Decorative Gas Appliances for
Installation inSolid-Fuel Burning Fireplaces.
If the information in this manual is not followed exactly, a fire or explosion may result, causing property
damage, injury, or loss of life.
—
Do not store or use gasoline or other flamma-
ble vapors and liquids in the vicinity of this or
any other appliance.
—
WHAT TO DO IF YOU SMELL GAS
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not
use any phone in your building.
•
Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
•
If you cannot reach your gas supplier, call
the fire department.
INSTALLER PLEASE NOTE:
DO NOT begin installation of this gas logset
until all instructions have been read and
understood.
CARBON MONOXIDE POISONING MAY LEAD TO DEATH
When used without fresh air, vent-free log sets may give off carbon monoxide, an odorless, poisonous gas.
Some people - pregnant women, people with heart or lung disease, anemia, or persons under the influence of alcohol, and
persons at high altitudes are more affected by carbon monoxide than others.
Early signs of carbon monoxide poisoning resemble the flu - headache, dizziness, and/or nausea. If you have these signs, the
heater may not be installed or working properly. GET FRESH AIR AT ONCE! Have the heater serviced before using it again.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Installation and Operation Instructions for
Vent-Free Gas Log Sets*
Models: VL18, VL21 and VL24 (Natural Gas)
VL18LP, VL21LP and VL24LP (Propane)
W A R N I N G
W A R N I N G
Tested and listed to
ANSI Z21.11.2b-2004, Unvented Heaters, and
Z21.60b-2004; CGA 2.26b-2004
ATTENTION
Installation and service must be performed by
a qualified agency, individual, firm, corpora-
tion, or company, experienced in the installa-
tion, repair, and servicing of this type of gas
appliance. Do not modify, alter or tamper with
any part of this heater, control, or logs.
This appliance may be installed in an after-
market, permanently located, manufactured
(mobile) home, where not prohibited by local
codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This ap-
pliance is not convertible for use with other
gases.
*These logsets are not for exterior use.
C E RT I F I E D
20002538 1/07 Rev. 8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Majestic VL18
Summary of Contents for Majestic VL18
- Page 1 Installation and Operation Instructions for Vent-Free Gas Log Sets* Models: VL18, VL21 and VL24 (Natural Gas) Decorative Gas Appliances for Installation inSolid-Fuel Burning Fireplaces. If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, injury, or loss of life.
-
Page 2: General Information
In order to assure a safe and effective instal- lation, only a qualified service person who is familiar with the building codes and installation techniques appropriate to your area may install and service this appliance. The Logsets have been designed and tested to operate safely when installed according to the installation instructions con- tained in this manual. -
Page 3: Installation Requirements
The fireplace must meet the minimum dimensions listed below. (Fig. 1) Do not install the logset if the fireplace does not meet these minimums. Min. Fireplace Dimensions Logset Front Rear Width Width 18” VL18 21” 16¹⁄₂” 21” VL21 Natural 21” 18¹⁄₂” 24” VL24 25”... -
Page 4: Installation Precautions
Planning Planning the installation is an important first step. It will save time and money later in the actual installation. In planning the installation, consider: • Where the heater will be located. • All components needed to complete the installation. •... -
Page 5: Provide For Adequate Ventilation
Fresh Air Requirements for Combustion and Ventilation W A R N I N G This heater must have fresh air for proper opera- tion. If it does not, poor fuel combustion could result. Read the following instructions to ensure proper fresh air supply for this and other fuel- burning appliances in your home. - Page 6 4. Compare the maximum BTU/hour rating the space can support with the total BTU/hour used by the appli- ances. Example: 76,800 BTU/hour the space can support 80,000 BTU/hour used by appliances In this example, the maximum BTU/hour that the space can support is less than the total used by the applianc- es.
