DS-CAM-88c / DS-CAM-120c
TECHNICAL REFERENCE MANUAL
DS-CAM-88c / DS-CAM-120c V20-1






1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DS-CAM-88c and is the answer not in the manual?

Questions and answers

Related Manuals for DEWESOFT DS-CAM-88c

Summary of Contents for DEWESOFT DS-CAM-88c

  • Page 1   DS-CAM-88c / DS-CAM-120c  TECHNICAL REFERENCE MANUAL  DS-CAM-88c / DS-CAM-120c V20-1              1 ...

  • Page 2: Table Of Contents

    8.2. General Safety Instructions 27  8.2.1. Environmental Considerations 27  8.2.2. Product End-of-Life Handling 27  8.2.3. System and Components Recycling 27  8.2.4. General safety and hazard warnings for all Dewesoft systems 28  9. Documentation Version 31  DS-CAM-88c / DS-CAM-120c V20-1 2/31   ...

  • Page 3: About This Document

    It gives you important information about the subject.  Please read carefully!    Hint   It gives you a hint or provides additional information about a subject.      Example   Gives you an example of a specific subject.        DS-CAM-88c / DS-CAM-120c V20-1 3/31   ...

  • Page 4: Key Features

    The benefits are: high speed data transfer rates up to 1GBit/s (based on 1000Base-T) connectible to every  standard GigE Ethernet port and cable lengths up to 100m.   Dewesoft uses Smartek GigE SDK for communication with cameras that support GigE Vision standard.  IMPORTANT : For best performance we recommended using a SSD for ...

  • Page 5: Technical Data

    Screw mount GigE RJ45  Screw mount GigE RJ45  Connectors  EIAJ (Hirose) 12 pin  EIAJ (Hirose) 12 pin  CE  CE  FCC  FCC  RoHS  Conformity  RoHS  GigE Vision  GigE Vision  GenICam (PoE IEEE  GenICam (PoE IEEE 802.3at)  802.3at)  DS-CAM-88c / DS-CAM-120c V20-1 5/31   ...

  • Page 6: Connections

    On the rear side of the camera there are two connectors. The 12pin HIROSE connector (matching part:  Hirose HR10A10P-12S(73)) contains the power, trigger and other digital pins. Ethernet connector pinout  according to the standard.  DS-CAM-88c / DS-CAM-120c V20-1 6/31   ...

  • Page 7: Power/Trigger Connector Pinout

    GND (for Power and RS232)  2  Power (+8...+30 V DC)  3  -  4  Camera In 1 (TRIGGER)  5  -  6  Camera Out 1 (open emiter, max. 20 mA)  7  Camera In GND  8  RxD (RS232)  DS-CAM-88c / DS-CAM-120c V20-1 7/31   ...

  • Page 8: Sirius Connection Example

    Note: Even if the camera is connected, synching to other SIRIUS devices is still possible, because there  are different pins used on the SYNC port for triggering/synching.    Illustration 4: SIRIUS SBOX with 1 SIRIUS slice connected to the DS-CAM-88c (or DS-CAM-120c) (per cable  H12f-L1B7m-L00B4m-3M)  DS-CAM-88c / DS-CAM-120c V20-1...

  • Page 9: Connecting To Existing Dewetron Systems

    Connect EXT_CLK1 (pin 17) to the CLK of the Lemo 00 connector of the camera (pin 3).   ● Connect DGND (pin 37) to GND of the Lemo 00 connector (pin 4)   ● Set the pin EXT_CLK1 to “Video” in DEWESoft hardware setup  ●   Illustration 5: DEWETRON Orion-1622-100 DSUB 37 pinout ...

  • Page 10: Connecting Multiple Cameras

    DS-CAM-88c / DS-CAM-120c  TECHNICAL REFERENCE MANUAL        Illustration 6: Clockout setup of EXT_CLK1 pin in DEWESoft  4.2.4. Connecting multiple cameras    Illustration 7: CAM-BOX2  DS-CAM-88c / DS-CAM-120c V20-1 10/31   ...
  • Page 11 ● DS-CAM-600!)   Power and Sync distribution for up to 4 cameras.   ● Small dimensions: 115 x 62 mm (front) and 135 mm deep  ●   Illustration 8: CAM-BOX2 pinout    Illustration 9: CAM-BOX2 pinout  DS-CAM-88c / DS-CAM-120c V20-1 11/31   ...

  • Page 12: Connections Overview

    DS-CAM-88c / DS-CAM-120c  TECHNICAL REFERENCE MANUAL      4.2.5. Connections Overview    DS-CAM-88c / DS-CAM-120c V20-1 12/31   ...

  • Page 13: Benchmarks

    SBOX: 128GB SSD -> max 190 MByte/s write rate   CPU: Intel Core i7 QM57; 2.0GHz; 4GB RAM   camera(s) clocked by SIRIUS   DEWESoft X1 SP7 b358 GigEVisionSDK Version 2.7.0.1   GigE Camera driver v3.5 (Plugin)   storing data to file, video buffer stable around 0..1%  ...

