  • Page 1 VX-10 Owner's Manual Audio/Video Subwoofer...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS RISK OF ELECTRIC SHOCK Caution: To reduce the risk of electric shock, do not remove cover (or back). parts inside. Refer servicing to qualified service personnel. The lighting flash with arrowhead symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"...

  • Page 3: Wichtige Sicherheitshinweise

    WICHTIGE SICHERHEITSHINWEISE GEFÄHRLICHE SPANNUNG Vorsicht: Zur Vermeidung von Gefahr durch elektrischen Schlag, Deckel (oder Rückwand) nicht abnehmen. Produkt enthält keine Anwenderteile. Reparatur und Wartung nur von qualifiziertem Fachpersonal vornehmen lassen. Das Blitzsymbol dient als Hinweis auf unisolierte „gefährliche Spannungen“ innerhalb des Gehäuses, deren Werte eine Berührungsgefahr für den Menschen darstellen können.

  • Page 4: Importantes Consignes De Securite

    IMPORTANTES CONSIGNES DE SECURITE Risque d’électrocution Attention: Afin d’éviter tout risque d’électrocution, ne pas enlever le boitier (ou partie arrière de l’enceinte). Aucune pièce ne doit être manipulée par l’utilisateur. Pour tout entretien, vous référer à un personnel de service qualifié. Le symbol de l’éclair avec la flèche sert à...
  • Page 5 Congratulations! Congratulations on your purchase of a Velodyne subwoofer system. This system represents the state of the art in home audio reproduction and will provide you with years of listening pleasure when properly cared for. Read and follow this instruction manual to insure safe and proper system connection and operation.

  • Page 6: Product Features

    Product Features • 10" (8.5" piston diameter) subwoofer with 2.0" high-temp voice coil and 40 ounce motor structure • Adjustable (50 to 200Hz) low-pass crossover • Line-level (RCA) inputs • Speaker-level inputs and outputs with spring loaded terminals • Signal sensing auto turn on/off •...

  • Page 7: Installation

    The VX-10 is magnetically shielded to reduce the amount of stray magnetic energy emitted from the speaker's motor structure. This greatly increases flexibility when placing the unit close to video monitors as there is very little stray magnetism.
  • Page 8 Low-pass crossover - 50 to 200Hz All inputs sum the left and right channels together, with the resulting signal passing through an adjustable low-pass crossover before being amplified. The crossover control allows you to adjust the upper limit of the subwoofer's frequency response from 50 to 200Hz.

  • Page 9: Subwoofer Outputs

    Speaker Line-level Connections When installed in this fashion the satellite speakers will be crossed over at 80Hz. This removes the lower bass from your amplifier and speakers, enabling them to do a better job reproducing high frequencies. By utilizing this method you will have a bi-amplified system, gaining improved power and headroom for your system.

  • Page 10: Low-Pass Crossover

    Operational References SPEAKER LEVEL INPUT terminals Connect these input terminals to the speaker output terminals of your amplifier or receiver. SPEAKER LEVEL OUTPUT terminals The speaker-level signal to the front speakers is output from these terminals. LINE INPUT jacks Connect these jacks to the LINE OUT jacks of the amplifier. LOW-PASS CROSSOVER Use this knob to select the high-frequency range at which you wish to cut-off the signal to the subwoofer.

  • Page 11: Speaker-Level Connection

    Speaker-level Connection Connect your Velodyne subwoofer directly to your receiver or integrated amplifier. Your receiver or amplifier will not notice the additional load of the subwoofer due to the high input impedance. Caution!!! To avoid damage to your main amplifier, be sure to maintain correct polarity when making all connections.
  • Page 12 Figure 2a. Line-level subwoofer connection diagram.
  • Page 13 Figure 2b. Speaker-level subwoofer connection diagram.

  • Page 14: Protection Circuitry

    Protection Circuitry Your new subwoofer is equipped with circuitry to provide maximum performance with greatest reliability. The unit is protected against: Overheating the amplifier. Excessive drop in power line voltage. If either of the above should happen, you should reduce the volume setting or shut the unit off until normal operating conditions return.
  • Page 15 Speaker Power Supply Power consumption Cabinet (H,W,D) Weight (approx.) Specifications are subject to change without notice. Thank you for purchasing a Velodyne VX-10 Subwoofer! VX-10 Bass-reflex with built-in power amplifier 36Hz - 120Hz (+/- 3dB) 50-200Hz (variable) 150 Watt (dynamic) 0°...

  • Page 16: Warranty Statement

    WARRANTY STATEMENT VELODYNE ACOUSTICS, Inc. ("VELODYNE") warrants all powered subwoofers for a period of two years, and full range/satellite speakers for a period of five years. All VELODYNE products have a warranty from the date of purchase against defects in materials and workmanship subject to the following conditions:...
  • Page 17 Other Velodyne Subwoofer Products: CHT Series CHT-8 CHT-10 CHT-12 CHT-15 CHT Front Row System Deco System Deco System Deco Satellites SPL Series SPL-800 SPL-1000 SPL-1200 SPL-523 Satellites HGS Series II HGS-10 HGS-12 HGS-15 THX Ultra 2 HGS-18 THX Ultra 2...
  • Page 18 NOTES...
  • Page 19 NOTES...
  • Page 20 "How do they get this kind of bass out of such a tiny box? Deep, tight, tuneful and loud enough to rattle pictures on the wall--this is serious subwoofing." -Robert Deutsch Stereophile Guide to Home Theater/September 1998 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax 408.779.9208 service fax...
