Introduction
Description
Voice Daughtercards
This quick reference guide provides general information on Vanguard Networks
Voice Daughtercards.
The voice daughtercards described in this guide can in be installed in the following
Vanguard Networks devices:
• Vanguard 340E/342
• Vanguard 6435/6455
• Vanguard 6840/6841
Figure 0-1 shows the current Vanguard devices.
Note
The Vanguard Networks models 100, 305, 320, 340, and 6425/6430/6450 have
been sunset and are not covered in this manual.
Vanguard 6840/6841
Figure 1. The Current Vanguard Networks Devices
Vanguard Networks
Quick Reference Guide
Voice Daughtercards
--NODE UP--
Vanguard 6435/6455
Vanguard 340E/342
1
Advertisement
Related Manuals for Vanguard Vanguard Networks 340E/342
Summary of Contents for Vanguard Vanguard Networks 340E/342
-
Page 1: Quick Reference Guide
Introduction This quick reference guide provides general information on Vanguard Networks Voice Daughtercards. Description The voice daughtercards described in this guide can in be installed in the following Vanguard Networks devices: • Vanguard 340E/342 • Vanguard 6435/6455 • Vanguard 6840/6841 Figure 0-1 shows the current Vanguard devices. - Page 2 Vanguard Voice Figure 0-2 illustrates the current set of Vanguard Networks voice daughtercards and Daughtercards their the applicable Vanguard Networks devices. Dual E&M Daughtercard • 340E/342 • 6435/6455 • 6840/6841 FXO-1 4-Port FXO Daughtercard • 340E/342 • 6435/6455 • 6840/6841 FXO/FXS Daughtercard •...
- Page 3 Typical Refer to Figure 0-4, and follow this procedure to install a voice daughtercard into a Daughtercard typical Vanguard Networks product (the Vanguard 340E/342 is shown): Installation Procedure Step Voice Daughtercards Power down the unit and remove the cables and power cord. Remove the motherboard.
- Page 4 Figure 4. Vanguard Network Device Typical Daughtercard Installation Mounting Screws Note Extended voice daughtercard is shown, requiring the use of two mounting screws and two standoffs Interface Header Faceplate Screws Voice Daughtercards...
