Installation Instructions and Homeowner's Manual
WARNING! IF THE INFORMATION IN THIS MANUAL IS NOT FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.
®
C
US
410 Admiral Blvd. • Mississauga, Ontario, Canada. L5T2N6 • 905-670-7777
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER
The Vermont Castings Majestic Products Company
FOR YOUR SAFETY
OR USE GASOLINE OR OTHER
FLAMMABLE VAPORS OR LIQUIDS
IN THE VICINITY OF THIS OR ANY
The Vermont Castings
Majestic Products Company
www.majesticproduts.com / www.vermontcastings.com
ADDISON
Freestanding
Electric
Stove Models:
ACSB
ACSG
ACSM
DO NOT STORE
OTHER APPLIANCE.
10003646
11/01 Rev. 1
1
Advertisement
Table of Contents
Related Manuals for Vermont Castings ACSG
Summary of Contents for Vermont Castings ACSG
-
Page 1: For Your Safety
INSTALLER: DO NOT DISCARD THIS MANUAL - LEAVE FOR HOMEOWNER The Vermont Castings Majestic Products Company ADDISON Freestanding Electric Stove Models: ACSB ACSG ACSM FOR YOUR SAFETY DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPORS OR LIQUIDS IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. -
Page 2: Table Of Contents
The Vermont Castings Majestic Products Company PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS Thank you and congratulations on your purchase of a VERMONT CASTINGS fireplace. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible electric shock, fire hazard and will void the warranty. Installation Instructions ... -
Page 3: Installation Instructions
INSTALLATION INSTRUCTIONS Read all instructions before using this appliance. This appliance is hot when in use. To avoid burns, do not let bare skin touch hot surfaces. If provided, use handles when moving this appliance. Keep combustible materials,such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (1 m.) from the front of this appliance. -
Page 4: Fireplace Dimensions
The Vermont Castings Majestic Products Company FIREPLACE DIMENSIONS Width of Stove Top Width at Legs Depth at Legs Depth at Apron Depth at Stove Top Total Height 565 mm 22-1/4 in 600 mm 23-3/8 in 390 mm 15-3/8 in 430 mm 17 in 400 mm 15-3/4 in... -
Page 5: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES Back...0”/0 mm Sides...0”/0 mm Floor...0”/0 mm Top...12”/305 mm HEARTH A hearth is not mandatory but it is recommended for aesthetic purposes. We recommend a non-combustible hearth which does not obstruct heater openings. ELECTRICAL SPECIFICATIONS Voltage...120VAC/60Hz Total Amps...11.9 Amps Total Watts...1430 Watts Heater Ratings... -
Page 6: Service Instructions
The Vermont Castings Majestic Products Company SERVICE INSTRUCTIONS WARNING: Disconnect power before attempting any maintenance or cleaning to reduce the risk of fire, electrical shock or personal injury FIREBOX REMOVAL Unplug the electrical supply to the unit. Let the fireplace cool if it has been operating. Move the fireplace away from wall to gain access to the rear of the unit. -
Page 7: Electrical Wiring Diagram
ELECTRICAL WIRING DIAGRAM Any electrical repairs or rewiring of this unit should be carried out by a licensed electrician in accordance with national and local codes. If repairing or replacing any electricial component or wiring, the original wire routing, color coding and securing locations must be followed. -
Page 8: Replacement Parts List
The Vermont Castings Majestic Products Company REPLACEMENT PARTS LIST Item # Part Description Log Set Fan/Heater Asembly Flame Generator Motor-120 Volt AC w/Terminal Cord Power 16/3 HPN w/Terminals ON/OFF Switch Heater Control (Thermostat) Heater Control Knob Door Glass, with gasket (not shown) Flame Generator Assembly Light filter (Ember Bed) (not shown) Light Diffuser (rear screen) (not shown) -
Page 9: Door Glass Replacement Parts And Intallation
DOOR GLASS REPLACEMENT INSTRUCTIONS 1. Unplug the electrical supply to the unit. 2. Let the fireplace cool if it has been operating. 3. Move the fireplace away from the wall to gain access to the rear of the unit. 4. Locate the firebox mounting brackets on the side of the firebox.
