euroshield 1
Synthesizer + Effects Development Board for Eurorack
Upper Pot
Lower Pot
MIDI Input
Audio In 1
Audio In 2
System Requirements:
- Teensy Development Board ver.
3.0 up to 3.6. Ver 3.2 is
recommended.
- PC or Mac for running the
development tools and
programming the Teensy module.
- Eurorack compatible case with
power and 8HP available.
- A USB A to microB USB cable to
connect the Teensy to your
computer.
Join the community at forum.1010music.com.
LEDs
Teensy Board
(not included)
MIDI Output
Audio Out 1
Audio Out 2
Download
Documentation
Visit the Forum
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for 1010music euroshield 1
Summary of Contents for 1010music euroshield 1
- Page 1 - PC or Mac for running the development tools and programming the Teensy module. - Eurorack compatible case with power and 8HP available. - A USB A to microB USB cable to connect the Teensy to your computer. Join the community at forum.1010music.com.
- Page 2 Lower Pot Input Range: 0 to 1023 Audio CODEC TX Same as PJRC audio shield Audio CODEC LRCLK Same as PJRC audio shield 3.3V Used by Euroshield AGND Not connected Power to Teensy +5V supplied by euroshield Download Documentation at https://1010music.com/shielddocs...
