- Page 1 Strata Enabled NCV6357 EVB User Guide © Semiconductor Component Industries, LLC, 2019 Publication Order Number: August, 2019 – Rev. 0 Contact your local Sales Representative...
- Page 2 Strata Enabled NCV6357 EVB Table of Contents INTRODUCTION ..................................3 Features..................................... 3 Applications ....................................3 USER GUIDE ....................................4 Hardware Setup ..................................4 User Interface ................................... 4 http://onsemi.com...
- Page 3 Strata Enabled NCV6357 EVB Introduction The Strata Enabled NCV6357 EVB provides an easy to use evaluation board within the Strata Development Environment for the NCV6357 configurable 5A step down converter. Through Strata, the developer can access datasheets, BOMs, schematics, and other collateral they may need.
- Page 4 User Interface in Strata. Hardware Setup The hardware required for using the Strata Enabled NCV6357 EVB are a computer (with Windows), a power supply, and a load. Follow the steps below. 1. Plug the power supply into the input of the board using the banana plugs J9 and J11. Do not apply over 5.5V to the input because this will break the board.
- Page 5 Strata Enabled NCV6357 EVB 2. The app will automatically detect the device that is plugged in and will bring up the UI for the board that is plugged in. 3. The view that comes up is the basic view, which offers basic telemetry, an enable switch for enabling/disabling the switcher, and a voltage select switch that will switch between the two programmed output voltages.
- Page 6 LIMITATIONS OF LIABILITY: ON Semiconductor shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if ON Semiconductor is advised of the possibility of such damages. In no event shall ON Semiconductor’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
