  • Page 1 OBLIQUE E E LECTRIC ELECTRIC W W ALL H H EATER MODEL P P 23E INSTALLATION A A ND U U SER I I NSTRUCTIONS Read a a nd u u nderstand t t hese i i nstructions c c ompletely b b efore c c ommencing a a ny a a ssembly o o r i i nstallation. Check t t hat a a ll c c omponents a a re i i ncluded i i n t t he p p ack.
  • Page 2: Table Of Contents

    PRELIMINARY N N OTES The Oblique electric wall heater provides convected heating in conjunction with a visual fuel effect display. The appliance is designed for indoor use, and can be flat wall mounted in the majority of wall positions antici- pated.
  • Page 3: Site Requirements

    SITE R R EQUIREMENTS The appliance can be flat wall mounted via the brackets on the rear panel with the fixings provided. The wall should be relatively flat and not interfere with any of the ventilation slots in the rear panel. Alternatively, it can be mounted in a corner wall using the corner wall mounting bracket and fixings pro- vided.
  • Page 4: Unpacking The Appliance

    Corner W W all L L ocation: The minimum distance from the top of the appliance to a ceiling is 700mm. The minimum distance to the sides of the appliance is 100mm. The minimum distance to the front of the applaince is 500mm. The appliance can be wall mounted at floor level, providing it does not stand on a carpet or similar material.
  • Page 5: Fixing The Appliance

    4. Remove the lower rear corner bracket fixing screw by turning anti- Fig 3 3 clockwise, as shown in figure 3. 5. The front hinged door can now be carefully closed. Gently lift the appliance and remove the rear corner bracket by sliding the bracket downward slightly and remove completely from the appliance.
  • Page 6 FIXING T T HE A A PPLIANCE ( ( continued) a) F F lat W W all L L ocation: There are three fixing positions, two upper “hanging” positions”, and one lower position on the back-panel locat- ed behind the fuel bed. A template is provided to aid location of fixings. Use a spirit level to ensure that the tem- plate is level.
  • Page 7: Operating The Appliance

    Ensure that the lower retaining stud on the corner mounting bracket is visible and lines up with the hole in the lower back panel of the appliance, as previously shown in figure 3. Refer to figure 3 and figure 6, fully open the door, and then re-insert the lower corner retaining screw through the hole in the rear of the appliance.
  • Page 8: Safety Cut-Out System

    To operate the fire in any of the above modes, the front switch marked ( ( OI) must be switched to the “on” posi- tion. To operate the fire, the first switch must be turned on firstly, followed by the second switch to start the blower, if required.
  • Page 9: Cleaning

    13.0 CLEANING ALWAYS D D ISCONNECT/ISOLATE T T HE A A PPLIANCE A A T T T HE S S UPPLY/OUTLET SOCKET A A ND ALLOW TO COOL BEFORE U U NDERTAKING A A NY C C LEANING. Regularly clean around the appliance to ensure that dust, fluff, pet hair/dander etc, are kept to a minimum. There are no other specific requirements for care, other than regular cleaning of the general appliance.
