OWNER'S MANUAL
This owner's manual for CDX-35,
CDX-35C and CDX-35P.
VESTAX CORPORATION
1-18-6 Wakabayashi, Setagaya-ku, Tokyo 154-0023 Japan
Phone:03-3412-7011 Fax: 03-3412-7013
VESTAX America
2750C 29th Ave Suite. 115 Hollywood. Fl33020
Phone:303-766-5269 Fax: 303-766-2196
VESTAX ( Europe ) Ltd.
Unit 5 Riverwey Industrial Park Alton, Hampshire GU34 2QL England
Phone:44-1420-83000 Fax: 44-1420-80040
Advertisement
Table of Contents
Related Manuals for Vestax CDX-35
Summary of Contents for Vestax CDX-35
- Page 1 OWNER'S MANUAL This owner's manual for CDX-35, CDX-35C and CDX-35P. VESTAX CORPORATION 1-18-6 Wakabayashi, Setagaya-ku, Tokyo 154-0023 Japan Phone:03-3412-7011 Fax: 03-3412-7013 VESTAX America 2750C 29th Ave Suite. 115 Hollywood. Fl33020 Phone:303-766-5269 Fax: 303-766-2196 VESTAX ( Europe ) Ltd. Unit 5 Riverwey Industrial Park Alton, Hampshire GU34 2QL England...
-
Page 2: Table Of Contents
CONGRATULATIONS ! Thank You for purchasing the VESTAX CDX-35, CD PLAYER. Please read this owner's manual carefully before you start to use, so that you will fully understand all of the special features and enjoy the full use of the product. -
Page 3: F C C
N O T E This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 4: Important Safe Guards
I M P O R T A N T S A F E G U A R D S READ BEFORE OPERATING EQUIPMENT T h i s p r o d u c t w a s d e s i g n e d a n d m a n u f a c t u r e d t o m e e t s t r i c t q u a l i t y a n d s a f e t y s t a n d a r d s . -
Page 5: F E A T U R E S
The CDX-35 produces a short loop of sound around the laser pick up, just like any other CD player. The difference with the CDX-35 is that the length can be adjusted from 0.013 to 3 seconds. Therefore, exactly one beat, half bar or full bar can be monitored in a loop and the loop can be moved around. -
Page 6: B E F O R E U S E
B E F O R E U S E Notes on the Compact Disc (CD) The surface which is glossy like a ralnbow is the front side of the CD, and the surface where the label information is printed is the back side. Unlike conventional analog disk turntables, the CD player reads information from the disc by applying laser beam, in place of a stylus, on the front surface. -
Page 7: Control And Function
CONTROL AND FUNCTION CONTROLLER UNIT PLAYER UNIT 12 6... -
Page 8: Controller Unit
CONTROLLER UNIT 18 19 16... - Page 9 ① PLAY/PAUSE KEY Each press of the PLAY/PAUSE button cause the operation to change from play to pause or from pause to play. ② CUE KEY Pressing cue button returns the CD to the last set "CUE" point and pauses it. The CUE point is either the position at which "PLAY"...
- Page 10 ⑬ LOOP START Used for setting a start loop point and new cue point during play. ⑭ LOOP END Used for setting the end loop point and and releasing loop action. ⑮ RELOOP/EXIT This button is for cancel and return loop play . During the loop play , press the RELOOP/EXIT button.
- Page 11 DISPLAY MAIN PLAYER Shows the player (A or B) that the unit is selected. TRACK Shows the track that the unit is playing. TIME (MIN/SEC/FRM) Shows the minutes/seconds/frames elapsed or remaining depending on mode settings. 1 second = 75 frames PITCH Shows present value of pitch.
- Page 12 [1] TIME MODE Shows the time information of disc. In this mode, RING DISPLAY is working together time counter (TIME DISPLAY ). 1. TRACK REMAIN TIME [2] DISK OPERATION MODE Shows the operation of disc. In this mode, RING DISPLAY rotates in various speed and direction. Speed is changed by playback speed.
-
Page 13: Player Unit
PLAYER UNIT ●FRONT PANEL SECTION POWER SWITCH ⃝ Turn on and turn off the machine from this button. The unit should always be shut down with this button first before any external power is removed. ⃝ DISK TRAY Place your CD in here. ⃝... - Page 14 Plug your control cable for second player unit. ⃝ CD OUT JACK (RCA) Connect your CD player to your mixer from this line level output. VESTAX CORPORATION MODEL NO.CDX-35 CLASS1 LASER PRODUCT KLASSE1 LASER PRODUCT 230V∼ 50Hz 18W I.H.T. IEC825 CAUTION：...
-
Page 15: Techniques For Dj Play
TECHNIQUES FOR DJ PLAY CUEING OPERATIONS (setting a cue point) [1] USE PAUSE MONITOR FUNCTION PAUSE ① CUE POINT direction of play back ② adjust the length of monitoring sound ③ ④⑤⑥ the cue point set During playback, when the disc comes to the ①... - Page 16 [2] USE THE SEARCH DIAL ① PAUSE CUE POINT direction of play back ②③ ④⑤ the cue point set During playback, press the PLAY/PAUSE ① button. PLAY/PAUSE Rotate the jog dial to search for desired ② location. (Playback speed is changing from 0% to +/- 300% by rotating speed.) ③...
- Page 17 [3] Clear the cue point memory When you press " STOP " button twice, the cue point memory is cleared. ① ② Turn off power of CDX-35, the cue point memory is cleared too. ① Set the cue point. (See the " cueing operation") Press the "MEMO"...
-
Page 18: Loop Play
LOOP PLAY [1] DESIGNATE A LOOP ①② set loop-in point direction of playback ③④ set loop MAXIMUM 20 second out point LOOP back ⑤ LOOP [2] CHANGE THE LOOP END POINT LOOP adjust end pointby pressing A or B button During the loop play, press the "NEXT"... - Page 19 MASTERTEMPO PITCH INDICATER Shows position of memorized tempo by LED. Please refer to following example. ⃝ ⃝ PLAYSELECT Adjust the tempo （ex.tempo：-6％） （ex. player A） ⃝ Change to the Aside. Present fader position：0％ Memorized tempo：-6% （ex. player A） Pitch indicater lights on minus side The pitch indicater shows which side of present fader position memorized tempo is set.
-
Page 20: Connection
CONNECTION One Player and One Controller Controller CDX-35C Two Player and Controller Controller CDX-35C Connection for another EQUIPMENTS Controller CDX-35C INPUT MAIN SPERKER Power amplifier [Vestax PT-X1000A] CHANNEL CHANNEL MINI MINI Sperker cable Player CDX-35P Player CDX-35P CONTROLLER CONTROLLER CD OUT... -
Page 21: Specification
Signal To Noise Ratio Channel Separation CD OUT HEADPHONE LEVEL 115V/230VAC, 18W 0.8kg(Controller), 2.4kg(Player) 210x49x165(Controller) 190x82x257(Player) Owner's manual (CDX-35, CDX-35C, CDX-35P) Connector cable (CDX-35, CDX-35P) 16bit linear 44.1kHz 8times over sampling 16Mbit,10sec CIRC Less than 0.011% 20Hz∼20KHz More than 96dB... - Page 22 Vestax Corporation 443 S 851250...
