UNVENTED (VENT-FREE)
PROPANE/LP GAS LOG HEATER
This appliance may be installed in an aftermarket* manufactured (mobile) home,
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer
OWNER'S OPERATION AND INSTALLATION MANUAL
18", 24", and 30"
Remote-Ready
Models
WARNING: If the information in this manual
is not followed exactly, a fire or explosion
may result causing property damage, per-
sonal injury, or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
— Installation and service must be per-
formed by a qualified installer, service
agency, or the gas supplier.
where not prohibited by state or local codes.
VS18PR VS24PR VS30PR
Save this manual for future reference.
WARNING: Improper installation, adjustment,
alteration, service, or maintenance can cause
injury or property damage. Refer to this manual
for correct installation and operational proce-
dures. For assistance or additional information
consult a qualified installer, service agency, or
the gas supplier.
WARNING: These gas log sets are for installa-
tion in a masonry solid fuel burning fireplace, a
U.L. listed manufactured solid fuel burning
fireplace or an AGA design certified vent-free
firebox (including LogMate series fireboxes
and stoves) listed for use with these gas log
models.
WARNING: This is an unvented gas-fired
heater. It uses air (oxygen) from the room in
which it is installed. Provisions for adequate
combustion and ventilation air must be pro-
vided. Refer to "Air for Combustion and Venti-
lation" section in this manual.
®
®
Advertisement
Table of Contents
Related Manuals for Vanguard VS24PR
Summary of Contents for Vanguard VS24PR
- Page 1 — Installation and service must be per- formed by a qualified installer, service agency, or the gas supplier. Save this manual for future reference. VS18PR VS24PR VS30PR WARNING: Improper installation, adjustment, alteration, service, or maintenance can cause injury or property damage. Refer to this manual for correct installation and operational proce- dures.
-
Page 2: Table Of Contents
CONTENTS SECTION Safety Information ... 2 Product Identification ... 4 Local Codes ... 4 Unpacking ... 4 Product Features ... 4 Air for Combustion and Ventilation ...5 Installing ... 8 Check Gas Type ...8 Installation and Clearances ... 9 Installing Heater Base Assembly ... 12 Connecting to Gas Supply ... - Page 3 SAFETY INFORMATION WARNING: Any change to this heater or its controls can be dangerous. 1. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not Continued convertible for use with other gases. 2.
-
Page 4: Product Identification
Top Middle Left Front Branch Front Burner Right Front Branch Control Knob Flame Adjustment Knob Figure 1 - VS24PR Shown 1430 Broadway New York, NY 10018 Crossover Log Rear Log Base Assembly Remote Selector Switch (Optional) National Fire Protection Association, Inc. -
Page 5: Air For Combustion And Ventilation
AIR FOR COMBUSTION This heater shall not be installed in a confined space unless provisions are provided for adequate combustion and ventilation air. Read the following instructions to insure proper VENTILATION fresh air for this and other fuel-burning appliances in your home. Today’s homes are built more energy efficient than ever. - Page 6 DETERMINING AIR FLOW FOR HEATER LOCATION AIR FOR Determining if You Have a Confined or Unconfined Space COMBUSTION Use this work sheet to determine if you have a confined or unconfined space. Space: Includes the room in which you will install heater plus any adjoining rooms with doorless VENTILATION passageways or ventilation grills between the rooms.
- Page 7 AIR FOR COMBUSTION If the area in which the heater may be operated is smaller than that defined as an uncon- fined space, provide adequate combustion and ventilation air by one of the methods VENTILATION described in the National Fuel Gas Code, ANSI Z223.1, 1992, Section 5.3. Continued VENTILATION AIR Ventilation Air From Inside Building...
