VMH26TPB
VMH26TNB
14,000 to 26,000 Btu/Hr
with Thermostat
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result
causing property damage, personal injury, or
loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity of
this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call
the fire department.
— Installation and service must be performed by
a qualified installer, service agency, or the gas
This appliance may be installed in an aftermarket,* permanently located, manufactured
(mobile) home, where not prohibited by local codes.
This appliance is only for use with type of gas indicated on the rating plate. This appliance
is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
VENT-FREE COMPACT FIREPLACE
OWNER'S OPERATION AND INSTALLATION MANUAL
®
Save this manual for future reference.
Save this manual for future reference.
Shown with Optional
Cabinet Mantel/Hearth
Base Accessory
WARNING: Improper installation, adjust-
ment, alteration, service, or maintenance
can cause injury or property damage.
Refer to this manual for correct installa-
tion and operational procedures. For as-
sistance or additional information con-
sult a qualified installer, service agency,
or the gas supplier.
WARNING: This is an unvented gas-
fired heater. It uses air (oxygen) from the
room in which it is installed. Provisions
for adequate combustion and ventila-
tion air must be provided. Refer to Air for
Combustion and Ventilation section on
page 4 of this manual.
Advertisement
Table of Contents
Related Manuals for Vanguard WMH26TNB
Summary of Contents for Vanguard WMH26TNB
- Page 1 For more information, visit www.desatech.com For more information, visit www.desatech.com VMH26TPB VMH26TNB 14,000 to 26,000 Btu/Hr with Thermostat WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury, or loss of life.
-
