Valor DV-180 User Manual

Half din size dvd player
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HALF DIN SIZE DVD PLAYER
MODEL: DV-180

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV-180 and is the answer not in the manual?

Questions and answers

Summary of Contents for Valor DV-180

  • Page 1 HALF DIN SIZE DVD PLAYER MODEL: DV-180...

  • Page 3: Audio System(S)

    Technical Specifications Supply Voltage: 12VDC(10.8V~ 16V), test voltage 13.2V, negative ground Environment temperature: 0 ~45 Chassis Dimensions: 183.4x178x50(mm) Current Consumption: Less than 2A Quiescent 5mA Video system NTSC/PAL/AUTO Discs Played: (1) DVD-VIDEO Disc 5 (12cm)single-sided, single-layer 5 (12cm)single-sided, double-layer (2)Compact Disc(CD-DA,VIDEO CD) 5 (12cm) disc Audio Output Level: 2ch 2.0 +0/-1Vrms(10K )

  • Page 4: Table Of Contents

    CONTENTS Safety Information...3 Disc Notes ...4 Front panel...5 Rear panel Electrical Connection...5 Remote Control ... 6 Preparing the Remote Control...6 Loading a DVD/VCD/CD Disc ... 7 Ejecting a Disc ... 7 Basic Operation...7 On-Screen Display Function ... 8 Multi-audio Language Function...8 Menu Function ...

  • Page 5: Safety Information

    Accessories and Hardware Diagram N o. Item User Manual Remote Control A/V Connections Power Supply Connections External Remote Sensor Rubber Foot Note: The use of any accessories except for those provided might result in damage to the unit. Make sure only to use the accessories shipped with the unit, as shown above. Safety information Caution: Mobile DVD player is a class A laser product.
  • Page 6 Disc Cleaning Preparing New Discs with Rough Spots Use a dry soft cloth to wipe the surface. If the disc is quite dirty, use a soft cloth slightly A new disc may have rough edges on its inside moistured with isopropyl (rubbing) alcohol. and outside edges.

  • Page 7: Rating Setup

    RATING SETUP Password Type the old password ( The initial factory Language Language Language Video Video Video Audio Audio Rating Rating Rating code is null) and key in a new four character password of you choice to confirm. * * * * **** **** Password...

  • Page 8: Using The Remote Control

    Zoom in the capture Select playing discs recorded in either PALor NTSC format in the stop/No Disc mode Changes the view angle on multi-angle DVD DV-180 DV-180 disc Selects forward back slow motion Playback Preparing the Remote Control...

  • Page 9: Initial Setup

    INITIAL SETUP LANGUAGE SETUP SETUP MENU---MAIN PAGE Language Language Video Rating OSD Menu Subtitle OSD Menu English Audio Subtitle Disc Menu Audio English Disc Menu English Language 1. Press SETUP in the stop mode. OSD Menu 2. The initial SETUP menu is displayed. Subtitle 3.

  • Page 10: On-Screen Display Function

    On-Screen Display Function Mute Function Press MUTE button on the Remote Control Press the DISPLAY button during playback to display the contents of the current disc on to cut down the Sound output. the screen. Press it again or vol + to resume to previous volume Level.