  • Page 14: Installation

    5. Installation  5.1. DEWESoft Fullinstaller  Usually all the drivers come with the DEWESoft Fullinstaller, if you select the option “GigE camera driver”  during installation. To check if the drivers are installed, go to Settings → Hardware setup → Video and see ...

  • Page 15: Manual Update (Camera Driver And Dewesoft)

    GigE Camera drivers. (Zip file includes  Smartek GigE SDK 2.7.0.1 and DEWESoft GigECamera driver 3.5) latest DEWESoftX version  5.2.1. Step-by-step instruction  Install Smartek_GigEVisionSDK Note that you must be an administrator, not just a user with admin ...
  • Page 16 Connect the camera to the PC via Ethernet cable and Power/Trigger-cable. See connection example..  The DS-CAM-88c/120c supports DHCP, so just set your computer's IP address to automatic and wait  until the IP is assigned. To test if the camera is working you can run Smartek GigEVisionClient. By ...
  • Page 17 Illustration 14: Dewesoft: Hardware setup > Video: finds GigE camera(s).  For the “File types for storing” you can choose between:   “DVI”, which is uncompressed DEWESoft video format (takes a lot of disk space, ~35 Mbyte / s /  ● camera @ 640x480 and 120fps, but no video size limit) – or  ...
  • Page 18 This is done with the “USB Firmware  Upgrade Utility” from http://www.dewesoft.com/download. Also the  Firmware File can be downloaded there. Close DEWESoft, start the Upgrade  Tool, select “DEWESoft USB” interface and firmware file and Start. After  finished, it is very important to unplug power AND USB cable and reboot the ...
  • Page 19 Enter key.      Illustration 17: Camera settings in DEWESoft.  Use the “Advanced Settings”, if you want to change specific parameters of the camera, such as the  custom resolution (AOI, area of interest) for instance. ...
  • Page 20 DS-CAM-88c / DS-CAM-120c  TECHNICAL REFERENCE MANUAL        Illustration 18: Advanced settings      DS-CAM-88c / DS-CAM-120c V20-1 20/31   ...

  • Page 21: Faq

    Is the Trigger cable connected?   ● Try decreasing the Shutter value   ● Check in hardware setup if the DEWESoft USB device is set to Master or Standalone   ● Disable Trigger in hardware setup and check if it’s working in free-run mode (cable problem?)  ●...
  • Page 22 Then start the GigEVisionClient from C:\Program Files\Smartek\GigEVisionSDK\bin\Win64  Cameras not working in DEWESoft  If you followed the step-by-step installation procedure, but still the camera is not working in DEWESoft,  you can try to copy the used dlls manually:   Copy the 32-bit dlls from  ...
  • Page 23 -> right-mouse-click on LAN connection -> Properties -> Configure -> Advanced  -> Jumbo Frame -> set to highest value (e.g. 9kB MTU))  Also an overloaded DEWESoft setup (many displays, e.g. high resolution FFT instruments) will  ● take system power. Try at first only with camera video instruments.  ...
  • Page 24 DS-CAM-88c / DS-CAM-120c  TECHNICAL REFERENCE MANUAL        Illustration 20: IP address problem          DS-CAM-88c / DS-CAM-120c V20-1 24/31   ...

  • Page 25: Warranty Information

      7.2. Support  Dewesoft has a team of people ready to assist you if you have any questions or any technical difficulties  regarding the system. For any support please contact your local distributor first or Dewesoft directly.   ...

  • Page 26: Printing History

    When used in text representing the company, product or  technology name, the ® sign is not used. The Dewesoft triangle logo is a registered trademark but the ®  sign is not used in the visual representation of the triangle logo. ...

  • Page 27: Safety Instructions

    Failure to comply with these precautions or with specific warnings elsewhere in  this manual violates safety standards of design, manufacture, and intended use of the product.  Dewesoft GmbH assumes no liability for the customer’s failure to comply with these requirements.    ...

  • Page 28: General Safety And Hazard Warnings For All Dewesoft Systems

    REMOVE POWER and do not use the product until the safe  operation can be verified by service-trained personnel. If necessary, return the product to  Dewesoft sales and service office for service and repair to ensure that safety features are  maintained. ...
  • Page 29 This product has left the factory in safety-related flawlessness and in proper condition. In order to  ● maintain this condition and guarantee safety use, the user has to consider the security advice  and warnings in this manual.  DS-CAM-88c / DS-CAM-120c V20-1 29/31   ...
  • Page 30 Devices and systems according to IEC 61508 or IEC 61511 which are considered as “operationally  well-tried”, are excluded from the scope of IEC 61326-3-1.    Fire-alarm and safety-alarm systems, intended for the protection of buildings, are excluded from the  scope of IEC 61326-3-1        DS-CAM-88c / DS-CAM-120c V20-1 30/31   ...

  • Page 31: Documentation Version

    Added FAQ “GigE plugin is not found in DEWESoft”  1.0.9  26.11.13  Added FAQ “Maximum frame rate @ VGA resolution only 36 fps”  1.1.0  22.12.14  Merge of DS-CAM-88c and DS-CAM-120c into one manual added new  benchmarks for DS-CAM-88c    DS-CAM-88c / DS-CAM-120c V20-1 31/31   ...
