FOWLHOUSE
1.5W x 1.4D x 2.0Hm
Assembly instructions
Congratulations on purchasing your new Pinnacle fowl house. Before assembling, we recommend
you read the instructions thoroughly. Your new fowl house comes with pre-drilled holes to make assembly
quicker. We recommend you assemble the fowl house using a trestle table or sawhorses and planks.
This will ensure that you are working off the ground and make it easier for you. Assembly is a two-person
job and should not be attempted in windy conditions.
Tools required: Drill, measuring tape, Phillips-head screw driver, rivet gun, rubber mallet, sturdy ladder, shifting spanner, 2 saw horses, 3mm
steel drill bit and a 4mm steel drill bit.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Pinnacle Outdoor FOWLHOUSE
Summary of Contents for Pinnacle Outdoor FOWLHOUSE
- Page 1 FOWLHOUSE 1.5W x 1.4D x 2.0Hm Assembly instructions Congratulations on purchasing your new Pinnacle fowl house. Before assembling, we recommend you read the instructions thoroughly. Your new fowl house comes with pre-drilled holes to make assembly quicker. We recommend you assemble the fowl house using a trestle table or sawhorses and planks.
- Page 2 FOWLHOUSE 1.5 x 1.4 x 2.0m Build your fowl house in 7 easy steps! Step 1: Check all parts against the component list Step 2: Assemble the rear wall panels Step 3: Assemble the side wall panels Step 4: Assemble the roof panels...
- Page 3 Step 1: Check all parts against the component list Lay out all parts with number facing outwards and check off against parts list. Part Picture Description Component Location QTY Check Sheet Sheet 1800x770mm Rear wall Sheet Sheet 1800x708mm Side Wall Sheet Sheet 1800x708mm Side Wall...
- Page 4 FOWLHOUSE 1.5 x 1.4 x 2.0m Part Picture Description Component Location QTY Check Channel Channel 1508mm Rear Wall Channel Channel 1508mm Rear Wall Channel Channel 1508mm Front Channel Channel 1508mm Front Roof Side Channel Channel 1391mm Wall Channel Channel 1391mm...
- Page 5 Part Picture Description Component Location QTY Check Corner Jamb Jamb 1898 Corner Jamb Jamb 1898 Lip 812mm Roof SL08 Gable Cap Connector Connector Roof 1393 Ridge Beam Ridge Beam 1393 Roof Roof SG27 Gable R/H Gable 734 Gable L/H Gable 734 Roof SG28 Logo Cap...
- Page 6 FOWLHOUSE 1.5 x 1.4 x 2.0m Fittings part list: Picture Component Picture Component √ Self tapping screws (10mm) Self tapping screws (16mm) 4 x 10mm Rivet 3 x 10mm Rivet Keeper (71) Pad bolt (70) Qty checking date: ____ / ____ / _____...
- Page 7 Fowl house overview:...
- Page 8 FOWLHOUSE 1.5 x 1.4 x 2.0m Assemble the rear wall panels Step 2: For easier assembly of your fowl house use sawhorses with timber studs as per diagram below (timber needs to be the same length as the fowl house (1.5 M)) or alternatively, a trestle table.
- Page 9 Step 2: Assemble the rear wall panels (continued) NOTE: All screws marked with a cross should not be fixed at this stage.
- Page 10 FOWLHOUSE 1.5 x 1.4 x 2.0m Step 3: Assemble the side wall panels Place parts S77 & S79L (sheets) on your worktable and tap or slide on part 36F (top channel) and part 36A (bottom channel). Make sure the small lip of the channels is always facing out. This ensures rainwater cannot build up inside your fowl house.
- Page 11 Assemble the side wall panels (Continued) Step 3: Now repeat for other side wall. FIX WITH 16MM SCREWS FIX WITH 3 X 10MM RIVET...
- Page 12 FOWLHOUSE 1.5 x 1.4 x 2.0m Assemble the roof panel Step 4: Place 1 x part S81 (sheet) and 1 x part S82 (sheet) on your worktable and join together with the self-tapping screws as per the diagram below. 2 pre-punched holes to...
