ASSEMBLY INSTRUCTIONS
RiverRidge
®
6-Bin Storage Cabinet
ITEM#: 16-007 ESPRESSO WITH BROWN BINS
ITEM#: 16-008 ESPRESSO WITH GRAY BINS
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken in
unpacking and assembling this item to keep small parts away from children.
WARNING
SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don't use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.
Advertisement
Related Manuals for RiverRidge 16-007
Summary of Contents for RiverRidge 16-007
- Page 1 ASSEMBLY INSTRUCTIONS RiverRidge ® 6-Bin Storage Cabinet ITEM#: 16-007 ESPRESSO WITH BROWN BINS ITEM#: 16-008 ESPRESSO WITH GRAY BINS ADULT ASSEMBLY REQUIRED This product requires assembly by an adult because of small parts. Care should be taken in unpacking and assembling this item to keep small parts away from children.
- Page 2 THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS. IF LOADED WITH MORE THAN 25 POUNDS PER SHELF THIS MAY CAUSE DAMAGE TO THE SHELF AND MAY CAUSE SERIOUS INJURY OR DEATH.
-
Page 3: Parts List
PARTS LIST... - Page 4 TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED) THE USE OF POWER SCREWDRIVER IS NOT RECOMMENDED...
- Page 5 STEP 1 1. Insert 4 short wood dowels (4) into dowel holes on bottom board (A). 2. Attach 2 divider panels (B) to bottom board (A) by inserting short wood dowels (4) into wood dowel holes on divider panels (B). STEP 2 1.
- Page 6 STEP 3 1. Insert 4 long wood dowels (3) into dowel holes on divider panels (B). 2. Attach shelf (D) to divider panels (B) by inserting wood dowels through dowels holes on shelf (D). STEP 4 1. Insert 4 short wood dowels (4) into dowel holes on left side panel (E). 2.
- Page 7 STEP 5 1. Insert 4 short wood dowels (4) into dowel holes on right side panel (F). 2. Screw in 2 cam bolts (1) into pre-drilled holes on right side panel (F). 3. Attach right side panel (F) to bottom board (A), shelf (D) and decorative panel (C) by inserting cam bolts (1) and short wood dowels (4) into cam lock holes and short wood dowel holes on bottom board (A), shelf (D) and decorative panel (C).
- Page 8 STEP 7 1. Insert 4 short wood dowels (4) into dowel holes on bottom of top board (G). 2. Screw in 4 cam bolts (1) into pre-threaded holes on bottom of top board (G). 3. Attach top board (G) to left side panel (E), right side panel (F) and divider panels (B) by inserting cam bolts (1) and short wood dowels (4) into cam lock holes and dowel holes on left side panel (E), right side panel (F) and divider panels (B).
- Page 9 STEP 9 1. Attach 1 bracket (6) to back of assembled cabinet by inserting 1 wood screw (5) through hole on bracket (6) and tighten into top board (G). 2. According to height of bracket (6) drill hole on wall and insert plastic anchor (7) into hole on wall.
- Page 10 STEP 11 1. Take bottom board out from folded storage bin (I). 2. Open folded storage bin and put bottom board into storage bin (I) making sure cloth tab is facing up. 3. Repeat steps 1 and 2 to assemble 5 more bins. STEP 12 1.
- Page 11 Cabinet! Thank you for purchasing this RiverRidge ® Home item. We hope you enjoy it and consider purchasing other RiverRidge items. ® To order replacement parts at no cost to you, email customer.service@ssi-rr.com, call 1-(844)-223-5201 or order parts online at www.riverridgehome.com RiverRidge ®...