-
Page 7: Installation Instructions
WARNING: Do not allow fans to blow directly into the fireplace. Avoid any drafts that alter burner flame patterns. WARNING: Do not use a blower insert, heat ex- changer insert or other accessory not approved for use with this gas logset. Do not burn solid fuels in a fireplace where an unvented gas room heater or logset is installed. -
Page 8: Damper Stop Installation
Damper Stop Installation When installing a decorative gas appliance in a fire- place, some local codes require a damper stop be added so the damper will not close completely. The CFM Corporation damper stop is designed so the damper can be locked in the closed position, and still allow a vent for the pilot gasses. -
Page 9: Gas Line Connection
Without Hood Noncombustible Material Standoff 20” 2¹⁄₂” MC656-2 Mantel Trim Front 3¹⁄₄” - VL18 Edge of 5¹⁄₄” - VL21, VL24 Grate 4¹⁄₂” Min. MC656-1 mantel clear w/o hood 3/26/99 djt MC656-3 Connect the appliance to the gas line using fittings and aluminum tubing provided. -
Page 10: Positioning The Logs
Check the inlet pressure to the appliance, to ensure that it is as shown in the table on page 3. The minimum is for the purpose of input adjustment. The pressure is controlled by the regulator and should be checked at the pressure test point located in the control valve body. - Page 11 Locator Pins LG100 Fig. 7 VL18 log placement. LG100 VL18 logset 3/26/99 changed burner 4/3/00 djt Locator Pins Locator Pin Fig. 8 VL21 log placement. LG102 VL21 logset 3/31/99 modified burner/grate 4/3/00 djt 20002538 Locator Locator Pins Grate Locator Pin Fig.
-
Page 12: For Your Safety Read Before Lighting
Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- ally. -
Page 13: Inspecting The Venting System
• Chassis • Gas Orifice • Grate Assembly • VL18 - four (4) decorative gas logs VL21 - five (5) decorative gas logs VL24 - six (6) decorative gas logs • Gas Valve Assembly • Pressure Regulator Most of these components require only occasional checkup and cleaning. - Page 14 VL18 VL21 LF101 VL18 flames 3/29/99 changed valve 4/13/00 djt 6” - 8” Ap- prox. LF103 VL21 flames VL24 3/31/99 changed valve 4/14/00 djt 6” - 8” Ap- prox. Fig. 13 Typical flame patterns. LF105 VL24 flames 4/1/99 changed valve 4/14/00 djt 7”...
-
Page 15: Troubleshooting
With proper installation and maintenance, your new Gas Appliance should provide years of trouble-free ser- vice. If you do experience a problem, this guide will assist a CERTIFIED SERVICE PERSON in the diag- nosis of problems and the corrective action to be taken. Symptom Pilot will not light with piezo ignitor or match... - Page 16 16a,b CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. VL18/21/24 Standard Vent Free Gas Logs Ref. Description Complete Log Set Top Side Logs (2) Top Center Log...
- Page 17 VL18/21/24 Standard Vent Free Gas Logs Ref. Description Burner Assembly - LP Copreci Valve Nut (15mm) Valve Control Knob Extension Knob 10a. Gas Valve - Copreci - Natural 10b. Gas Valve - Copreci - LP 11a. Gas Regulator - Natural 11b.
- Page 18 The following accessories are available from your CFM Corporation dealer. Should you need additional information beyond what your dealer can furnish, contact CFM Corporation, 410 Admiral Blvd. Mississauga, Ontario, Canada L5T 2N6, Attention: Technical Service. Accessory Hood AC100 AC100 FIREPLACE HOOD 3/29/99 DJT Accessories Description...
- Page 19 LIMITED 2/20 YEAR WARRANTY For Majestic Fireplaces Decorative Gas Appliances CFM Corporation extends the warranties specified in paragraphs A and B below with respect to its Vermont Castings Decorative Gas Appliances (the “Gas Appliance”), including CFM Corporation supplied accessories and components referred to in those paragraphs, subject to the following conditions and limitations: (1) These warranties are extended only to the Gas Ap-...
- Page 20 CFM Corporation 410 Admiral Blvd. • Mississauga, Ontario, Canada L5T 2N6 800-668-5323 • www.cfmcorp.com © CFM Corporation...