-
Page 8: Installing
INSTALLING A qualified service person must install heater. Follow all local codes. State or local codes may only allow operation of this appliance in a vented configuration. Check your state or local codes. Make sure the remote selector switch is in the OFF position before installing heater. Before installing in a solid fuel burning fireplace, the chimney flue and firebox must be cleaned of soot, creosote, ashes and loose paint by a qualified chimney cleaner. -
Page 9: Installation And Clearances
INSTALLATION AND CLEARANCES INSTALLING Continued Maintain the minimum clearances. If you can, provide greater clearances from floor, ceiling, and adjoining wall. Carefully follow the instructions below. This will ensure safe installation into a masonry or U.L. listed manufactured fireplace or an AGA listed vent-free firebox approved for use with these gas log heaters. Minimum Wall and Ceiling Clearances (see Figure 4) A. - Page 10 INSTALLING Non-Combustible Continued Material Distance (A) 12" or more Between 8" and 12" Less than 8" Non-combustible material must extend 8" above the fireplace opening. Minimum Non Combustible Material Clearances If Using Mantel You must have non-combustible material(s) above the fireplace opening. Non-combustible materials (such as slate, marble, tile, etc.) must be at least 1/2 inch thick.
- Page 11 Mantel Clearances INSTALLING If you meet minimum clearance between mantel shelf and top of fireplace opening, a hood is not required Continued (see Figure 6). If above minimum clearances are not met, you must have a hood. Follow minimum clearances shown in Figure 7 when using hood.
-
Page 12: Installing Heater Base Assembly
Floor Clearances INSTALLING A. If installing appliance on the floor level, you must maintain the minimum distance of 14" to combus- Continued tibles (see Figure 8). B. If combustible materials are less than 14" to the fireplace, you must install appliance at least 5" above the combustible flooring (see Figure 9). - Page 13 Installation Items Needed INSTALLING • hardware package (provided with heater) Continued • approved flexible gas hose (not provided) (if allowed by local codes) • sealant (resistant to propane (LP) gas, not provided) • electric drill with 3/16" drill bit Install optional GHRCT Receiver and Hand Held Remote Control Kit (see Accessories, page 30) Note: before installing gas log heater.
-
Page 14: Connecting To Gas Supply
CONNECTING TO GAS SUPPLY INSTALLING Continued A qualified service person must connect heater to gas supply. Follow all local codes. Never connect heater directly to the propane supply. This heater requires an external regulator (not supplied). Install the external regulator between the heater and propane supply. Installation Items Needed Before installing heater, make sure you have the items listed below. -
Page 15: Checking Gas Connections
Installation must include a manual shutoff valve, union, and plugged 1/8" NPT tap. Locate NPT tap within INSTALLING reach for test gauge hook up. NPT tap must be upstream from heater (see Figure 13). Continued Apply pipe joint sealant lightly to male threads. This will prevent excess sealant from going into pipe. Excess sealant in pipe could result in clogged heater valves. -
Page 16: Installing Logs
Pressure Testing gas Supply Piping system INSTALLING Test Pressures In Excess Of 1/2 PSIG Continued 1. Disconnect heater and its individual manual shutoff valve from gas supply piping system. Pressures in excess of 1/2 psig will damage heater regulator. 2. Cap off open end of gas pipe where manual shutoff valve was connected. 3. - Page 17 INSTALLING LOGS INSTALLING Continued Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this heater may result in property damage or personal injury. Each log is marked with a number. These numbers will help you identify the log when installing. It is very important to install these logs exactly as instructed.
-
Page 18: Operating Heater
INSTALLING 4. Place the crossover log (#5) on the back log and the top middle log. Make sure the peg on the rear log is in the hole in the bottom of the crossover log. The crossover log should fit in the cutout of the top Continued middle log (see Figure 20). - Page 19 OPERATING HEATER Continued • If fireplace has glass doors, never operate this heater with glass doors closed. If you operate heater with doors closed, heat buildup inside fireplace will cause glass to burst. Also if fireplace opening has vents at the bottom, you must open the vents before operat- ing heater.
