
