CFM A052041 Assembly And Owner's Manual

Portable gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Formerly:
Assembly and

Owners manual

Model A052041
2004 Series
Portable
Gas Gr ill
ASSEMBLER / INSTALLER:
Leave these instructions with the consumer
CONSUMER / USER:
Read all of these instructions and keep them in a safe place for future reference.
FOR YOUR SAFETY
If you smell gas:
1
Shut o gas to the appliance.
2
Extinguish any open ame.
3
Open lid.
4
If odor continues, immediately call
your gas supplier or re department.
Now:
®
.
FOR YOUR SAFETY
1
Do not store or use gasoline or other
ammable vapors and liquids in the
vicinity of this or any other appliance.
2
An unconnected liquid propane
cylinder should not be stored in the
vicinity of this or any other appliance.
CFM Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A052041 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CFM A052041

Summary of Contents for CFM A052041

  • Page 1: Owners Manual

    Formerly: Assembly and Owners manual Model A052041 2004 Series Portable Gas Gr ill ASSEMBLER / INSTALLER: Leave these instructions with the consumer CONSUMER / USER: Read all of these instructions and keep them in a safe place for future reference.

  • Page 2: Table Of Contents

    Table of Contents Chapter One - INSTALLATION Necessary Information Choosing a Safe Location Portable L.P. Gas Grills Important Features of the Series 4000 LP Gas Grill L.P. Gas Dealer Instructions Chapter Two - ASSEMBLY INSTRUCTIONS Identifying Parts Attach Pillar to Grill Bottom Assemble Base to Pillar Install X-Brace Install the Side Tables...

  • Page 3: Chapter One - Installation

    Model A052041 Series Installation Necessary Information to Safely Use a Gas Grill. The gas fuel used by this product is highly flammable and must be used in a responsible and cautious manner. It is your responsibility to assemble, operate, and maintain your gas barbecue grill properly.

  • Page 4: Portable L.p. Gas Grills

    Do not store spare cylinders near grill. • The ventilation openings of the cylinder enclosure must be kept free and clear from other debris. 6. Do Not store a spare L.P. gas cylinder under or near this appliance. • Do not store an L.P. cylinder in a build- ing, garage or any other enclosed area.

  • Page 5: Gas Supply Cylinder

    The L.P. FUEL SUPPLY SYSTEM An L.P. gas grill requires a fuel delivery sys- tem made up of an L.P gas supply cylinder, a fuel regulator with hose and a gas-control valve. Dual Burner Fuel-Control Valve Type 1 Fuel Regulator Valve Orifice The L.P.

  • Page 6: Gas Cylinder Specifications

    L.P. GAS CYLINDER SPECIFICATIONS Any L.P. gas-supply cylinder used with this grill must be approximately 12 inches diameter and 18 inches high. The maxi- mum fuel capacity must be 20 pounds of propane. Full-cylinder weight should be approximately 38 pounds (43.7 lbs. nominal water capacity).

  • Page 7: Important Features Of The Series 4000 Lp Gas Grill

    Remove the X-Brace only when installing an L.P. gas supply cylinder. Rear view of Series A052041 grill with the heat shield, gaskets, collar assembly. Rear view of Series A052041 grill with the X-...

  • Page 8: Take These Instructions To The L.p. Gas Dealer

    Take These Instructions to the L.P. Gas Dealer. When using a cylinder exchange, be sure the exchanged cylinder is a Type 1 cylinder; a 510 POL cylinder will not fit a Type 1 regulator. 1 L.P. G ILLING AND URGING DANGER! Purging and filling of L.P.

  • Page 9: Chapter Two - Assembly Instructions

    Model A052041 Series Assembly Instructions Chapter Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3. You may want to place an old towel or cloth at the assembly site to prevent nuts and bolts from becoming lost.

  • Page 10: Identifying Parts

    Assembly Instructions • Identify the Grill Parts Locate these parts: warming rack (1) cooking grid (1) ceramic briquettes ( 1 package ) rock grate (1) left side table (1) right side table (1) base (1) master hardware bag (1) consisting of: (1) "A"...

