INSTALLER / CONSUMER
SAFETY INFORMATION
PLEASE READ THIS MANUAL
BEFORE INSTALLING AND
USING APPLIANCE
WARNING!
IF THE INFORMATION IN THIS
MANUAL IS NOT FOLLOWED
EXACTLY, AN ELECTRICAL SHOCK
OR FIRE MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY OR LOSS OF LIFE.
FOR YOUR SAFETY
Service must be performed by a qual-
ified service agency.
DO NOT STORE OR USE
GASOLINE OR OTHER
FLAMMABLE VAPORS OR
LIQUIDS IN THE VICINITY OF
THIS OR ANY OTHER
APPLIANCE.
C
US
www.cfmcorp.com
Electric Fireplace
Model:
Installation Instructions and
CFM Corporation
2695 Meadowvale Boulevard
Mississauga, Ontario L5N 8A3 Canada
(800) 668-5323
HEF22
HEF26
HEF33
HEF36
Homeowners Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HEF22 and is the answer not in the manual?

Questions and answers

Summary of Contents for CFM HEF22

  • Page 1 GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. Mississauga, Ontario L5N 8A3 Canada www.cfmcorp.com Electric Fireplace Model: Installation Instructions and Homeowners Manual CFM Corporation 2695 Meadowvale Boulevard (800) 668-5323 HEF22 HEF26 HEF33 HEF36...
  • Page 2: Table Of Contents

    PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS Thank you and congratulations on your purchase of a CFM Home Products electric fireplace. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. Installation Instructions General .
  • Page 3: Installation Instructions

    1. Read all instructions before using this appliance. 2. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes and curtains at least 3 feet (914mm) from the front of this appliance.
  • Page 4: Fireplace Dimensions

    20” (508 mm) 11 ” (292 mm) 22” (559 mm) 21 ” (540 mm) 15” (381 mm) Fireplace Dimensions HEF22 HEF26 27 ” (699 mm) 25 ” (641 mm) 26” (660 mm) 24 ” (622 mm) 11 ” (292 mm) 18”...
  • Page 5: Electrical Connection

    This instruction is intended as a guide for replacing the power cord supplied with Models HEF22/26/33/36 electric fireplace with direct (hard) wiring. NOTE: When direct wiring this appliance, it must be connected to a 15 Amp dedicated circuit breaker or fuse in the electrical panel of the dwelling.
  • Page 6: Service Instructions

    WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electrical shock or personal injury. Replacing Front Cover Access to heater/fan 1. Turn off power to the unit. 2. Let fireplace cool if it has been operating. 3.
  • Page 7: Replacing The Light Bulbs

    4. Locate two (2) screws that hold the refractory (brick patterned) bracket together with the ember bed. (Fig. 5) (Not applicable to HEF22) 5. Remove those two (2) screws using an appropriate screwdriver. One screw is located on either side of the unit.
  • Page 8: Electrical Wiring Diagram

    AVERTISSEMENT: Debrancher la source d’alimentation avant le service. Electrical Wiring Diagram BLUE WHITE BLACK WHITE LIGHT RETURN LIGHT NEUTRAL COMM. HEATER RETURN MOTOR LIMIT SWITCH BLUE HEATER BLACK CIRCUIT BOARD GROUND MOTOR LINE NEUTRAL NOTE: HEF22/26 Units have only 2 light bulbs POWER CORD 10006946...
  • Page 9: Operating Instructions

    All of the fireplace control functions can be accessed in two (2) ways: • Using a multifunction remote control unit • Using touchpad control panel, located in the lower right-hand corner of the fireplace behind the door front or fixed front (depending on the model). Remote control unit has all the controls required to operate any feature on the unit.
  • Page 10: Replacement Parts

    216mm [8 1/2"] (DISTANCE BETWEEN TWO SOCKETS) CFM Home Products reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. HEF22/26/33/36 Electric Fireplace Ref. Description 1. Logset 2. Ember Lava Rock 3.
  • Page 11 HEF22/26/33/36 Electric Fireplace Ref. Description 7. DC Motor 8. Glass Operable Door Assembly 9. Folding Door 10. Glass Door Assembly 11. Heater/Fan Assembly 12. Socket w/Wire Assembly 13. Power Cord 14. Flame Generator Assembly 15. Screen Diffuser (not shown) 10006946...
  • Page 12: Year Warranty

    BASIC WARRANTY: CFM Home Products (hereinafter referred to collectively as the "Company") warrants that your new electric fireplace is free from manufacturing and material defects for a peri- od of one year from date of installation, subject to the fol- lowing conditions and limitations.

This manual is also suitable for:

Hef26Hef33Hef36
