  • Page 1 CD 2737B CD 2537U CD 2327G CD 2217G User manual Mode d’e emploi Bedienungsanleitung Gebruiksaamwijzing Instuzioni d’uso Instrucctiones de manejo Modo de emprego Bruksanvisning Betenningsveiledning Käyttöohje Εγχειρίδιο χρήστη www.vdodayton.com...

  • Page 3: Product Views

    SOURCE MUTE SOURCE MUTE SOUND BAND 10 5 SOUND BAND 10 5 CD 2737B AUX IN CD 2327G AUX IN...
  • Page 4 TALK The Remote Control is a separate accessory. Please contact your dealer. 8mm 188mm...
  • Page 5 SDVC N.C. N.C. N.C. Illumination Blink Illumination Power Microphone-In + Talk (Headunit) Pink Tel.Mute BT Mic. Blue SWRC+ White Brown Preamp SWRC- Gray R. Amp. Illumination Ground Illumination Switch Microphone Ground...

  • Page 7: Introduction

    INTRODUCTION Before Starting Thank you for purchasing this VDO Dayton product, which has been designed and manufactured according to applicable Safety Regulations, following the highest standards and subjected to rigor- ous testing. Kindly familiarize yourself with the product by reading this user manual carefully. Use the product as intended, and keep this manual handy in your car for future reference.

  • Page 8: Table Of Contents

    CONTENT PAGE INTRODUCTION ...7 Before Starting... Environment ... Preventive Maintenance ... TECHNICAL AND FUNCTION DATA ...7 CONTENT PAGE ...8 GENERAL INFORMATION ...9 Disclaimer ...9 Class 1 Laser Product ...9 Disposal of batteries and accumulators (Directive 2006/66/EC) ...9 FCC Compliance ...9 CE Compliance...9 Protecting your headunit from theft ...10 CD player and care...10...

  • Page 9: General Information

    The designs and specifications stated in this user manual are subjected to changes without prior notice. VDO Dayton accepts no responsibility for data loss on your storage cards and/or USB devices if the data is lost while using this headunit.

  • Page 10: Protecting Your Headunit From Theft

    Protecting your headunit from theft The front panel can be detached from the head- unit and stored in the provided protective case to prevent theft. Important: Never use force or grip the display and the  buttons too tightly when removing or attach- ing.

  • Page 11: Notes On Mp3 Files

    Notes on MP3 files The following MP3 files are supported by the headunit: Files conforming with MPEG 1/2 or 2.5,  Layer-3 Up to 65k titles in up to 255 directories (each  data name with maximum of 32 characters) Bit rate: This headunit can play recordings ...

  • Page 12: Notes On Sd/Mmc

    Notes on SD/MMC The headunit can support the following SD or MMC card that has one of these markings shown below. The headunit can support memory cards with  up to 2 GB of memory and does not support HC-SD (4 GB and above). The headunit may not play SD cards with ...

  • Page 13: Installation

    INSTALLATION Use the supplied mounting sleeve and the rear screw to mount the headunit firmly in the dashboard. Only use the supplied screws for installation. Keep leftover installation equipment for future use. If the installation requires drilling of holes or other modifications to the vehicle, please contact your dealer.

  • Page 14: Wire Of Telephone Mute

    Wire of Telephone Mute If your mounted hands-free car kit of your mo- bile phone provides a mute signal wire, you can connect this wire to the headunit’s telephone mute wire to enable automatic interruption of the headunit’s sound output during an incoming phone call.

  • Page 15: Location Of The Bluetooth Microphone Module

    Location of the Bluetooth Microphone Module The distance between driver and the Blue-  tooth Microphone Module should be within 00 mm with no obstacle in-between. The said module should be placed in the front near the centre console, for example, be- sides the headunit.