- Page 13 Step 5: Assemble the front wall panel Place part S80 (front wall sheet) on the worktable then fit parts 20T (top channel) and 20U (bottom channel) to the front wall sheeting and fix with self-tapping screws. Secure the iron mesh by riveting part C121 (channel) onto part 20T (top channel). It’s recommended you fix the back part first, then the front.
- Page 14 FOWLHOUSE 1.5 x 1.4 x 2.0m Fit parts 42 (jamb), J36 (jamb) and part 23 (bottom channel) to the front wall and fix with self-tapping screws. Make sure the joints are fixed as per the below diagrams. NOTE: All screws marked with a cross should not be fixed at this stage.
- Page 15 Attach the front door Step 6: Fix part D33 (pre-assembled door) to the front wall panel using a rivet gun and the provided 4.0 x 10mm rivets. FIX WITH 4 X 10MM RIVET...
- Page 16 FOWLHOUSE 1.5 x 1.4 x 2.0m Attach the front door (Continued) Step 6: Now fix part 70 (pad bolt) using the pre-drilled holes with the 10mm self-tapping screws or 3 x 10mm rivets provided. FIX WITH 10MM SCREWS FIX WITH 3 X 10MM RIVET...
- Page 17 Step 7: Fit the panels together Attach the two side walls to the back wall, then fit the front wall by fixing 2 x parts Z34, 1 x part Z35 and 1 x part Z36 (corner bracing) Fix all of these components together using the provided self-tapping screws as per the diagram below.
- Page 18 FOWLHOUSE 1.5 x 1.4 x 2.0m Once all 4 panels are fixed together attach 2 x part SG28 (Gable L/H) and 2 x part SG27 (Gable R/H) to the front and back panels with the provided self tapping screws as per diagram below. Note: Fix the pad bolt keeper with the provided 16mm self-tapping screws or 3 x 10mm rivets at this stage as well.
- Page 19 Start assembling the roof by fixing part 93 (ridge beam) to part 92 (gable cap connector) and then fix to one of the assembled roof panels from step 4. CHANNEL TYPE 36A THIS END CHANNEL TYPE 36C THIS END...
- Page 20 FOWLHOUSE 1.5 x 1.4 x 2.0m Once half the roof is fixed together, place on top of fowl house and slide the other assembled roof panel from step 4 into place and fix from underneath. Now attach 4 x part SL08 (lips) to the front and back ends of the roof panels as per diagram below.
- Page 21 Fix 4 x part SL08 (lips) to the front and back ends of the roof panels with the provided 16mm self tapping screws. Now place 2 x part E1 (logo cap) to the front and back peaks and fix with the provied 16mm self tapping screws as per diagram below. FIX IT WITH 16MM SELF TAPPING SCREWS FIX IT WITH 16MM...
- Page 22 FOWLHOUSE 1.5 x 1.4 x 2.0m A bolt down kit can be purchased from your local Bunnings store and attached to this fowl house. Please refer to diagram below for installation. BOLT NUT WALL SHEET STEEL ANGLE SLAB SLEEVE ANCHOR BOLT...
- Page 23 Warranty statement: This warranty against defects is given by: Pinnacle Hardware. Business Address: 28 Hudson Court, Keysborough VIC 3173 1800 349 776 Email: support@pinnacle.net.au New Zealand customers please contact: HARCO (Harkness & Young Ltd) Ph: 09 276 4071 Email: sales@harknessyoung.co.nz Details of Manufacturer’s Warranty This product comes with a 15 year limited structural warranty (“the Warranty Period”) from the date of purchase.
- Page 24 FOWLHOUSE 1.5 x 1.4 x 2.0m IMPORTANT 1. Manufacturer’s Disclosure This warranty against defects shall not apply in the following situations: A) Where the product is not assembled in accordance with the instructions provided in the product kit. B) Where the product is used to store corrosive materials such as fertilizer, chlorine etc;...