-
Page 20: To Turn Off Gas To Appliance
8. Keep control knob pressed in for 30 seconds after lighting pilot. After 30 seconds, release control OPERATING knob. HEATER • If control knob does not pop out when released, contact a qualified service person or gas Continued supplier for repairs. Note: 9. - Page 21 OPERATING OPTIONAL GHRCT HAND HELD REMOTE OPERATION HEATER Continued You must light the pilot before using the hand-held remote control unit. See Lighting Instructions on page 19. Figure 23 - Setting the Remote Selector Switch, Control Knob, and Flame Adjustment Knob The GHRCT receiver and hand-held remote control must be purchased separately (see Note: Accessories, page 30).
-
Page 22: Inspecting Burners
Check pilot flame pattern and burner flame patterns often. INSPECTING PILOT FLAME PATTERN BURNERS Figure 25 shows a correct pilot flame pattern. Figure 26 shows an incorrect pilot flame pattern. The incorrect pilot flame is not touching the thermocouple. This will cause the thermocouple to cool. When the thermocouple cools, the heater will shut down. -
Page 23: Cleaning And Maintenance
CLEANING AND MAINTENANCE You must keep control areas, burners, and circulating air passageways of heater clean. Inspect these areas of heater before each use. Have heater inspected yearly by a qualified service person. Heater may need more frequent cleaning due to excessive lint from carpet- ing, bedding material, etc. - Page 24 OBSERVED PROBLEM TROUBLE- SHOOTING ODS/pilot lights but flame goes out when Continued control knob is released One or both burners do not light after ODS/pilot is lit Delayed ignition of one or both burners Burner backfiring during combustion Yellow flame in front burner during burner combustion Slight smoke or odor...
- Page 25 TROUBLE- OBSERVED PROBLEM SHOOTING Heater produces a whistling noise when Continued burners are lit If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. •...
-
Page 26: Specifications
SPECIFICATIONS Btu (Variable) Type Gas Ignition Pressure Manifold Inlet Gas Pressure (in. of water) Maximum Minimum* * For purpose of input adjustment Shipping Weight WIRING DIAGRAM You may have further questions about installation, operation, or troubleshooting. If so, contact DESA TECHNICAL International’s Technical Service Department at 1-800-DESA LOG (1-800-337-2564). -
Page 27: Replacement Parts
Use only original replacement parts. This will protect your warranty coverage for parts replaced REPLACEMENT Note: under warranty. PARTS Parts Under Warranty Contact authorized dealers of this product. If they can’t supply original replacement part(s), call DESA International’s Technical Service Department at 1-800-323-5190. When calling DESA International, have ready •... -
Page 28: Illustrated Parts Lists
ILLUSTRATED PARTS BREAKDOWN Variable Control Model VS18PR VS24PR VS30PR 10-2 10-1 103448... -
Page 29: Parts List
099387-09 101004-10 101004-10 103783-01 099998-01 100563-01 103877-01 100565-01 100639-01 101137-02 101416-27 GA6060 103448 PART NUMBERS VS24PR VS30PR DESCRIPTION 103580-01 103580-03 Left Front Log (1L) 103580-02 103580-02 Right Front Log (1R) 103576-02 103576-02 Bottom Middle Log 103577-01 103577-03 Rear Log (#3) -
Page 30: Accessories
ACCESSORIES Purchase these heater accessories from your local dealer. If they can not supply these accessories, call DESA International’s Parts Department at 1-800-972-7879 for referral information. You can also write to the address listed on the back page of this manual. MANUAL SHUTOFF VALVE - GA5010 For all models. - Page 31 __________________________________________________________________________ NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ 103448...
-
Page 32: Warranty Information
WARRANTY INFORMATION Model Serial No. Date Purchased Always specify model and serial numbers when communicating with the factory. We reserve the right to amend these specifications at any time without notice. The only warranty applicable is our standard written warranty. We make no other warranty, expressed or implied. VENT-FREE PROPANE GAS LOG HEATERS DESA International warrants this product to be free from defects in materials and components for three (3) years and five (5) years on stainless steel burners from the date of first purchase, provided that the product has been properly installed,...