  • Page 16: Front Panel And Remote Control

    FRONT PANEL AND REMOTE CONTROL See figures A and B. Remote Headunit Control (11) MUTE (10) SOURCE SOUND BAND Action Tuner Mute Power On / Off Decrease (lower) Decrease (lower) volume volume Increase (higher) Increase (higher) volume volume Change source Enter SAM menu Activate Auto Store Enter SOUND menu...
  • Page 17 Remote Headunit Action Control (12) (10) (11) (12) (13) (14) (15) (16) (17) (18) Note: * Depending on model SP: Short Press LP: Long Press CD, USB *, SD / Tuner MMC * & Aux Auto search fre- quency down Track fast-rewind (PTY mode: select (continuously press)

  • Page 18: General Operation

    GENERAL OPERATION Switching On / Off To switch on the headunit, short-press the knob. To switch off the headunit, long-press the button. Selecting a Source Your headunit is designed for different types of sources, depending on your headunit model. RADIO ...

  • Page 19: Am Band

    AM Band For ease of operation, you may turn-off the AM bands, totally or individually for MW or LW, in the case that you do not need to use them. To toggle the AM setting: Navigate the SAM to select ‘AM’. Turn the knob clockwise / anti-clockwise to turn on or off MW, LW or both (AM).

  • Page 20: Interrupting Ta

    Interrupting TA If you do not wish to continue listening to a par- ticular Traffic Announcement broadcast, you can interrupt it without switching off the TA mode. Short-press the button once, the hea- dunit will return to the previous operating mode.

  • Page 21: Listening To Music

    Listening to Music Multi-Session Disc For multi-session discs, if the first track is a data track, the disc will be treated as compressed audio disc. However, if no compressed audio file was found throughout the disc, then it will be treated as an audio disc.

  • Page 22: Bluetooth Operation

    BLUETOOTH OPERATION General You can use the Bluetooth in your car to make a phone call hands-free or stream music onto your in-car speakers (via this headunit). Controls (fig. K) Bluetooth status Button Handsfree Inactive (HFP/HSP) Reject phone (n.a.) (incoming call) MUTE Press more Answer phone...

  • Page 23: Telephone Mute

    Telephone Mute This headunit was designed to interface with dif- ferent types of hands-free kits that provide tel- ephone mute cables. Please read the instruction manual of your hands-free kit on its mute logic level (either mute-high or mute-low). Navigate the SAM to select ‘TEL MUTE’. Turn the knob clockwise / anti-clockwise to toggle the logic level according to your hands-free kit type.
  • Page 24 Continue programming your SWRC’s buttons to the pre-defined as much as possible with the same steps. For those buttons that you do not need, please disabled them by selecting “-DIS- ABLE-” and press-and-hold the unwanted buttons for more than 2 seconds. Important Note: In the case that you did not disable the unwanted SWRC buttons, due to the complexity of the programming to cater to most...

  • Page 25: Software Access Menu (Sam)

    SOFTWARE ACCESS MENU (SAM) It is possible to customize your headunit settings to your personal preferences via the SAM. To navi- gate the SAM, here are the steps: Short-press the button to enter the SAM.  Short-press button to select the next SAM menu item; or short-press the ...
  • Page 26 Option Setting (◄/▼ or ►/▲) (turn the knob) BRIGHTNESS [1, 2] COLOR [ORANGE, GREEN, MIXED] LOGIC [OFF, ON] [OFF, ON] MULTI-S [OFF, ON] SCROLL [OFF, ONCE, SCAN TIME [5S, 10S, 20S] REGION [EUROPE, AMERICA, ASIA, LATAM] [OFF, ON] [AM OFF, MW OFF, LW OFF, AM ON] REG-RDS...
  • Page 27 Option Setting (◄/▼ or ►/▲) (turn the knob) TA EON [OFF, LO, DX] [PTY OFF, PTY ON, NEWS INT] BLUETOOTH [BT OFF, HFP 1ST, A2DP 1ST, DEVICE] Usage Select 'EON DX' to allow distant EON stations broadcast. Note: The quality of reception (and hence sound output) of the distant EON stations may be poor Select the various Programme Type (PTY) modes: Select 'PTY OFF' to turn off this PTY function...

  • Page 28: Troubleshooting

    TROUBLESHOOTING Maybe, it will happen that your headunit will not function as you expected it to be. Before calling for service, please read this user manual and review carefully the setting values. You may find that a function cannot work properly with the values you defined.
