Recommended CameraLink Cable
Cable length
1m
2m
3m
5m
2. DCIN/SYNC connector
PIN NO.
Signal
1
GND (+12V)
2
+12V
3
4
5
6
Connector (camera side) : SANWOO SHN-10-12 (RPCB) or equivalent
Plug (matching cable plug : HR10A-10P-12S(01) HIROSE or equivalent
(Note) Please do not unplug and insert cable (camera cable) with a power supplied to a camera.
Please do not input any signal to N.U. pin because machine may break down.
Model name
C-101SCL
C-201SCL
C-301SCL
C-501SCL
PIN NO.
7
8
GND
9
N.C.
10
GND
11
N.C.
12
Signal
TRIG
GND
N.C.
FLASH / VD OUT
N.C.
GND
1
9
2
8
10
3
7
11
12
4
6
5
6