  • Page 11: Attach Pillar To Grill Bottom

    Assembly Instructions • Attach the Pillar to Grill Bottom. tools needed: ⁄ " open-end wrench flat-blade screwdriver Locate these parts: collar assembly front control knobs Use hardware bag “B”: back hinge strut HINT: For the first portion of the assembly you will be assembling the grill bottom, pillar and base up- side-down.
  • Page 12 pillar bottom fuel supply hose w/ regulator gas control valve ends burner venturi tubes collar grill bottom back back hinge strut...

  • Page 13: Assemble Base To Pillar

    Assembly Instructions • Assemble Base to Pillar tools needed: ⁄ " open-end wrench ⁄ " open-end wrench Locate this part: front locking casters back back base ( 1 ) shown right- 1. Lock the pre-assembled casters on side up base by pushing down on the latch. 2.
  • Page 14 base back pillar black lead wires heat shield bottom casting back ignitor unit...

  • Page 15: Install X-Brace

    Assembly Instructions • Install X-Brace. No tools needed. Locate this part: 1 Now with the help of an top bent assistant carefully turn the ends grill assembly right-side-up. IMPORTANT: Inspect beneath the grill bottom to check that the control-valve ends are still inside the burner venturi tubes.
  • Page 16 ATTENTION PRODUCT ASSEMBLER: Install the X-brace retainer wire across the back of the pillar for warranty validation. 3. Position the wire ends “A” and “B” firmly into the pillar corners behind the bolt heads and against the base. (See Lower Detail.) 4.

  • Page 17: Install The Side Tables

    Assembly Instructions • Install the Side Tables. tools needed: 3/8" open-end wrench 7/16" open-end wrench Locate these parts: left side table assembly ( 1 ) right side table assembly ( 1 ) 1. Insert four 3/4" bolts through holes in the support brackets of the right side table assembly.
  • Page 18 3. Insert four 3/4" bolts through holes in the support brackets of the left side table assembly. 4. Attach the left side table to the four holes located in the left side of the grill bottom using the locking hex nuts provided. HINT: Preformed hooks included on the right side table assembly may be used to keep cooking utensils (not included) at hand.

  • Page 19: Assemble Grill Lid

    Assembly Instructions • Assemble the Grill Lid tools needed: 7/16" open-end wrench flat-blade screwdriver Locate these parts: handle ( 1 ) handle standoff ( 2 ) grill lid ( 1 ) 1. Position the back of the lid so that the rear holes are in line with the hinge struts on the back of the grill bottom.
  • Page 20 3. Hold the lid to align the hinge holes. 4. Insert a hinge pin through the hinge hole in the lid and into the hole in the bottom hinge strut. 5. After the hinge pin is in place, insert a hair pin through the hole of the hinge pin to secure it.

  • Page 21: Installing The Internal Parts

    Assembly Instructions • Installing the Internal Grill Parts. No tools are needed. Locate these parts: rock grate ( 1 ) ceramic briquettes ( 1 box ) cooking grid ( 1 ) warming rack ( 1 ) 1. Place the single rock grate into the grill bottom.
  • Page 22 4. Set the porcelain coated cooking grid on the front and back ledges formed inside the grill bottom for a level cooking surface. 5. Set the warming rack onto the back of the cooking grid. The grill assembly is now complete. 3.

  • Page 23: The Great Outdoors Grill Company

    Model 4000 Series Replacement Parts Replacement parts are available direct from our warehouse. Some components are not available preassembled and may be ordered separately. For convenience, the following parts list is provided along with a representation of the items listed. Charges for replacement parts and shipping may apply.
  • Page 24 Breakdown of Preassembled Components Bottom/Burner Assembly quantity description Bottom/Burner Assembly consisting of: Cast Iron Burner Venturi Tube w/gasket AZ000507 #8-32 x 7/16" Screw Bottom Grill Casting Collar Heat Shield Forward Gasket Side Gasket 1/4 x 20 x 1 1/4” bolt Speed Nuts Pillar Assembly Pillar Assembly...
