Thank-you for choosing the Vandersteen VCC-5 Reference, a center
speaker
designed for the full-range signal of modern discrete multi-
channel formats (Ie. AC-3 and/or DTS). With proper care, your new
speaker will provide many years of trouble free, high quality performance.
We recommend that you read this entire manual prior to installing,
connecting or using your Vandersteen VCC-5 Video Center Channel
Dialog Speaker.
The VCC-5 Video Center Channel Dialog Speaker
is an integral part of a home audio/video system
where it helps localize dialog and other movie
sounds at the TV screen. The VCC-5 is the product
of extensive research into the qualities required for
realistic movie sound reproduction. The engineer-
ing, construction and materials of the VCC-5 far ex-
ceed conventional industry standards and result in a
level of performance unmatched by other center
channel dialog speakers.
The VCC-5 is a phase coherent design intended to
be used in a high-quality audio/video surround sys-
tem in combination with main speakers that have ac-
curate frequency response and phase response.
Whether you chose Vandersteen Audio main speak-
ers or others with the proper qualities, the seamless
CONTENTS
Vandersteen A/V
blend with the VCC-5 will insure maximum intelli-
gibility on dialog and superior realism on music and
sound effects.
