Labels

1-800-466-6385 • www.guardianfall.com
Trench Box Anchor
Part #: 15192
Prior to use, read and understand
all instructions provided at time of
shipment from manufacturer.
Compliant with all OSHA 1910, OSHA
1926 Subpart M, ANSI Z359.1-2007,
and ANSI A10.32-2012 regulations.
Date of Manufacture:
Materials: galvanized steel.
Capacity range: 130-420 lbs.
(including all equipment).
Structure must withstand
minimum load of 5,000 lbs.
Suitable for Fall Arrest and
Restraint applications.
ONLY make connections to Trench Box
Anchor Mast. NEVER connect to
guardrails or any other
component of this system.
All connections must be selected and
deemed compatible with the Trench Box
Anchor System by a Competent Person.
Install guardrail posts with rungs
facing AWAY from fall hazard.
Guardrails must be 2" x 4" or 2" x 6"
lumber, or compatible snap-on metal
rails. Lumber guardrails must
overlap minimum 12"
Ensure toprail is 42" (+/- 3")
above work surface.
Maximum spacing of Trench Box
Anchor assemblies: 10'.
90073 (Rev. B)
!
WARNING
MAXIMUM 1 connection per anchor mast.
NEVER climb or lean on guardrails.
11
Prior to use, read and understand all instructions
provided at time of shipment from manufacturer.
Trench Box
Guardrail Receiver
Compliant with all OSHA 1910 and 1926 Subpart M regulations.
Part #: 15193
Install guardrail posts with rungs facing AWAY from fall hazard.
Date of Manufacture:
Ensure toprail is 42" (+/- 3") above work surface.
Materials: Guardrails must be 2"x4" or 2"x6" lumber, or compatible
galvanized steel. snap-on rails. Lumber guardrails must overlap minimum 12".
Maximum spacing of Trench Box Guardrail Receivers: 10'.
90073 (Rev. B)
!
WARNING
NEVER make any connections to Trench Box Guardrail Receiver.
User must inspect prior to EACH use. Competent Person must complete
formal inspection every 6 months. Competent Person to inspect and initial.
Date of First Use: __________________. Product lifetime is 5 years from
Date of First Use or, if not recorded, from Manufacturing Date.
