Owner's Manual
M odel:NST- 300S2- BK
www.vantecusa.com
All Registered Trademarks Belong To Their Respected Companies.
Copyright © 2007 Vantec Thermal Technologies. All Rights Reserved.
4.Installation
4-1 Connect the 3.5" hard drive to the SATA/Power connector.
4-2 Secure the hard drive onto the drive caddy with the screws provided. See
picture below for where the screws are to go.
4
1.Introduction
Vantec introduces its NexStar CX 3.5" SATA External Hard Drive Enclosure. Ideal for anyone
in need of storing and transferring large amounts of data, the NexStar CX is a convenient
way of upgrading storage to your computer. TheNexStar CX turns any internal 3.5" SATA
Hard Drive into an external hard drive that can be used on any system with a USB port. In
addition, the aluminum casing protects the drive from overheating and vibration. The
NexStar CX supports USB 1.1 and USB 2.0 to offer fast transfer speeds of up to 480Mbps.
The Vantec NexStar CX 3.5" SATA External Hard Drive Enclosure is great for anyone who
requires a high performance, lightweight, and durable external storage solution.
2.System Requlrements
Intel Pentium II 350 MHz Compatible or Mac G3 Processor & Greater
Microsoft Windows 98SE/ME/2000/XP/Vista or Mac OS 8.6 & Greater
USB-Equipped System
For USB 2.0 Speeds, the System Must Support USB 2.0 Specifications
1
4-3 Insert the drive caddy back into the aluminum housing. Be sure to reconnect
the LED cable before closing the unit. When reinserting the caddy, also be
sure to align the top of the caddy with the guides on the housing.
5
3.Specifications/Features
Features:
Aluminum Casing Cools Down Your Hard Drive.
Transfer Rates Up to 480Mbps w/USB 2.0.
Easily Add Storage to Any System with USB.
Hot-Swappable: Plug & Play Without Rebooting.
Attractive Blue LED Indicates Power & HDD Activity.
Specifications:
Package Includes:
Device Support:SATA I/II Hard Drive
3.5" NexStar CX Enclosure
Device Size:3.5"
Power Adapter
Internal Interface:SATA
USB Cable
External Interface:USB 2.0
User Manual
Material:Aluminum
Installation Screws
Dimension:215 x 123 x 31mm
Vertical Stand
2
4-4 Secure the caddy to the housing using the screws provided.
6
3.Parts Layout
SATA/Power Connector
LED Cable
Hard Drive Caddy
Aluminum Housing
3
5. Warranty
The Nexstar CX comes with a 1 year limited warranty (90 day parts). If your unit become
defective within that time frame, please go to http://www.vantecusa.com for
information on how to receive warranty exchange or repair. Cosmetic defects and
missing parts are not covered under this warranty. Please check the contents of the unit
to make sure you received all parts.Also,check for any cosmetic flaws. If any parts are
missing or if there are cosmetic defects, please contact the retailer from which you
purchased the unit immediately and ask for a replacement.
Vantec Thermal Technologies
43951 Boscell Rd.
Fremont, CA 94538
tel: 510-668-0368
fax: 510-668-0367
website: www.vantecusa.com
7
